- Page 1 Please read this Operating Manual thoroughly before installing and operating your iron. Please retain this Operating Manual for future reference. Languages English 한국어 Spanish...
-
Page 2: Table Of Contents
OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 “ Thank you for purchasing the “ Thank you for purchasing the HÖT-STEAM® SGB HÖT-STEAM® SGB Series Series Gravity-Fed Iron ”. Gravity-Fed Iron ”. The HÖT-STEAM® SGB Series Gravity-Fed Iron... -
Page 3: Installation
OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 A. INSTALLATION 1. Before setting up new iron, find a secure place where the tank can be stationed at least 3 Feet (1 Meter) above the iron. 2. Verify the WATER CONTROL VALVE of the WATER TANK is closed. - Page 4 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 [NAME OF THE PARTS] Water Tank Demineralizer Strainer Mesh Filter Water Control Valve Silicon Hose 1 Meter (3 Feet) Power Cord Spring Heat Indicator Light Solenoid Valve Thumb Switch...
-
Page 5: Operation & Use
OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 B. OPERATION & USE Turn the knob counterclockwise to open the WATER CONTROL VALVE. (* Caution: Use finger pressure when turning the knob) Plug in the POWER CORD and turn on the POWER SWITCH upward. -
Page 6: Troubleshooting
OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 [Safety Instructions] • Place the iron on the iron rest always when not in use. • Do not place the iron on its back. It may cause injury to the operator. - Page 7 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 5. Check if the steam orifices on the base are clogged. Clean them using the CLEAN- ING PIN (Included in the Maintenance Kit). 6. While the power is on, you should hear a “clack” from the SOLENOID VALVE whenever the STEAM BUTTON is pressed.
-
Page 8: Maintenance
OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 Problem: The Power is ON but the HEATING INDICATOR LIGHT OFF and the iron does not heat. “ ” = Solution: You may have 2 different situations. 1. There is no Clack of SOLENOID VALVE when you press STEAM BUTTON. - Page 9 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 “ HÖT-STEAM® SGB “ HÖT-STEAM® SGB Series Series 물통 다리미를 구입해 주셔서 ” ” 감사드립니다 . 이 다리미는 스팀 전기 다리미로서 보일러 없이 사용하실 수 있는 다리미입니다. 다리미 사용 전에 이 사용설명서를 주의 깊게 읽어 보신 후...
- Page 10 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 A. 설치 다리미를 설치하시기 전에, 다리미로부터 약 3 FEET (1 METER) 이상 높은 곳에WATER TANK를 걸어 놓을 안전한 곳을 정하세요. 플라스틱 물통(WATER TANK)의 아래에 달려있는 WATER CONTROL VALVE가 잠겨 있는지 확인하시고, DEMINERALIZER (1 BAG)을...
- Page 11 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 [NAME OF THE PARTS] Water Tank Demineralizer Strainer Water Control Valve Silicon Hose 1 Meter (3 Feet) Power Cord Spring Heating Indicator Light Solenoid Valve Thumb Button Temperature Dial Power Switch [RESIN FILTER (DEMINERALIZER) 사용법]...
- Page 12 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 B. 사용 방법 물통에 달린 WATER CONTROL VALVE를 시계 반대방향으로 돌려서 밸브를 “OPEN” 상태로 만드세요. (*주의: 손가락 힘으로만 돌리시기 바랍니다.) 전원코드를 전기 아울렛에 꽂으시고, POWER SWITCH를 위쪽으로 눌러서 스위치...
- Page 13 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 [안전 수칙] 다리미 사용이 끝난 후에는 다리미를 항상 IRON REST 위에 얹어 놓으세요. » » 다리미를 뒤로 세워 놓지 마세요. 사람이 다칠 위험이 있습니다. 다리미 사용이 끝나면 WATER CONTROL VALVE 를 잠그고, 전원코드를 뽑아 놓으세요.
