Introduction <Introduction> This software is intended to help analyze the data recordings that are stored in Fixed Protective Capsule, Float-free Capsule or Internal Storage of VDR/S-VDR installed onboard. This software chronologically plays back all the data including the radar/ECDIS image, bridge and VHF communication audios recorded in VDR/S-VDR.
Before Using <Before Using> Icons This manual and product employ various icons to enable users to use the product safety and correctly, and to prevent any harm to users or others, and to prevent damage to the property. The icons and the meanings are indicated below. Incorrect use of the equipment by ignoring this icon may cause death or a WARNING seruous injury.
Notes on Using < Notes on Using > Be careful of a computer virus. If a computer is infected with a virus, it may suffer the damage of an unusual display, a program, and data being destroyed, and may become the cause of failure. Please confirm whether it is infected with the computer virus, using a virus checker program periodically.
Page 5
Notes on Using Blank Page Playback Software / Instruction Manual...
Contents <Contents> <Introduction> ......................i <Before Using> ......................ii < Notes on Using > ....................iii Chapter1 Outline ......................1 Chapter2 Installing Playback Software ..............3 2.1 PC specification ........................... 3 2.2 How to install ............................4 2.3 How to uninstall ..........................25 Chapter3 Connecting PC to VDR/S-VDR ..............
Page 7
Contents 6.6 To set playback time .......................... 50 6.6.1 Setting playback time by Slide bar ....................50 6.6.2 Setting playback time by [Forward] button or [Rewind] button ............ 51 6.6.3 Setting playback time by [Clock] button ..................51 6.7 To change a playback speed ......................52 6.8 To adjust Volume and select audio source ..................
Page 8
Contents Chapter8 Converting Recorded Data into Industry Standard Formats ....87 8.1 Starting Conversion software ......................87 8.2 Convert all recorded data ........................88 8.3 Convert parts of recorded data ......................90 8.4 Converted file (Industry Standard Formats files) ................92 Chapter9 Trouble Shooting ..................
Chapter1 Outline Chapter1 Outline This software intends to be used for playing back recorded data required the International Standard in a Fixed Protective Capsule, a Float-free Capsule or a Internal Storage of VDR/S-VDR equipment. Record data ・Configuration data of VDR/S-VDR ・Sensor data ・Bridge audio and VHF communication ・Radar image...
Chapter2 Installing Playback Software Chapter2 Installing Playback Software 2.1 PC specification Confirm the following system requirement on your PC. Windows Vista (SP1) Windows 7 Windows 8 Core2 Duo 2GHz or Higher Windows Vista / Windows 7 Minimum 1GB Windows 8 Minimum 2GB Minimum 40GB To play back record data, HDD of 16GB/day size is required.
When the Index_E.htm in CD-ROM is clicked, the following contents Note are possible to refer in the web screen. ・ Playback software instruction manual ・ JCY-1900 VDR instruction manual ・ Basic Instruction for Downloading Data from VDR Playback Software / Instruction Manual...
Page 14
Chapter2 Installing Playback Software The Instruction of how to install on Windows Vista, Windows 7 and Note Windows 8 ・ In order to install Playback Software, always login PC as administrator, and execute the installation. ・ Run SetupE.exe in the folder by left-clicking it, then the following confirmation screen for execution displays.
Page 15
Chapter2 Installing Playback Software (3) The preparation for the installation are started. (4) The opening screen is indicated, and click [Next] button. (5) The Install Shield Wizard for the Playback software starts, and click [Next] button. Playback Software / Instruction Manual...
Page 16
Chapter2 Installing Playback Software (6) The confirmation screen where the installation folder and user information are shown is indicated, and click [Install] button. Install is started, and progress bar is indicated. (8) Visual C++ install screen is displayed. Input ✓ mark in checkbox of “I have read and accept the license terms”, and click [Install] button.
Page 17
Chapter2 Installing Playback Software (9) Complete screen of VC++ Install is displayed. Click [Finish] button. (10) The Install Shield Wizard completion screen is indicated, and click [Finish] button. (11) Please eject the Install CD-ROM from the CD drive, and keep the Installation CD-ROM carefully.
