- Page 1 INSTRUCTION MANUAL ModBlox 4” x 1” Slat Wall Kit 30 Minute Approximate Build Time 2 People Recommended For Assembly ModBlox — a modular revolution for your garden space! www.ModBlox.co.uk...
-
Page 2: General Information
(if appropriate) for access. Assembling your ModBlox Privacy Slat Wall is fun and easy, even for novices with little or no building experience. Assembly with a friend can be done in as little as an half an hour. -
Page 3: Kit Contents
KIT CONTENTS 4” x 1” Treated Round 25mm ModBlox™ 2” x 1” Treated Round Edge Timber U Channel Edge Timber Wood Screws 16mm ModBlox™ Wood Screws 3" x 8g U Channel Fixing Screws 1½" x 8g www.ModBlox.co.uk... - Page 4 Channel. We recommend lining the top of the U Channel with the bottom of your ModBlox™ fitting as shown on the right. The lower U Channel should be fixed directly below the bottom of the upper U Channel and fixed into position in the same way, using two of the 3"...
- Page 5 With your U Channels fixed to the post, the next step is to start slotting in your timber slats and fixing into place using the 16mm ModBlox™ U Channel Fixing Screws, 2 per slat, per side, screwed into the hole nearest the edge of the slat timber.
