Summary of Contents for SISTEMATICA EASY SMART
- Page 1 S m a r t MANUALE D’USO • MANUEL DE L’UTILISATEUR • BENUTZERHANDBUCH • USER MANUAL...
-
Page 3: Table Of Contents
The product descriptions in the present manual also comply to Directive 2014/53/EU The Declaration of Conformity for Sistematica S.r.l products is available at the web address www.sistematica.it/docs/DeclarationOfConformitySmartline.pdf ENGLISH WARNINGS RECEIVERS SYSTEM INSTALLATION POWER ON LIGHT GUIDE OPTIONS PAIRING WEEE EXTERNAL ANTENNA / STUB ANTENNA... -
Page 4: Warnings
When the key is released, the corresponding output on the receiver remains Sistematica S.r.l. reserves the right to make, at any time and without notice, activated. It deactivates the next time the button is pressed. modifications and improvements to the products to increase quality, and without such modifications being reported in this publication. -
Page 5: System
SYSTEM TUTORIAL PAIRING QRCode POWER ON PAIRING System coding (pairing) is a necessary operation when you want to replace The system consists of a transmitter (handheld) and a receiver (SmartBox). the SMARTBOX, or if you want to use the same one but with a different By pressing START on the handheld, the SmartBox exits standby and handheld from the one to which it was previously paired. - Page 6 WEEE Statement for Domestic EEE, containing rechargeable and removable Batteries or Accumulators, in which the battery can be easily removed by the user. INFORMATION TO USERS OF DOMESTIC EQUIPMENT Pursuant to art. 26 of Legislative Decree 14 March 2014, n. 49 “Implementation of Directive 2012/19/EU on electrical and electronic equipment waste (WEEE)” and of Legislative Decree 188 of 20 November 2008.
-
Page 7: Handhelds
HANDHELDS TECHNICAL FEATURES EASY SMART (NEMO/PLD) Number of keys: up to 6 (plus START & STOP) Dimensions (mm): 109 x 56 x 30 122 x 56 x 43 (with E-STOP) Power supply: 2 AAA AlKaline 1,5V batteries or rechargeable on demand Manufacturer: Sistematica S.r.l. - Page 8 BATTERIES When the RED LED on your handheld lights up if you press a key, it means the batteries are low. System performance may be reduced and should be replaced as soon as possible. For security reasons, any key pressed will be interpreted as a STOP command. STANDARD ‘STANDARD’...
- Page 9 RECHARGEABLES EASY and TREND with rechargeable batteries are supplied by Sistematica together with their battery charger support (USB Type-C cable is on demand). The charging station takes 3-4 hours to fully recharge the lithium batteries of the handheld. Make sure the contact points of the charger and your handheld are clean to ensure good connnection.
-
Page 10: Leds
LEDS Among the various alerts, our LEDs are the most visual and immediate, located in the upper part of the handheld. GREEN Indicates the presence of radio transmission and active CloseLink. It also lights up when a function key is pressed when the activity is in progress (if this does not happen, the batteries are probably flat or START was not pressed before). -
Page 11: App
LEDS ON HANDHELD The handheld is equipped with 3 LEDs used to indicate the functioning of the system. The various meanings are described in the following table.* OPERATION MEANING One flash A key is pressed Flashing every 10 seconds Radio connection with the SMARTBOX correctly working GREEN Signal that the handheld is being switched off (due to loss of radio connection, or after pressing the Flashes 3 times... -
Page 12: Options
OPTIONS EMERGENCY BUTTON SCREEN It is an option (IP65) that helps ensure complete control of operations when- ever an emergency stop of the application is required. 1. By pressing the red button, the receiver turns off resetting all outputs. Both SmartLine handhelds can be equipped with a screen: while EASY 2. -
Page 13: Tilting Hand
CALIBRATION OF THE PROPORTIONAL VALVE TILTING HAND The calibration procedure allows you to set the MINIMUM and MAXIMUM movement speeds by storing them in the SMARTBOX. Receivers have the ability to control an output proportionally (accelerometer): 1. With the system is switched on, press START and STOP on the handheld upon pressing a key and with the handheld in the horizontal starting simultaneously for at least 2 seconds until the RED LED on the handheld position, the proportional solenoid valve is activated at the minimum value. -