Page 18
Chapter2 Installing Playback Software ●For Windows Vista ・Click [Start] button and then click “Control Panel”. Control Panel ・Click “Security”. Security ・Click “Turn Windows Firewall on or off”. Turn Windows Firewall on or off ・Select “Off (not recommended)”, and click [OK] button. Off (not recommended) Playback Software / Instruction Manual...
Page 19
Chapter2 Installing Playback Software ●For Windows 7 and 8 ・Click [Start] button and then click “Control Panel”. Control Panel ・Click “System and Security”. System and Security ・Click “Windows Firewall”. Windows Firewall ・Click “Turn Windows Firewall on or off”. Turn Windows Firewall on or off Playback Software / Instruction Manual...
Page 20
Chapter2 Installing Playback Software ・Select “Turn off Windows Firewall (not recommended)”, and click [OK] button. Turn off Windows Firewall (not recommended) Playback Software / Instruction Manual...
Page 21
Chapter2 Installing Playback Software (13) Set power option so that your PC does not enter system standby (sleep) or hibernation while operating Playback software. ●For Windows Vista ・Click “System and Maintenance” on the Control Panel screen. System and Maintenance ・Click “Change when computer sleeps”. Change when computer sleeps ・Click “Change advanced power setting”.
Page 22
Chapter2 Installing Playback Software ・Select ”Never” for ” Plugged in” of “Hard disk”, “Sleep after”, and “Hibernate after” and click [OK] button. Hard disk Sleep after Hibernate after Playback Software / Instruction Manual...
Page 23
Chapter2 Installing Playback Software ●For Windows 7 and 8 ・Click “Hardware and Sound” on Control Panel screen. ・Click “Change when computer sleeps”. Hardware and Sound ・Click “Power Options”. Power Options ・Click “Change plan settings”. Change plan settings Playback Software / Instruction Manual...
Page 24
Chapter2 Installing Playback Software ・Click “Change advanced power settings”. Change advanced power settings ・Set “Turn off hard dick after”, ”Sleep after” and “Hibernate after” to “Plugged in Never”, click [OK] button. Turn off hard dick after Sleep after Hibernate after Playback Software / Instruction Manual...
Page 25
Chapter2 Installing Playback Software (14) For notebook or laptop PC, set as follows so that PC does not enter sleep mode when closing the lid. ●For Windows Vista ・Click “Mobile PC” on the Control Panel screen. Mobile PC ・Click “Change what closing the lid does”. Change what closing the lid does ・Select “Do nothing”...
Page 26
Chapter2 Installing Playback Software ●For Windows 7 and 8 ・Click “Hardware and Sound”. Hardware and Sound ・Click “Choose what closing the lid does”. Choose what closing the lid does ・Set “When I close the lid” to “Do nothing”, click [Save changes] button. When I close the lid [Save changes] button Playback Software / Instruction Manual...
Page 27
Chapter2 Installing Playback Software (15) If the operating system (OS) on your PC is not Japanese or English version, Playback software might not display correctly. Please set language to "English (United States)" or "English (United Kingdom)" as follows. ●For Windows Vista ・Click “Clock, Language, and Region”...
Page 28
Chapter2 Installing Playback Software ・Select “Format” tab and select “English (United States)” or “English (United Kingdom)”. Format tab English (United States) or English (United Kingdom) ・Select “Administrator” tab. Click [Change system locale] button, and select “English (United States)” or “English (United Kingdom)”, and then click [OK] button.
Page 29
Chapter2 Installing Playback Software ●For Windows 7 and 8 ・Click “Clock, Language, and Region” on Control Panel screen. Clock, Language, and Region ・Click “Regional and Language Options”. Regional and Language ・Select “Administrative” tab. Click [Change system locale] button, and select “English (United States)” or “English (United Kingdom)”, and then click [OK] button.
