- Page 1 INSTRUCTION MANUAL ModBlox Apex ™ 1 Hour Approximate Build Time 3 People Recommended For Assembly ModBlox — a modular revolution for your garden space! www.ModBlox.co.uk...
-
Page 2: General Information
(if appropriate) for access. Assembling your ModBlox pergola is fun and easy, even for novices with little or no building experience. Assembly with a friend can be done in as little as an hour (longer if your pergola includes roof rafters and/or a privacy wall). You won't need any speciality tools, either... -
Page 3: Kit Contents
KIT CONTENTS 2 x ModBlox™ 2 x ModBlox™ 2 x ModBlox™ Corner Angled Corner Angled Apex TriSleeves QuadSleeve (Right) QuadSleeve (Left) 9 x Roof ModPost™ 88 x 40mm Fixing 1 x 8mm Hex Head (92mm x 92mm) Screws with Caps Driver Bit 4 x Corner ModPost™... - Page 4 ModBlox™ Apex MEASUREMENTS Pegola Name ModBlox™ Apex Pergola (2400mm x 2400mm) 2400mm 1180mm 2100mm 3115mm ModBlox™ Apex Pergola (2400mm x 3600mm) 2400mm 1180mm 2100mm 3115mm ModBlox™ Apex Pergola (3000mm x 3000mm) 3000mm 1530mm 2100mm 3115mm ModBlox™ Apex Pergola (3600mm x 3600mm)
-
Page 5: Step 1 - Roof Assembly
Fig 6 (next page) for reference. Fig. 2 Once this is done you can then insert 2 of the apex posts (shorter ModPosts) into the angled part of the bracket. At this stage we do not recommend fixing these in place as it will allow for some movement when the whole roof is together in order to ensure everything is square. - Page 6 Each ModSleeve in your kit includes 40mm fixing screws and caps, see the screw diagram to the right to see which holes the screws should go in. (Additional holes are for attaching accessories.) www.ModBlox.co.uk...
- Page 7 The further the spike is into the ground the harder it will be to realign, so check the level frequently as you go deeper. The spike can then be tightened to the post using the 2 bolts on the side which locks it into its final position. www.ModBlox.co.uk...