Page 14: Safetypoint Smart
TUTORIAL QRCode SAFETYPOINT SMART HOW SAFETYPOINT™ TECHNOLOGY WORKS SafetyPoint Technology forces the user to maintain a specific position to 1. Bring the front of the handheld close to the TAG at a maximum distance control certain maneuvers safely. These activities are constrained through the software, activating only when the handheld is pointed 2cm from the of 2cm. -
Page 15: Page Change
PAGE CHANGE QRCode MANUAL The option multiplies the handheld keyboard by a maximum of 4 ‘pages’. OPERATION SAFETYPOINT TAG PAIRING (see manual) 1. Power up the receiver paired with the handheld (see PAIRING p. 77 if the 1. INSTALL and complete the download of the SmartApp. App icon will system doesn’t work) and wait a few seconds. - Page 16 RECEIVERS TECHNICAL FEATURES SMARTBOX 8 Manufacturer: Sistematica s.r.l. Dimensions (mm): 108 x 110 x 44 Operating temperature: -20°C ÷ +55°C Number of outputs: up to 8 Power voltage: 10/30V ±10% Number of digital inputs: 1 Typical absorption in standby: 30 mA...
- Page 17 CNTR 8 INSTALLATION DRILLING TEMPLATE In order to ensure correct operation, the following rules must be respected: · Installation must be performed by qualified personnel. · Position the receiver vertically (with the cable outlet facing downwards) and in an accessible way. In order not to compromise reception, the SMARTBOX must not be shielded from ferrous masses (e.g.
- Page 18 LIGHT GUIDE The SMARTBOX is equipped with 4 LEDs used to indicate the functioning of the system. The various meanings are described in the following table. OPERATION MEANING Always on Powered correctly GREEN Flashes slowly Indicates that a button is being pressed on the handheld Slow flashing Device awaiting pairing with handheld (duration 15 seconds) YELLOW...
- Page 19 OPTIONS EXTERNAL ANTENNA STUB ANTENNA The External Antenna with coaxial cable is used to improve reception capacity The receiver is supplied with an external antenna (STUB) and relative gasket. It of the SMARTBOX in cases where the latter must be mounted in positions must be mounted on the SMA connector on the SMARTBOX.
- Page 20 Can outputs to go inside a second programmed control unit, also equipped with a Canbus line (ECU, PLC, etc). The protocol used by Sistematica in OPERATION the Canbus communication of its products is proprietary (or protocol The keyboard reproduces the handheld’s function-commands:...
- Page 21 Connection via Bluetooth to a SmartLine device SMARTBOX Views Real Time info/warnings Displays and transmits parameters, anomalies, diagnostics and tests to Sistematica’s Web Portal Data Sheet of the products associated with the Account Data Sheet of the products associated with the Account Allows you to use the “Virtual Handheld”...
- Page 22 LABELS HANDHELDS QR CODE Producer (S/N - ART - SW) Model Code WEEE directive Serial number European certification Power supply Operating temperature Order reference...
- Page 23 RECEIVER BOX Producer Power supply Operating temperature Automotive certification WEEE directive European certification...
- Page 24 RECEIVER FACEPLATE QR CODE (S/N - ART - SW) Serial number Order reference Model Code...
- Page 25 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSES SOLUTION The GREEN LED on the handheld does Low battery Replace the handheld batteries (see “BATTERIES” p. 80) not light up when a button is pressed Low battery Replace the handheld batteries (see “BATTERIES” p. 80) Check the correct insertion of the batteries;...
- Page 26 INSTRUCTIONS 1. Complete the FORM in its entirety (legibly) 2. Send it by email to: customercare@sistematica.it 3. Prepare the object in a box together with a copy of the FORM and send (at your expense) to: SISTEMATICA (Magazzino) VIA ANDREA SANSOVINO 217 10151 TORINO (TO) - ITALY 4.
- Page 28 This product may be subject to restrictions in its use. More information can be requested by writing to info@sistematica.it s i s t e m a t i c a . i t Sistematica S.r.l. - Via Andrea Sansovino 217 - 10151 - Torino - Italia...