Page 30
(16) For Windows Vista, Windows 7 or Windows8, since Playback software has to start by the administrator user continually, set as follows. ●For Windows Vista ・Right-click the “JCY-1900 VDR Monitor” icon on desktop. ・Select “Properties”. Properties ・Select the “Compatibility” tab.
Page 31
Chapter2 Installing Playback Software ・Input “✓” mark in “Run this program as an administrator” under “Privilege Level”, and click [OK] button. Privilege Level The setup for Windows Vista PC is completed above. After installation also, always login as administrator user and use Note Playback software.
Page 32
Chapter2 Installing Playback Software ●For Windows 7 and 8 ・Right-click the “JCY-1900 VDR Monitor” icon on desktop. ・Select “Properties”. Properties ・Select “Compatibility” tab. Compatibility tab JCY-1900 VDR Playback Playback Software / Instruction Manual...
Page 33
Chapter2 Installing Playback Software ・ Input “✓” mark in “Run this program as an administrator” under “Privilege Level”, and click [OK] button. Privilege Level The setup for Windows 7 or 8 PC is completed above. After installation also, always login as administrator user and use Note Playback software.
・Click [Start] button and click “Control Panel” in Start menu. Control Panel ・Click “Uninstall a program”. Uninstall a program ・Click “JCY-1900 VDR Monitor”. JCY-1900 VDR Monitor ・Click [Yes] button. ・Since some files remain in the installation folder after completing the uninstallation, open My Computer and delete the folder.
Page 35
・Click [Start] button and click “Control Panel” in Start menu. Control Panel ・Click “Programs”. Programs ・Click “JCY-1900 VDR Playback”. JCY-1900 VDR Playback ・Click [Yes] button. [Yes] button ・Since some files remain in the installation folder after completing the uninstallation, open My Computer and delete the folder.
Chapter3 Connecting PC to VDR Chapter3 Connecting PC to VDR/S-VDR (1) Open the door with key, and connect a LAN cable to the” DATA” port of VDR/S-VDR. Data port Playback Software / Instruction Manual...
Page 37
Chapter3 Connecting PC to VDR Blank Page Playback Software / Instruction Manual...
Chapter4 Downloading Recorded Data from VDR/S-VDR 4.1 Downloading Recorded Data from VDR/S-VDR by Download Software (1) Click the JCY-1900 VDR Monitor icon on the desktop. The icon is created automatically after installation. (2) Click [DOWNLOAD] button from “VDR INVESTIGATIVE SOFTWARE” launcher menu, and start the download software.
Page 39
Chapter4 Downloading Recorded Data from VDR/S-VDR (4) Select a storage media (Data Source) for downloading the recorded data. • Internal Storage ← Recorded data in the Built-in medium • Float-free Capsule ← Recorded data in the Float-free Capsule • Fixed Protective Capsule ←...
Page 40
Chapter4 Downloading Recorded Data from VDR/S-VDR (6) Set download value with the slide bar. Setup method differs by selection of “Data Source”. ●In case of “Internal Storage”, “Float-free Capsule” or “Fixed Protective Capsule” Download data period can be specified in date/time. In downloading all recorded data, enter a check mark into a check box of "All".
Page 41
Chapter4 Downloading Recorded Data from VDR/S-VDR (7) In case of the “Internal Storage”, select data in the Download Data Selection screen. Internal Storage can save accident recording data before and after Note outbreak of 3 hours to three times separately from normal recorded data.
Chapter4 Downloading Recorded Data from VDR/S-VDR (9) When download starts, download progresses of recorded data are shown by progress bar. (10) If the following screen is indicated, download is completed. Click [OK] button, and close the download software. 4.2 Copying Recorded Data to USB Memory from VDR/S-VDR The preserved data by the protected operation and the recorded data in the Internal Storage can copy to the USB memory for up to 6 hours.
Page 43
Chapter4 Downloading Recorded Data from VDR/S-VDR (2) Remove the OPU’s USB port cover, and insert a USB memory into the USB port. USB port Note Use the USB memory which formatted in the FAT32. The storage capacities can use up to 32GB. (3) Tap the [Select] button in the Data Copy screen.
