4. Peel off the protective film of the silicone pad and stick it on the front-facing surface of the SSD, then
peel off the film on the other side.
5. Reinstall the panel and power on the NAS. After successful boot up, go to the "UGREEN NAS" app to
set the SSD cache.
Warning
To avoid data loss, please remove the SSD cache in the "UGREEN NAS" before
removing any M.2 SSD. This will provide added protection in case the system
is using it for caching.
11
Installing Memory Modules
1. Power off the NAS device, then turn it over. Loosen the screws and remove the bottom panel.
2. Align the notch on the pins of the module with the corresponding ridge in the slot. Insert the module
into the slot and gently push it down to ensure the module is properly inserted.
3. Reinstall the panel and tighten the screws.
2 3
