- Page 1 INSTRUCTION MANUAL ModBlox CUBE 1 Hour Approximate Build Time ModBlox — a modular revolution for your garden space! www.ModBlox.co.uk...
-
Page 2: General Information
(if appropriate) for access. Assembling your ModBlox pergola is fun and easy, even for novices with little or no building experience. Assembly with a friend can be done in as little as an hour (longer if your pergola includes roof rafters and/or a privacy wall). You won't need any speciality tools, either... -
Page 3: Kit Contents
KIT CONTENTS 4 x ModBlox 3Way Brackets 4 x Roof Beams (92mm x 92mm) 4 x Corner Posts (92mm x 92mm) 40mm Fixing Screws with Caps 8mm Hex Head Driver Bit www.ModBlox.co.uk... -
Page 4: Step 1 - Roof Assembly
1 or 2 helpers, and slide into position the corner posts into both 3way brackets on that side until they hit the top of the brackets. Secure the posts to the 3way brackets using the provided 40mm fixing screws and finish with the screw caps. www.ModBlox.co.uk... - Page 5 Each 3way post bracket in your kit includes 12 40mm fixing screws and caps. See the screw diagram to the right to see which 12 holes the screws should go in. (Additional holes are for attaching accessories.) CORNER VIEW www.ModBlox.co.uk...
- Page 6 The further the spike is into the ground the harder it will be to realign, so check the level frequently as you go deeper. The spike can then be tightened to the post using the 2 bolts on the side which locks it into its final position. www.ModBlox.co.uk...
- Page 7 With all your rafter built it is then just a matter of placing them into position, equally spaced, approx. 400-500mm depending on the size of your pergola and fixing to the main frame using another two 40mm Fixing Screws. The final step is to cover your screws with the provided caps to create a sleek modern finish. www.ModBlox.co.uk...