Page 44
Chapter4 Downloading Recorded Data from VDR/S-VDR (4) Tap the [Select] button in the Data Select screen and select from the drop-down listthe recorded data that would like to copy. Selecting the Recorded Data Selectable Recorded Data Data Name Description Latest data The latest recorded data for 6 hours that is recorded in the internal storage.
Page 45
Chapter4 Downloading Recorded Data from VDR/S-VDR (5) If [Latest data] is selected, change the date and time of recorded data that would like to copy by the button shown the following figure. The date and time of recorded data that would like to copy Setting the date and time of recorded data The button in the Data Select screen Button...
Page 46
Chapter4 Downloading Recorded Data from VDR/S-VDR (6) Tap the [Set] button in the Data Select screen. Return to the Data Copy screen and displays the date and time that would like to copy in the [Period] field. Data Select screen Data Copy screen (7) Select the item that would like to copy in the Data Copy screen.
Page 47
Chapter4 Downloading Recorded Data from VDR/S-VDR (8) Tap the [Copy] button in the Data Copy screen, then starts copying. If the data starts to be copied, the progress bar is displayed. During copying the[Copy] button turns into the [Cancel] button. Tapping the [Cancel] button stops a copy. Data Copy screen It takes about 30 minutes to copy the recorded data for 6 hours.
Chapter4 Downloading Recorded Data from VDR/S-VDR 4.3 Folder Composition Location to save (e.g. Desktop) Save folder (e.g. YYYYMMDDhhmmss: year/month/day/hour/minute/second) Internal_Storage *1 audio event init test visual Float-free_Capsule *1 audio event init test visual Fixed_Protective_Capsule *1 audio event init test visual *1: The folder of the downloaded media is created, but the folder of the media which is not downloaded is not created.
Page 49
Chapter4 Downloading Recorded Data from VDR/S-VDR Blank Page Playback Software / Instruction Manual...
Chapter5 Setup for Playback Software Chapter5 Setup for Playback Software In order to start Playback software, Setup is required. When Playback software is started and the following warning screen is indicated, setup is not completed. Refer to “Chapter 8 for Converting Recorded Data into Industry Standard Formats”. The Conversion software can convert recorded data in the Internal Storage and the Capsules into Industry Standard Formats.
Page 51
Chapter5 Setup for Playback Software The Login screen is indicated, and click [OK] button after confirming that “User” is selected in the Operator block. User (4) The Setup for User screen is indicated. Click [Import] button. [Import] button Playback Software / Instruction Manual...
Page 52
Chapter5 Setup for Playback Software (5) As “Open” screen displays, select and open SysInfo.dat (VDR composition information) file, that is VDR/S-VDR recorded data downloaded at Section 4.1. The vdrInfo.dat file is downloaded in the following location. *\YYYYMMDDhhmmss\Data Source\init\vdrInfo.dat The name of data source (Internal_Storage, Float-free_Capsule Download folder or Fixed_Protected_Capsule)
Page 53
Chapter5 Setup for Playback Software (8) Click [Folder Selection] button, and select a folder specified with the clause 4.1(4) of Chapter 4. Folder Selection button When playing back download data, select the media folder ( Internal Storage, Float-free Capsule or Fixed Protective Capsule) (9) Click [Set] button, and setup is completed.
Chapter6 Playback Operation 6.2 How to exit the Playback software (1) Click [Setup] button of bottom right in the playback screen and the Setup screen is indicated. [Setup] button (2) Click [Exit] button of bottom left in the Setup screen. [Exit] button (3) Click [OK] button in the Confirm window.
Chapter6 Playback Operation 6.3 Playback screen The Playback screen is composed with Main Block, Status Block, Playback Operation Panel and Menu Block. Main Block Menu Block Status Block Playback Operation Panel Playback Software / Instruction Manual...
Page 57
Chapter6 Playback Operation The Playback screen has Voyage screen, Alarm/Status screen, AIS screen and Radar/ECDIS screen on the Main Block, and their screens are selected with buttons of the Menu Block. AIS screen does not display when AIS is not connected to VDR/S-VDR Voyage Alarm/Status Menu Block...
