- Page 1 REAR TINE TILLER BE-RTTR7 OPERATIONS & PARTS MANUAL FOR MODELS: • BE-RTTR7 PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER 103.106C MANUAL CODE:...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION PREASSEMBLY PLANNING ASSEMBLY TOOLS REQUIRED HARDWARE INCLUDED PACKAGE CONTENTS ASSEMBLY OPERATION MAINTENANECE CARE, CLEANING AND STORAGE TROUBLESHOOTING EXPLODED VIEW & PARTS LIST... -
Page 3: Safety Information
• Only allow responsible individuals, who are familiar with the instructions, to operate the tiller. • Do not operate the tiller while under the influence of alcohol or drugs. • The control lever is a safety device. Never attempt to bypass its operation. Doing so makes the safety BE-RTTR7 USER MANUAL... - Page 4 • To avoid personal injury or property damage use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are explosive. Serious personal injury can occur when gasoline is spilled on yourself or your clothes, which can ignite. Wash your skin and change clothes immediately. BE-RTTR7 USER MANUAL...
- Page 5 Never tamper with factory setting of engine governor. WARNING This machine is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush covered or grass-covered land unless the engine’s exhaust system is BE-RTTR7 USER MANUAL...
-
Page 6: Preassembly
Bolt M16x140 Up/Down Lever Lock Clevis Pin 8x30 Cotter Pin Washer Spring Washer Clevis Pin 8x45 Cable Clip PACKAGE CONTENTS PART DESCRIPTION QUANTITY Tiller Body/Upper Handle Wheel Depth Regulator Tiller Protective Shield Tines Bumper Use And Care Guide BE-RTTR7 USER MANUAL... -
Page 7: Assembly
(D) holes to the plate holes. Insert M8x20 bolts (AA) with spring washers (HH) and regular washers (GG) and tighten with a wrench. The front plate requires two MB nuts (BB) to secure. See Figure 1-2. WARNING Make sure the tiller protective shield is installed in place before starting the machine. BE-RTTR7 USER MANUAL... - Page 8 Place the cotter pin (FF) to lock in place. See Figure 1-4 WARNING Make sure to install the wheel in the correct direction. See Figure 1-4. BE-RTTR7 USER MANUAL...
- Page 9 • Insert tines (E) on each side through the tine axle located on the rear of the tiller. Align pre-drilled holes and insert clevis pin ( 11) then insert cotter pin (FF) to secure in place. See Figure 1-6. BE-RTTR7 USER MANUAL...
-
Page 10: Operation
SF, SG, SH, SJ or higher. • Do not use special additives. • Outdoor temperatures determine the proper oil viscosity for the engine. Use the chart to select the best viscosity for the outdoor temperature range expected. BE-RTTR7 USER MANUAL... - Page 11 GEAR LEVERS The tiller gear box is mounted on the tiller frame. One lever controls 1st, 2nd and reverse gears. The other lever controls the function of tilling on the soil. The 2 functions are scarify and furrow. BE-RTTR7 USER MANUAL...
- Page 12 • Always set the wheels in tilling position before starting engine. • Always put depth regulator lever in the transport position before starting engine. Tines should clear ground. DANGER Always keep hands and feet clear of rotating machine parts. BE-RTTR7 USER MANUAL...
- Page 13 • Make sure you return the choke lever to it’s original position and you close the fuel lever. 6 TILLING • Adjust the depth regulator lever to desired tilling depth. Insert the clevis (EE) and cotter pin (FF) to secure depth regulator to desired depth. See Figure 1-9. BE-RTTR7 USER MANUAL...
- Page 14 It is important that you know how to use the tiller properly, keep control at all times, stop the tines and wheels from turning, and stop the engine if necessary. If you do not know how to do these things, read the controls, adjustments and safety sections before proceeding. BE-RTTR7 USER MANUAL...
- Page 15 • Tighten upper jam nut (1) • Check adjustment. • This procedure can be repeated until conduit adjustment bolts are fully adjusted. If no more adjustment can be made, the wire may have to be replaced. See Figure 1-11 BE-RTTR7 USER MANUAL...
