- Page 1 GASOLINE TILLER BE-BRTXXX OPERATIONS & PARTS MANUAL FOR MODELS: • BE-BRTH65 • BE-BRTR7 PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER 102.108C MANUAL CODE...
- Page 2 TABLE OF CONTENTS SAFETY ASSEMBLY OPERATION MAINTENANCE & STORAGE STORAGE & TROUBLESHOOTING PARTS LIST...
- Page 3 SAFETY OWNER’S RESPONSIBILITY Accurate assembly and safe and effective use of the rototiller is the owner’s responsibility. • Read and follow all safety instructions. • Carefully follow all assembly instructions. • Maintain the tiller according to directions and schedule included in this operator’s manual. •...
- Page 4 PREPARATION • Dress appropriately when operating the tiller. Always wear sturdy footwear. Never wear • Do not allow children to operate this rototiller. Keep small children away from the area being tilled. Do not sandals, sneakers, or open shoes, and never operate the tiller with bare feet. Do not wear allow adults to operate the tiller without proper instruction.
- Page 5 • Do not run the engine indoors; exhaust fumes are deadly. • Do not overload the machine capacity by attempting to till too deep at too fast a rate. • Never operate the machine at high transport speeds on slippery surfaces. Look behind and use care when backing.
- Page 6 others who may use the equipment. Follow the safety instructions necessary for safe, effective operation of your rototiller. ASSEMBLY INSTRUCTIONS BE-BRTXXX USER MANUAL The rototiller comes fully assembled...
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS The rototiller comes fully assembled except for a few parts. The following The rototiller comes fully assembled except for a few parts. instructions will help you assemble and The following instructions will help you assemble and adjust the tiller’s depth regulator, cable tension, and handlebar adjust the tiller's depth regulator, cable height.
- Page 8 3. Tighten all the nuts. STEP 3: Attach handle bar to the Tiller STEP4 Fill Engine Crankcase 1. Insert four fastness bolts for each side in every holes. IMPORTANT 2. Start fastness nuts on each bolt. Engine is shipped from factory without oil. Engine oil must be added before st 3.
- Page 9 START- UP The controls required to start and run the rototiller are located on the engine and are marked “choke” and “Throttle”. A more detailed description of engine operation and all related precautions and procedures can be found in the engine manufacturer’s manual that accompanies each tiller. COLD STARTS 1.
- Page 10 TILLING 1. Adjust the depth regulator lever to desired tilling depth. NOTE: Raise depth regulator lever up one hole at a time, testing tiller operation after each raise. Raising depth regulator lever too high can result in loss of control of tiller! 2.
- Page 11 Pulling the drive safety control lever(REVERSE) to Releasing the lever stops the wheels and tines. 4. Repeat for other wheel. NOTE: Always have both wheel lock pins in or out. Do not operate tille one wheel locked. REVERSE LEVER Engages wheels and tines into reverse. To place wheels in free-wheel position.
- Page 12 2. Raise the depth regulator lever to position tines at chosen tilling depth. DEPTH REGULATOR LEVER 3. Align hole in depth regulator lever with DEPTH REGULATOR LEVER Tilling depth is controlled by the height of the hole in depth regulator bracket and replace Tilling depth is controlled by the height of the depth regulator depth regulator lever.
- Page 13 TILLING TIPS The key to successful tilling is to begin with a shallow cut on the first pass, and then work an inch or two deeper on each successive pass. WARNING Extreme caution must be taken in selecting tilling depth, if you attempt to kill too deeply for soil conditions, that is, with the drag stake in too high a position, loss of control could result.
- Page 14 make certain unit is safe to operate. Use only a non-flammable solvent, not gasoline, to clean parts. Keep cigarettes, sparks and flames away from all fuel-related parts. • When completing maintenance or service, make sure all safety guards and devices are •...
- Page 15 belt out of the V-groove. - slide the belt free of the engine pulley. The following information will help you SERVICING THE ROTOTILLER - pull the forward belt down and out of the make the necessary checks and perform The following information will help you make the necessary way.
- Page 16 CHECK OR FILL ENGINE CRANKCASE 1. Add oil according to engine manual. Do 5. Keep engine and parts clean. not overfill. Use a clean, high quality 6. Check engine and equipment often for loose nuts and bolts, keep these items tightened. detergent oil.
- Page 17 STORAGE PREPARE FOR STORAGE Follow the steps below to prepare your tiller for storage. Read your engine manual for detailed instructions on preparing the engine for storage. 1. Protect wheels and axles from rust: • Remove lock pin and slide wheel off hub. •...
- Page 18 PROBLEM REMEDIATION • Lock wheels in tilling position Tines turn, wheels do not turn • Internal transmission failure, see your dealer Tines turn, wheels turn, tiller does • Lower the tines for deeper tilling by raising the depth regulator lever not move •...
- Page 19 EXPLODED VIEW & PARTS LIST CLUTCH & HANDLE BE-BRTXXX USER MANUAL...
- Page 20 Blade kits & Safty Guard BLADE SKIRTS & SAFETY GUARDS 84-2 84-1 84-1 84-3 BE-BRTXXX USER MANUAL...
- Page 21 DRIVER PARTS BE-BRTXXX USER MANUAL...
- Page 22 REF PART NUM DESCRIPTION REF PART NUM DESCRIPTION 102.108C.001 Handle bar knob nut 102.108C.042 Axle sleeve 102.108C.002 Fan-shaped screw 102.108C.043 Reverse tension wheel Outer Hexagon flange 102.108C.044 Reverse belt 5PK740 102.108C.003 Bolt M6x40 Deep groove ball bearing 102.108C.045 102.108C.004 Handle bar assembly 6200 Clutch handle shock 102.108C.046 Circlip 30...
- Page 23 REF PART NUM DESCRIPTION REF PART NUM DESCRIPTION 102.108C.081 Big belt cover protector 102.108C.120 Output shaft bearing 102.108C.082 Cable protector 102.108C.121 Ajustable washer 102.108C.083 Outer Hexagon Nut M8 102.108C.122 Wheel shaft 102.108C.084 Safety guard assembly 102.108C.123 Flat key 84-1 102.108C.085 Right cover 102.108C.124 Cabinet assembly 84-2 102.108C.086 Left connecting plate...