- Page 14 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 다리미 밑바닥의 스팀 홀이 막혀 있다면 Maintenance Kit에 포함된 CLEANING PIN으로 청소하세요 다리미에 전원이 켜진 상태에서STEAM BUTTON을 눌렀을 때, SOLENOID VALVE에서 ‘딸깍’ 하는 소리가 나야 합니다. 이 소리가 들리지 않는다면, SOLENOID VALVE 맨 위쪽의 두꺼운 넛트(COVER NUT)를...
- Page 15 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 문제: POWER SWITCH 를 켰으나 불이 들어오지 않고 다리미가 뜨거워지지 않는 경우 = 해결: 이 문제는 두가지의 경우로 나누어서 문제를 해결해야 합니다. 1. STEAM BUTTON을 눌렀을 때 SOLENOID VALVE에서 ‘딸깍’ 하는 소리가 나지 않는 경우...
- Page 16 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 “ Gracias por adquirir la “ Gracias por adquirir la Plancha de Gravedad Plancha de Gravedad HÖT-STEAM® SerienSGB.” HÖT-STEAM® SerienSGB.” La Plancha de Gravedad HÖT-STEAM® Serie SGB es una plancha eléctrica...
- Page 17 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 INSTALACIÓN 1. Antes de comenzar la instalación, buscar un lugar fijo y es- table en donde pueda colgarse el tanque a 1 metro de alto como mínimo sobre el nivel de la plancha.
- Page 18 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 [NAME OF THE PARTS] Water Tank Demineralizer Strainer Water Control Valve Silicon Hose 1 Meter (3 Feet) Power Cord Spring Heating Indicator Light Solenoid Valve Thumb Button Temperature Dial...
- Page 19 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 B. OPERACIÓN & USO 1. Abrir la VÁLVULA DE AGUA en el tanque hacia la izquierda. (* Precaución: La válvula girará con tan solo utilizar la presión de los dedos).
- Page 20 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 [Instrucciones de Seguridad] • Asegurarse siempre de colocar la plancha sobre el Reposador. • No asentar la plancha verticalmente, pueda que cause daños al operador. • Luego de su uso, asegurarse de cerrar la Válvula de Agua del tanque.
- Page 21 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 5. Verificar si los orificios de vapor en la base no están obstruidos. Limpiarlos utili- zando el PICO METÁLICO (Incluido en el Kit de Mantenimiento). 6. Con la plancha encendida, la VÁLVULA MAGNÉTICA esta supuesta a cliquear cada vez que presiona el INTERRUPTOR DE VAPOR.
- Page 22 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 Problema: El Interruptor de la plancha está encendido pero La luz per manece apagada y la plancha no calienta. = Solución: “ Analizar las siguientes 2 situaciones ”...
- Page 23 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 Iron’s Exploded View 20-7 20-13...
- Page 24 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 Part List REF# Description Description Iron Rest 20-1 Bolt for Handle Tip Steam Chamber & Sole Plate 20-2 Tip for Handle Chamber Cover 20-3 Micro Switch Chamber Front Bolt...
- Page 25 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 Quick Basic Maintenance Schedule The following quick maintenance list is highly recommended to per- form in a monthly basis for best results and to ensure the iron’s longest possible life.
- Page 26 OPERATING MANUAL HÖT-STEAM® SGB Series-Model No. SGB300, SGB600, SGB700, SGB800 & SGB900 Limited Warranty Gravity-Fed Iron is tested and inspected before leaving HÖT-STEAM® our factory. We warrant to the original user of this product that it will be free from defects in material and workmanship for a period of Six (6) Months from the date of purchase.
- Page 27 DEMINERALIZER will void or affect the warranty coverage. What is not covered? Operating your iron without using Genuine HOT-STEAM® Demineralizer and a proper type of Water can clog your iron in a very short time, making the steam sputter out or not coming out at all.
- Page 28 Copyright©2020 HÖT-STEAM® All rights reserved.
