- Page 1 INSTRUCTION MANUAL ModBlox Hex / Hex Wide 30 Minute Approximate Build Time 3 People Recommended For Assembly ModBlox — a modular revolution for your garden space! www.ModBlox.co.uk...
-
Page 2: General Information
(if appropriate) for access. Assembling your ModBlox pergola is fun and easy, even for novices with little or no building experience. Assembly with a friend can be done in as little as an hour (longer if your pergola includes roof rafters and/or a privacy wall). You won't need any speciality tools, either... -
Page 3: Kit Contents
KIT CONTENTS 6 x ModBlox 6 x Roof Beams 3Way 30⁰ Brackets (92mm x 92mm) 6 x Upright Posts (92mm x 92mm) 72 x 40mm Fixing 1 x 8mm Hex Head Screws with Caps Driver Bit www.ModBlox.co.uk... - Page 4 Before beginning measure 180mm from each end of our posts and mark them with a pencil, this is how much of the posts need to be inserted into the ModBlox fitting to ensure everything stays equal on each side. Hex Wide...
- Page 5 This will allow you to then have two brackets that are parallel when sliding together to complete the frame rather than at an angle which may make it difficult to insert the timber. All ModBlox fittings are to be secured in place using 4 x 40mm Fixing Screws, 2 on each side of the fitting, see image below for reference.
- Page 6 Each Apex TriSleeve bracket in your kit includes 12 x 40mm fixing screws and caps. See the screw diagram to the right to see which 12 holes the screws should go in. CORNER VIEW (Additional holes are for attaching accessories.) www.ModBlox.co.uk...
- Page 7 Bolt down anchors are the ideal to secure your posts onto a concrete base, brick wall, or other hard flat surfaces such as decking. We recommend using a Hex Head M8 x 60mm Thunderbolts or similar (sold separately). Simply line up your anchor in your chosen final position that drill a hole using the correct masonry drill bit, remove the dust and debris and wind in until fastened down tight.