Chapter6 Playback Operation 6.4 Playback Operation Panel Shows the function of buttons and sections. ① ② ③ ⑩ ④ ⑪ ⑤ ⑫ ⑥ ⑦ ⑧ ⑨ Name Function ① OLDEST time Show the oldest time of the recorded data. ② LATEST time Show the latest time of the recorded data.
Chapter6 Playback Operation 6.5 To start playback, and to stop To start playback, click [Playback] button. And to stop playback, click [Stop] button. Stop Playback 6.6 To set playback time Explain how to set playback time. 6.6.1 Setting playback time by Slide bar If knob is slid, a playback time is forwarded or reversed according to the position.
Chapter6 Playback Operation 6.6.2 Setting playback time by [Forward] button or [Rewind] button If [Forward] button is pressed, a playback time is forwarded. And the step time is increased by pressing the button continuously. If [Rewind] button is pressed, a playback time is reversed. And step time is increased by pressing the button continuously.
Chapter6 Playback Operation (4) Selected date is indicated in the Playback time Slide bar select button Playback time (5) Click [Playback] button. (If playback is in progress, playback is restarted automatically without clicking [Playback] button.) If 12 hours of slide bar select button is set, time span is 12 hours after Note selected playback time.
Chapter6 Playback Operation 6.8 To adjust Volume and select audio source If [Speaker] button is clicked, the Volume control screen appears. Speaker To adjust volume, slide up or down the volume knob. If exclude an unnecessary audio source, click the source and remove the “✓” mark. Moreover if the All mute is clicked and enter the “✓”...
Chapter6 Playback Operation 6.9 Voyage screen There are the Graphic screen and the Numeric screen in the Voyage screen. To change the screens, click [Voyage] button in the Menu block. Graphic screen Numeric screen Voyage Playback Software / Instruction Manual...
Chapter6 Playback Operation 6.9.1 Graphic screen The following explains Graphic screen. “*” mark displays when data in numeric indication are not recorded. “N.C” displays when the input equipment is not connected. Moreover, it becomes an invalid indication when all the items in the divided block have not been connected.
Page 65
Chapter6 Playback Operation 6.9.1.2 Rudder direction and heading block This block shows heading against rudder direction by graphic. The following figure is an example in case there is one rudder. The green line shows rudder. And the blue line shows heading by Gyro. Rudder direction Heading 6.9.1.3 Heading block...
Page 66
Chapter6 Playback Operation 6.9.1.4 Ship block (Voyage screen) This block shows status of propeller, rudder and speed by numeric and graphic under voyage. The following figure is an example in case there are 1 propeller and 1 rudder. If [Voyage/Docking] button is clicked, the Ship block is switched to the Docking screen. Refer to “6.9.1.5 Ship block (Docking screen)”...
Page 67
Chapter6 Playback Operation 6.9.1.5 Ship block (Docking screen) This block shows status of propeller, rudder, speed and thruster by numeric and graphic under docking. The following figure is an example in case there are 1 propeller, 1 rudders and 1 thruster. If [Voyage/Docking] button is clicked, the Ship block is switched to the Voyage screen.
Page 68
Chapter6 Playback Operation 6.9.1.6 Voyage Info block This block shows date, time, own ship’s position etc. by numeric. Playback Software / Instruction Manual...
Page 69
Chapter6 Playback Operation 6.9.1.7 Depth block This block shows Depth by numeric and graphic. The brown zone is seabed, and the light-blue zone is underwater. A horizontal axis shows lapsed time and shows the depth of water of the newest at right end.
Chapter6 Playback Operation 6.9.2 Numeric screen There are two numeric screens as follows. In numeric screen, all data of graphic screen are showed in numeric. “*“ mark displays if data in numeric indication have not yet received or illegal data are inputted, “N.C”...
