- Page 1 MINI TILLER CULTIVATOR BE-MTR2 OPERATIONS & PARTS MANUAL FOR MODELS: • BE-MTR2 PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER MANUAL CODE: 102.107B...
- Page 2 TABLE OF CONTENTS Introduction Safety Structure Assembling Adjustment and Operation Maintenance Troubleshooting Exploded view and partst list BE-MTR2 USER MANUAL...
- Page 3 3. When machine is operation, prohibit touching the gear wheel. In order to improve the quality, the changes of some parts which are changed according to the market will not be informed separately. Please give enough understanding. BE-MTR2 USER MANUAL...
- Page 4 • Make sure the professional person maintains the machine; • Should inspect the machine termly, if appear abnormity when operating, must stop the machine for repairing at once; • Need for repairing or service, please contact our SuperHandy customer service center by 1-866-493-0524 for assistance. BE-MTR2 USER MANUAL...
- Page 5 5. DO NOT START ENGINE IF FUEL IS SPILLED. WIPE OFF EXCESS FUEL AND ALLOW TO DRY. REMOVE ENGINE FROM AREA TO AVOID SPARKS. 6. EVER RUN ENGINE INDOORS. EXHAUST FUMES ARE DEADLY. 7. FAILURE TO FOLLOW THESE WARNINGS CAN CAUSE DAMAGE TO EQUIPMENT AND INJURY TO PERSONNEL. BE-MTR2 USER MANUAL...
- Page 6 (No.11). Fig 3 Locking metal sleeve Highest groove Locking metal sleeve, (locked position) (unlocked position) No.11 Wheel adjuster plate Expanded spring Compressed spring Fig. 3 Fig.5 Fig.4 BE-MTR2 USER MANUAL...
- Page 7 If the equipment should start to vibrate abnormally, stop the engine, disconnect the spark plug wire and prevent it from touching the spark plug. Check immediately for cause. Vibration is generally a warning of trouble. If the noise or vibrations of the machine increase, stop immediately and perform an inspection. BE-MTR2 USER MANUAL...
- Page 8 Drop a lie motor oil on the cleaner element, not attach it back to the inside cover until the oil dry. If the sponge is too dirty, please change a new one. BE-MTR2 USER MANUAL...
- Page 9 Carburetor out of adjustment or bad Call customer service Engine revs too high Carburetor out of adjustment Call customer service Idle speed too high Adjust idle speed lower Tines turn at idle Broken clutch spring Replace spring BE-MTR2 USER MANUAL...
- Page 10 TILLER EXPLODED VIEW AND PARTS LIST BE-MTR2 USER MANUAL...
- Page 11 Bolt M6x8 102.107B.026 Bolt assy 102.107B.057 Engine 102.107B.027 Connect bat II 102.107B.058 Electrical assing 102.107B.028 Bolt M6x20 102.107B.059 Bolt M6x12 102.107B.029 Screw M8 102.107B.060 Bolt M5x12 102.107B.030 Washer 8 102.107B.061 Washer 5 102.107B.031 Wheel 102.107B.062 Washer 12 BE-MTR2 USER MANUAL...
- Page 12 TILLER EXPLODED VIEW AND PARTS LIST BE-MTR2 USER MANUAL...
- Page 13 102.107B.024 Start dial 102.107B.054 Cylinder cover cap 102.107B.025 Recoil start 102.107B.055 Cylinder paper gasket 102.107B.026 Needle bearing Intake manifold paper 102.107B.056 102.107B.027 Piston pin clip gasket 102.107B.028 Piston pin 102.107B.057 Allen screw M5*20 102.107B.029 Piston 102.107B.058 Locating pin BE-MTR2 USER MANUAL...
- Page 14 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-MTR2 USER MANUAL...