- Page 16 On engines not built for the United States the carburetor can be adjusted to operate under this condition. The carburetor should be returned to its normal setting if regular operation is less than 5,000 feet. Contact your service center to modify the carburetor. BE-RTTR7 USER MANUAL...
-
Page 17: Maintenanece
Keeping your tiller in top running condition will prolong its life, and help you obtain optimum performance. • Please read this normal care schedule, and note the recommended care operating intervals to extend the life of your tiller. BE-RTTR7 USER MANUAL... - Page 18 IMPORTANT: The tiller ships from the factory with transmission gear oil installed. Operating the tiller when the transmission is low on oil can result in severe damage. Do not operate the tiller if the gear oil level is low. Doing so will result in severe damage to the transmission components. BE-RTTR7 USER MANUAL...
-
Page 19: Care, Cleaning And Storage
• While engine is still warm, drain the oil from the engine. • Refill with fresh oil of the recommended grade. • Clean external surfaces, engine and cooling fan. • Remove spark plug, pour one ounce of SAE 30 oil into spark plug hole. BE-RTTR7 USER MANUAL... -
Page 20: Troubleshooting
• The tines assembled incorrectly. • Refer to “Install the Tines” Section. properly. • Excessive tilling speed / depth. • Till at a moderate pace. Make multiple passes. Frequent engine stalling. • Engine problems (above). • Refer to engine solutions (above). BE-RTTR7 USER MANUAL... -
Page 21: Exploded View & Parts List
SENSOR, ENGINE OIL 103.106C.003 GEAR ASSY, GOVERNOR 103.106C.004 ARM, GOVERNOR 103.106C.005 BOLT, DRAIN PLUG 103.106C.006 FLAT WASHER 103.106C.007 DEEP GROOVE BALL BEARING 103.106C.008 SEAL, OIL 103.106C.009 HEXAGON NUT WITH FLANGE 103.106C.010 FLAT WASHER 103.106C.011 COTTER PIN 103.106C.012 BOLT BE-RTTR7 USER MANUAL... - Page 22 GASKET, CYLINDER HEAD 103.106C.025 COVER SUBASSEMBLY, CYLINDER HEAD 103.106C.026 CYLINDER HEAD COVER GASKET 103.106C.027 TUBE, BREATHER 103.106C.028 BOLT 103.106C.029 STUD BOLT 103.106C.030 STUD BOLT 103.106C.031 POSITION PIN 103.106C.032 CYLINDER HEAD BOLT 103.106C.033 PLUG, SPARK 103.106C.034 HEAD SUBASSEMBLY, CYLINDER BE-RTTR7 USER MANUAL...
- Page 23 FIG.4 CONNECTING CRANKSHAFT ROD REF PART NUM DESCRIPTION 103.106C.037 CRANKSHAFT ASSY. FIG.5 CONNECTING RING SET,OIL / ROD,CRANKSHAFT REF PART NUM DESCRIPTION 103.106C.040 RING ASSY, PISTON 103.106C.041 CLIP, PISTON PIN 103.106C.042 PISTON 103.106C.043 PIN, PISTON 103.106C.044 ROD, CONNECTING BE-RTTR7 USER MANUAL...
- Page 24 TAPPET, VALVE 103.106C.054 LIFTER, VALVE PLATE SUBASSEMBLY, LIFTER 103.106C.055 STOPPER 103.106C.056 ROCKSHAFT BOLT 103.106C.057 ROCKER, VALVE 103.106C.058 NUT， VALVE ADJUSTING 103.106C.059 NUT, VALVE LOCK FIG.7 RECOIL STARTER REF PART NUM DESCRIPTION 103.106C.062 BOLT 103.106C.063 STARTER ASSY, RECOIL BE-RTTR7 USER MANUAL...