Chapter6 Playback Operation 6.10 Alarm/Status screen The Alarm/Status screen shows alarm information, status of engine telegraph, door status, water level and fire detection etc. This screen is composed 3 blocks of Alarm/Status, Category Menu and Alarm/Status Menu. To show door status e.g., click [Door] button from the Alarm/Status Menu. Moreover, to show about Steering gear e.g., click the Steering gear from the Category Menu.
Chapter6 Playback Operation 6.11 Radar/ECDIS screen It is possible to view Radar and ECDIS images captured every 15 seconds in this screen. It is prepared so that the icon and the menubar may effectively view the screens. It is possible to view maximum 6 images as follows. ・No.1 and No.2 X-Band RADAR ・No.1 and No.2 S-Band RADAR ・No.1 and No.2 ECDIS...
Chapter6 Playback Operation 6.11.1 Icon Shows the function of buttons below. ① ⑤ ② ⑥ ③ ⑦ ⑧ ④ Name Function ① Zoom Out Available to contract a selected screen. ② Zoom In Available to expand a selected screen. ③ Rotation Available to rotate a selected screen.
Chapter6 Playback Operation 6.11.2 Menu bar Shows the composition of the menu bar below. The functions are same as icons of “6.11.1 Icon”. File Window Zoom Out Tile Zoom In Cascade Rotation Print Close Playback Software / Instruction Manual...
Chapter6 Playback Operation 6.12 AIS Screen There are the Graphic screen and List screen in the AIS screen. To select the screens, click [Graphic] button or [List] button. And simple information of own ship and AIS targets is indicated on right side. Graphic screen Simple Information...
Chapter6 Playback Operation 6.12.1 Graphic screen Centering on own ship, the state of AIS target is indicated on graphics by a symbol. Screen area is expanded or contracted by Range button. (Radius: from 0.75 to 24 nm) Range button Playback Software / Instruction Manual...
Page 77
Chapter6 Playback Operation Explains about symbols in the following table. Category Symbol Explain ・Solid line shows heading. Own ship ・ Dashed line shows COG(Course Over Ground). ・Solid line shows heading. AIS Target ・ Dashed line shows COG(Course Over Ground). If position report of a ship is not received more than a certain time, the symbol is indicated.
Chapter6 Playback Operation 6.12.2 List screen Position report, ship's name, IMO number, call sign and length of hull etc are showed in this screen. It is indicated on near order from a top from own ship. Playback Software / Instruction Manual...
Chapter6 Playback Operation 6.12.3 Detail Information of own ship If [Detail] button in the simple information block, the detail screen is indicated. Playback Software / Instruction Manual...
Chapter6 Playback Operation 6.12.4 Detail information of AIS target If [Detail] button in the simple information block, the detail screen is indicated. Playback Software / Instruction Manual...
Chapter6 Playback Operation 6.13 To confirm the record sentences in the NMEA format Available to confirm the record sentences in the NMEA format on the Dump screen. To open the Dump screen, operate as follows. (1) Click [Setup] button in the Menu Block. [Setup] button (2) Select the Maintenance tab in the setup and click [View] button.
Chapter6 Playback Operation (4) Click [Start] button. To abort view, click [Stop] button. Shows the function of buttons below. ④ ③ ② ① ⑤ ⑥ Name Function ① Port No. Available to select a certain channel or all channels. ② Start Available to start view.
Chapter6 Playback Operation 6.15 To confirm the VDR system information Available to confirm the VDR system configuration that is required in the International Standard on the VDR System Information screen. To open the VDR System Information screen, operate as follows. (1) Click [Setup] button in the Menu Block and select the Version tab.
Page 84
Chapter6 Playback Operation (3) The VDR System Information screen is opened. Shows the function of buttons below. ① ② Name Function ① Available to show the RCU system information on the screen. ② Close Available to close the screen. Playback Software / Instruction Manual...
Chapter6 Playback Operation 6.16 How to customize screen layout It is possible to move, expand and reduce the Voyag1 and Voyage2 screens. And when [Setup] button is clicked, setting tabs of each block are indicated, and if a check mark of "Dialog"...
Page 86
Chapter6 Playback Operation (2/4) Corresponding Block Note Ship (Docking) ・It is possible to display maximum 6 Radar windows in the Radar screen. Current / Wind Voyage Info Playback Software / Instruction Manual...
