- Page 1 ROTARY TILLER BE-TXGXX OPERATIONS & PARTS MANUAL FOR MODELS: • BE-TXG40 PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
- Page 2 TABLE OF CONTENTS GENERAL INFORMATION & SAFETY OPERATION MAINTENANCE EXPLODED VIEW & PARTS LIST...
- Page 3 INTRODUCTION Thank you for purchasing your BE Rotary Tiller. Your rotary tiller is designed to be used on 540 RPM tractors. It is important to properly maintain and keep in place all safety guards and shields that came with your tiller. SAFETY Read and understand this manual and all safety signs before operating and maintaining.
- Page 4 SAFETY DECAL CARE • Keep safety signs clean and legible at all times. • Replace safety signs that are missing or have become illegible. • Replaced parts that displayed a safety sign should also display the current sign. • Safety signs are available from your Distributor or Dealer Parts Department or the factory. HOW TO INSTALL SAFETY SIGNS: •...
- Page 5 • Beware of bystanders, particularly children. Always look around to make sure that it is safe to start the engine of the towing vehicle or move the unit. This is particular important with higher noise levels and quiet cabs, as you may not hear people shouting. •...
- Page 6 standing alongside of unit. • Never leave running equipment attachments unattended. • As a precaution, always recheck the hardware on equipment following every 100 hours of operation. Correct all problems. Follow the maintenance safety procedures. OPERATION DANGER Before attaching the rotary tiller to the tractor, check the unit to ensure there is oil in the top and side gearbox.
- Page 7 Slip clutches have adjustable torque settings. The torque setting varies with the different compression of each spring. All the springs should have an equal amount of compression. IMPORTANT: Do not over-tighten the compression nuts as this may impair performance or cause premature wearing of the slip clutch.
- Page 8 MAINTENANCE Performing Maintenance • Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. • Make sure there is plenty of ventilation. Never operate the engine of the towing vehicle in a closed building. The exhaust fumes may cause asphyxiation. •...
- Page 9 EXPLODED VIEW & PARTS LIST BE-RTH120 USER MANUAL...
- Page 10 REF PART NUM DESCRIPTION REF PART NUM DESCRIPTION “R” Clip - 4mm TX.06.01 Skid Weldment - Left T10-66-01-02-02 Hitch Pin (Lower Hitch Block) Nylon Lock Nut M24*1.5 TX.02-02 Lower Hitch Bracket O-Ring - Idler Gear Support Shaft TX.02-03 “U” Bolt, Lower Hitch Bracket TX.05.01 Side Drive Cover GB/T6177.1...
- Page 11 PTO SHAFT REF PART NUM DESCRIPTION DP1075-40 PTO Yoke - Series 40 DP1075-60 PTO Yoke - Series 60 DP1079-40 Female Yoke & Tube (tractor end) - Series 40 DP1079-60 Female Yoke & Tube (tractor end) - Series 60 DP1076-40 Cross & Bearings - Series 40 DP1076-60 Cross &...
- Page 12 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-RTH120 USER MANUAL...