- Page 25 103.106C.074 BOLT SWITCH SUBASSEMBLY, 103.106C.070 103.106C.075 BOLT STOP ENGINE FIG.9 CARBURETOR ASSEMBLY REF PART NUM DESCRIPTION 103.106C.078 CARBURETOR ASSY. 103.106C.079 AIR CLEANER SEAL GASKET 103.106C.080 CARBURETOR SEAL GASKET 103.106C.081 PLATE, CARBURETOR INSULATOR 103.106C.082 GASKET, CARBURETOR INSULATOR 1 BE-RTTR7 USER MANUAL...
- Page 26 FIG.11 THROTTLE CONTROL ASSEMBLY REF PART NUM DESCRIPTION 103.106C.093 CONTROL ASSY, THROTTLE 103.106C.094 BOLT 103.106C.095 SPRING, GOVERNOR 103.106C.096 ROD, GOVERNEOR 103.106C.097 SPRING, THROTTLE VALVE RETURNING 103.106C.098 BOLT, GOVERNOR SUPPORT 103.106C.099 HEXAGON NUT WITH FLANGE 103.106C.100 GOVERNOR BRACKET SUBASSEMBLY BE-RTTR7 USER MANUAL...
- Page 27 REF PART NUM DESCRIPTION 103.106C.112 FUEL TANK 103.106C.113 FUEL STRAINER 103.106C.114 COVER, FUEL TANK 103.106C.115 BOLT HEXAGON NUT WITH 103.106C.116 FLANGE OUTLET SUBASSEMBLY, FUEL 103.106C.117 TANK OIL 103.106C.118 PIPE CLAMP 103.106C.119 TUBE, FUEL 103.106C.120 JACKET, RUBBER 103.106C.121 PIPE CLAMP BE-RTTR7 USER MANUAL...
- Page 28 103.106C.129 SEAT, ENGINE CONNETING 103.106C.130 BOLT 103.106C.131 STANDARD SPRING WASHER 103.106C.132 HEXAGON SOCKET HEAD CAP SCREW 103.106C.133 FLAT WASHER - GRADE A 103.106C.134 STANDARD SPRING WASHER 103.106C.135 HEXAGONAL HEAD BOLT - FULL THREAD 103.106C.136 BOX SUBASSEMBLY, TRANSMISSION BE-RTTR7 USER MANUAL...
- Page 29 103.106C.159 HEXAGONAL HEAD BOLT - FULL THREAD 103.106C.160 LARGE WASHER - GRADE A TYPE 1 NON-METALLIC INSERT HEXAGON LOCK 103.106C.161 103.106C.162 PANEL 103.106C.163 WIRE CLIP 103.106C.164 SLEEVE, HANDLE RUBBER 103.106C.165 GEAR LEVER 103.106C.166 PIN SHAFT 103.106C.167 SOCKET BE-RTTR7 USER MANUAL...
- Page 30 103.106C.182 103.106C.183 DAMPING ARM 103.106C.184 CONNECTION FRAME 103.106C.185 SOCKET 103.106C.186 PIN SHAFT HEXAGONAL HEAD BOLT - FULL 103.106C.187 THREAD 103.106C.188 FLAT WASHER - GRADE A 103.106C.189 STANDARD SPRING WASHER 103.106C.190 TYPE 1 HEXAGON NUT 103.106C.191 COTTER PIN BE-RTTR7 USER MANUAL...
- Page 31 PIN SHAFT 103.106C.196 SOCKET 103.106C.197 DEVICE SUBASSEMBLY, REVOLVE TILLING 19. WHEELS REF PART NUM DESCRIPTION 103.106C.200 TINE, OUTSIDE 103.106C.201 WHEEL, TRANSPORTION 103.106C.202 REAR WHEEL SHAFT 103.106C.203 STANDARD SPRING WASHER 103.106C.204 TYPE 1 HEXAGON NUT 103.106C.205 WHEEL, TRANSPORTION BE-RTTR7 USER MANUAL...
- Page 32 SERVICE PARTS REF PART NUM DESCRIPTION WHEEL AIR CLEANER ASSEMBLY RECOIL TINES BE-RTTR7 USER MANUAL...
- Page 33 BE-RTTR7 USER MANUAL...
- Page 34 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-RTTR7 USER MANUAL...