Page 87
Chapter6 Playback Operation (3/4) Corresponding Block Note ・It is possible to change a graph range Depth Graph in addition to selection of visible and invisible. ・It is possible to select “KEEL” mode or “WATER/TRANS/KEEL” mode. ・ Initially this block is not shown. If Engine Graph needed, change the dialog.
Page 88
Chapter6 Playback Operation (4/4) Corresponding Block Note ・It is possible to change AIS target number and range in the AIS screen. ・It is possible to select blue or black for background System color. Default background color is blue. Background: Blue (Default) Background: Black Playback Software / Instruction Manual...
Chapter6 Playback Operation 6.17 How to restore to initial screen layout It is possible to restore to initial screen layout by [Restore] button in the Maintenance tab. If the Voyage1 screen is restored, click [Restore] button after opening the Voyage1 screen. If the Voyage2 screen is restored, click [Restore] button on the Voyage2 screen.
Chapter7 Optional Function Chapter7 Optional Function As optional function, by making LAN connection with VDR/S-VDR, real time display and record for long term are available as Real Time Monitor. Shows the operation below. Note If you require real time display, output setup of VDR/S-VDR is necessary by our service engineer.
Page 91
Chapter7 Optional Function (3) Select User, and click [OK] button. (4) Select one from 4 modes in the “For” of the Setup Folder block. Mode Mode1:Live Mode2:Playback Mode3:Live / Playback Mode4:Live / Playback / Record Playback Software / Instruction Manual...
Page 92
Chapter7 Optional Function (5) Select the folders In case of selecting except mode1, select the playback folder. Moreover in case of mode 4, set the Record Folder, the Record Period and the Overwrite. Playback Folder Record Folder Record Period Overwrite (6) Click [Set] button, and close the Setup software with [Close] button.
Chapter7 Optional Function 7.2. Alternating to real time display (1) Check that the “LIVE” of the Status block lights out. If the “LIVE” lights up yellow, it is already becoming a real time display, so that the following operation is not necessary. (2) Click [Live/Play] button in the Menu block.
Chapter7 Optional Function 7.3. Record start (1) Click [Backup] button in the Menu block. [Backup] button (2) Since displays record folder and free space of HDD, click [REC] button after check. [REC] button (3) The ”REC” in the Status block lights up, and starts record. The record by the Real Time Monitor records data from VDR/S-VDR by Note UDP protocol.
Chapter7 Optional Function 7.4. Record stop or pause (1) Click [Backup] button in the Menu block. [Backup] button (2) When record is stopped, click [STOP] button. When record is paused, click [PAUSE] button. [STOP] button (3) The “REC” lights out, and record is stopped or paused. (4) The recorded data can be played back in the playback mode by clicking [Live/Play] of the Menu block.
Chapter8 Converting Recorded Data into Industry Standard Formats Chapter8 Converting Recorded Data into Industry Standard Formats 8.1 Starting Conversion software (1) Click [CONVERT] button, so that conversion software starts up. [CONVERT] button (2) Conversion software screen displays. (3) Method for conversion Refer to Section 7.2, when converting all recorded data.
Chapter8 Converting Recorded Data into Industry Standard Formats 8.2 Convert all recorded data (1) Click Folder Selection button in the “Source Folder,” and select “Data Source” folder in the folder that recorded data are saved. *\YYYYMMDDhhmmss\”Data Source” The name of data source (Internal Storage, Float-free Capsule Recorded data folder or Fixed Protective Capsule)
Page 98
Chapter8 Converting Recorded Data into Industry Standard Formats (3) Click Folder Selection button in “Convert Folder”, and select “Convert_Data” folder as the destination of converted files. [Folder Selection] button Select the “*\Convert Data” on desktop. (4) Click [Convert]. When conversion starts, progress of conversion is indicated in progress bar. Also, converted files are indicated in list box.
