hot-steam T Series Operating Manual

Hide thumbs

page of 10

/ 10
Bookmarks

Quick Links

Download this manual

HÖT-STEAM

Premium Industrial Steam Iron

Operating Manual

IMPORTANT

• Please read this owner's manual thoroughly before

installing and operating your iron.

• Please retain this owner's manual for future reference

after reading it thoroughly.

Series

- All Steam Iron -



Model No

. T2, T3, T4, T6

Ver.231121

Need help?

Do you have a question about the T Series and is the answer not in the manual?

Questions and answers

Summary of Contents for hot-steam T Series

Page 1 HÖT-STEAM ® Premium Industrial Steam Iron Operating Manual Series - All Steam Iron -  . T2, T3, T4, T6 Model No IMPORTANT • Please read this owner’s manual thoroughly before installing and operating your iron. • Please retain this owner’s manual for future reference after reading it thoroughly.
Page 2 OPERATING MANUAL Series - Model No. T2, T3, T4 & T6 HÖT-STEAM ® • ® T Series All-Steam Iron. This iron HÖT-STEAM Thank you for purchasing the  requires a steam generator or boiler as a steam source to operate. Please read this instruction manual carefully before using the iron to ensure its longest possible life.
Page 3 OPERATING MANUAL Series - Model No. T2, T3, T4 & T6 HÖT-STEAM ® • 2. Connect the second hose to the returning line of the boiler and the other end of the hose to the iron exhaust valve (Part# TEVC). (Fig.2) Read the next step before tightening.
Page 4 OPERATING MANUAL Series - Model No. T2, T3, T4 & T6 HÖT-STEAM ® • ⚠ IMPORTANT ❖ After installing the hoses, verify each hose connection. If water starts leaking out of the iron base when pressing on the push lever, the hoses were reversed.
Page 5 OPERATING MANUAL Series - Model No. T2, T3, T4 & T6 HÖT-STEAM ® • C. ADJUSTING STEAM VOLUME ➢ With a flat head screwdriver hold the ‘Adjusting Screw’ located at the center of the ‘Cap Nut’ of the ‘Lever Bracket’ (Part# T8600-1). ➢...
Page 6 OPERATING MANUAL Series - Model No. T2, T3, T4 & T6 HÖT-STEAM ® • E. TROUBLESHOOTING The iron is not releasing any steam or the iron is not heating up • Verify the boiler has heated thoroughly. • Verify the steam supply line is open and if enough pressure is running in the system.
Page 7 OPERATING MANUAL Series - Model No. T2, T3, T4 & T6 HÖT-STEAM ® • The iron is leaking steam from near the Push Lever • There may be debris/dirt stuck in the Steam Valve. ➢ Remove the ‘Push Lever’ and ‘Lever Bracket’, then remove the Steam Valve.
Page 8 OPERATING MANUAL Series - Model No. T2, T3, T4 & T6 HÖT-STEAM ® • PARTS BREAK DOWN T8600-1 TS007-1 TSVC THNC TEVC TS008 T7252 TS013...
Page 9 OPERATING MANUAL Series - Model No. T2, T3, T4 & T6 HÖT-STEAM ® • PARTS LIST Part No. Name Description • Handle Tip Screw TS007-1 Handle Assembly • Handle Tip • Handle Nut • Handle • Lever Clamp T8600-1 Lever Bracket •...
Page 10 Limited Warranty ® HÖT-STEAM All-Steam Iron is tested and inspected before leaving our factory. We warrant to the original user of this product that it will be free from defects in material and workmanship for 12 Months from the date of purchase. With respect to non-durable parts that normally require replacement within a year, including hoses, and valve discs that can wear down to normal wear and tear there is a limited warranty of 90...

This manual is also suitable for:

T2 T3 T4 T6
