- Page 1 Team Home Manual DE / EN...
-
Page 3: Table Of Contents
Inhalt / Contents Technische Daten / Technical specifications Allgemeine Hinweise / General information Pflegehinweise / Care instructions Sicherheitshinweise / Safety instructions Gewährleistung / Warranty Lieferumfang / Scope of delivery Maße / Dimensions Installation Demontage / Disassembly Funktionen / Functions Features... -
Page 4: Technische Daten / Technical Specifications
Technische Daten / Technical specifications PRI 220 – 240 V / 50 – 60 Hz / SEC max. 60 V 780 mA / 35 W LED, 2700 – 4000 K, Direkt CRI 90+ Schutzklasse I / Protection class I Der indirekte Lichtanteil dieser Leuchte enthält eine Lichtquelle der Energieeffizienzklasse C;... -
Page 5: Allgemeine Hinweise / General Information
• Differences in LED brightness and white tone are a normal occurrence in manufacture and do not constitute reason for complaint. • The LEDs can be replaced by the manufacturer only. Manual Team Home •... -
Page 6: Pflegehinweise / Care Instructions
Sicherheitshinweise / Safety instructions • Die Leuchte darf nicht geöffnet werden. • Diese Leuchte ist entsprechend der EU-Verordnung ordnungsgemäß zu entsorgen. • Do not open the luminaire. • This luminaire is to be disposed properly according to EU regulation. Manual Team Home •... -
Page 7: Gewährleistung / Warranty
We will process your claim as soon as possible. In the event of a return, please ensure that the luminaire is packed in protective packaging to prevent damage in transit. Manual Team Home •... -
Page 8: Lieferumfang / Scope Of Delivery
Leuchtkopf / Luminaire head Schaft / Shaft Leuchtenfuß / Base Abdeckung / Cover Inbusschlüssel / Allen key Schrauben M5 x 16 / M5 x 16 screws Ersatzschrauben und Sicherungsscheiben / Leuchtenkopf Spare screws and lock washers luminaire head Manual Team Home •... -
Page 9: Maße / Dimensions
Betrieb genommen wurde, erlischt das Recht auf Reklamationen wegen ästhetischer Mängel. Please check the luminaire for optical flaws or scratches before use. Once the product has been put into operation, the right to claim for aesthetic defects expires. Manual Team Home •... -
Page 10: Installation
Installation Entferne die Abdeckung des Leuchtenfußes. Remove the cover of the lamp base. Manual Team Home •... - Page 11 Insert the screws into the base and secure with captive washers. Place the shaft on a soft surface and align. Tight- en the screws lightly, align the foot straight, then tighten. Extend Allen key with enclosed tube for better leverage. Manual Team Home •...
- Page 12 Installation Setze die Abdeckung ein. Insert the cover. Manual Team Home •...
- Page 13 Setze den Leuchtenkopf auf den Schaft und achte darauf, die Kabel nicht einzuklemmen. Ziehe die vier Schrauben leicht an. Place the lamp head on the shaft, taking care not to pinch the cables. Lightly tighten the four screws. Manual Team Home •...
- Page 14 Justierung. Verwende keinen Akkuschrauber. Align the luminaire head straight. Tighten the outer screws by hand using an Allen key. Tighten the inner screws only slightly, they are only used for adjustment. Do not use a cordless screwdriver. Manual Team Home •...
- Page 15 Installation Stecke den achtpoligen Stecker in die Buchse. Insert the eight-pin plug into the socket. Manual Team Home •...
- Page 16 Installation Setze die Abdeckung ein. Put the cover in place. Manual Team Home •...
-
Page 17: Demontage / Disassembly
Gehe nun genau wie bei der Montage vor, bloß in umgekehrter Reihenfolge. Gently press the lamp cover to release and pull it towards you. Now proceed in exactly the same way as for assembly, but in reverse order. Manual Team Home •... -
Page 18: Funktionen / Functions
Funktionen / Functions Smart Switch Obere Taste / Upper button • Kurzer Tastendruck: Ein / Aus • Langer Tastendruck: Dimmen • Short touch: On / Off • Long touch: Dimming Manual Team Home •... - Page 19 Short press of a button: switch between color temperature 2700K or 3500K • Long button press: Continuous color change between 2700K and 4000K Note: after switching the light off and on again, the last set color temperature and brightness is used (memory function) Manual Team Home •...
- Page 20 Manual Team Home •...
-
Page 21: Features
Features Color Tune Beam Lens Indirektes Licht / Indirect light Produziert in Deutschland / Assembled in Germany Manual Team Home •... - Page 22 Manual Team Home •...
- Page 23 Team Home direkte LED Team Home indirekte LED Grau GmbH www.grau.art • Status 07 / 2024 BR 16 1708 •...
- Page 24 Für weitere Informationen scannen Scan for more information...