Chapter8 Converting Recorded Data into Industry Standard Formats (5) Stop converting Click [Cancel] button in order to stop converting. 8.3 Convert parts of recorded data (1) Click Folder Selection button in “Convert Folder”, and select “Convert Data” folder as the destination of converted files.
Page 100
Chapter8 Converting Recorded Data into Industry Standard Formats Drag & Drop Note When OS is after Windows Vista, to use the “drag & drop” operation cancel UAC (User Account Control). Playback Software / Instruction Manual...
Chapter8 Converting Recorded Data into Industry Standard Formats 8.4 Converted file (Industry Standard Formats files) The Convert software creates the converted files as follows. Data File Name Note Configuration Information YYMMDD,hhmmss,CF,????????.csv Digital Sensor Data YYMMDD,hhmmss,DD,????????.txt Audio YYMMDD,hhmmss,A1,????????.wav Mix MIC-CH1 and CH2, YYMMDD,hhmmss,A2,????????.wav Mix MIC CH3 and CH4 YYMMDD,hhmmss,A3,????????.wav...
Chapter9 Trouble Shooting Chapter9 Trouble Shooting If the Playback software may be not normal or occur a error, please confirm the contents of this chapter before contact us Symptom Cause Action Download from Faulty wiring of LAN cable. Check the connections. VDR/S-VDR is not possible.
Chapter10 Appendix Chapter10 Appendix 10.1 How to stop recording data ・Follow the directions of the relevant authorities as to whether to stop or Note restart the data recording. ・If the data recording is stopped, the recording to the Fixed Protective Capsule, the Float-free Capsule, and the Internal Storage stops.
Chapter10 Appendix 10.2 How to preserve recording data Operate the OPU as follow. 10.2.1 Preserving (1) Push [SAVE] button to display the “Guide for saving recorded data at marine accident” screen. (2) Push [RECORD STOP/START] button to display the “Password” input screen. No Al er t Al er t Copy...
Page 106
Chapter10 Appendix (4) Push [▼] button to select save area. Select the Save area from Save1, 2 and 3. Home > Save > Pr ot ect Dat e and t ime of accident : 1 8 FEB 2 0 1 3 1 9 FEB 0 0 : 0 0 0 6 : 0 0 1 2 : 0 0 1 8 : 0 0 0 0 : 0 0 0 6 : Day-...
Chapter10 Appendix 10.3 Sentence and indication place (1/4) Screen Block Section Data Indication Unit Sentence Voyage1 Wind True Wind Direction xxx.x deg(°) $xxMWV Voyage2 Wind Speed xx.x kts, m/s (Graphic) Relative Wind Direction xxx.x deg(°) Wind Speed xx.x kts, m/s Rudder direction Rudder Starboard...
Page 108
Chapter10 Appendix (2/4) Screen Block Section Data Indication Unit Sentence Voyage1 Engine Telegraph Telegraph Position STOP ENGINE e.g. $xxETL Voyage2 SUB Telegraph S/B, F/A, F/E e.g. (Graphic) Ope.Location Bridge, Port wing, Starboard wing e.g. Propeller Cont. Single, Starboard, Wing e.g. Voyage Info DD/MM/YYYY $xxZDA...
Page 109
Chapter10 Appendix (3/4) Screen Block Section Data Indication Unit Sentence VDR1 Depth Offset from transducer Depth(Water/Tran./ $xxDPT (Numeric) Keel) Depth xxx.x Heading True xxx.x deg(°) $xxHDT Rudder order Automatic Order xxx.x deg(°) $xxHTC and response Response xxx.x deg(°) $xxHTD Manual Location Bridge, Port wing, $xxROR...
Page 110
Chapter10 Appendix (4/4) Screen Block Section Data Indication Unit Sentence VDR2 Speed Water Log1/Log2 STW (Water-reference) [AS/AH]xx.x $xxVBW (Numeric) and Ground SOG (Ground-reference) [AS/AH]xx.x Bow (The left and right [P/S]xx.x in bow) Stern (The left and right [P/S]xx.x in stern) SOG (Ground-reference) [AS/AH]xx.x $xxVTG...
