XINGYI HIGH TECH GRINDING 680-3A Instruction Manual

Self propelled floor grinding machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual of 680-3A Self Propelled Floor Grinding Machine

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIGH TECH GRINDING 680-3A and is the answer not in the manual?

Questions and answers

Related Manuals for XINGYI HIGH TECH GRINDING 680-3A

Summary of Contents for XINGYI HIGH TECH GRINDING 680-3A

  • Page 1 Manual of 680-3A Self Propelled Floor Grinding Machine...

  • Page 2: Table Of Contents

    Contents 1. Introduction 1.1 Summary 1.2 Responsibility 1.3 Accessories 1.4 Package acceptance 1.5 Machine name plate 1.6 Handling and storage 1.7 Warranty items 2. Safety guidance 2.1 Overview 2.2 Operation safety guidance 2.3 Electrical safety guidance 3. Machine 3.1 Overview 3.2 Machine parts 3.3 Swing lever accessories 3.3.1 Overview...
  • Page 3 4.2.5 Lift the machine 4.2.6 Precautions 4.3 Transportation 4.3.1 Manual 4.3.2 Automatic 4.3.3 Transportation and storage 4.4 Start and stop the grinder 4.5 Replace abrasives 4.6 Wind type of machine working wire 4.7 Grinding route(for reference) 5. Equipment maintenance 5.1 Overview 5.2 Daily check 5.2.1 Check the switches 5.2.2 Check the disc cover...

  • Page 4: Introduction

    1. Introduction 1.1 Summary Xingyi machine are used to handle the floor surface. The scope of use of the machine depends on the choice of the tool. In addition to the use and general functions, this manual describes information on the use, repair and maintenance of the grinder.

  • Page 5: Machine Name Plate

    For complete information on the manufacturer's warranty period, please refer to the current warranty terms of Xingyi. Local retailer may have special warranty terms. If you have any uncertainty about the warranty terms,...

  • Page 6: Overview

    Any machine parts that need to be changed must be provided by XINGYI. Xingyi machines only can be used in the way of Xingyi recommended. And they can only be used for commercial purposes. Anyone who uses a machine should know its function, the location of the emergency stop.

  • Page 7: Operation Safety Guidance

    8. Do not lend or rent the machine without an instruction manual. 9. Wear personal protective safety equipment. 10. Random modification of the machine is not allowed. Only XINGYI accessories can be used for maintenance and adjustment. 11. Do not operate the machine outside on rainy or foggy days.
  • Page 8 10. Keep the machine away from drains and furnace mouths or other dangerous goods, otherwise it may cause personal injury or loss of machinery and property. 11.Tight-hold hand grip, clockwise rotate the emergency switch, then turn on the power button and start the machine.

  • Page 9: Electrical Safety Guidance

    2.3 Electrical safety guidance 1. All circuit repairs can only be carried out by qualified personnel. 2. Note: After the machine is stopped, the line is still energized. Disconnect all power before servicing the machine. 3. The machine is equipped with an overload protection device, and it will automatically jump off when the machine is overloaded, to prohibit the machine from running;...

  • Page 10: Machine

    (to a dust collector recommended by Xingyi). Due to inhalation of dust is harmful during operation, even if there is a vacuum cleaner connected a protective mask may also be necessary to protect health.

  • Page 11: Machine Parts

    3.2 Machine Parts 1. Handle rubber sleeve 27. USB interface 2. Elbow handle 28. Forward and reverse switch 3. Swing lever angle adjustment handle 29. Emergency stop switch 4. Forward and backward switch 30. Inverter box key 5. LED light switch 31.

  • Page 12: Swing Lever Accessories

    3.3 Swing lever accessories 3.3.1 Overview 1. Forward/reverse switch: Controls the forward and backward movement of the machine. 2. Swing lever angle adjustment handle: the handle can adjust the angle of Swing lever to corresponding location. 3. Driving wheel speeder: adjust the walking speed of driving wheel. 4.

  • Page 13: Led Light Switch Equipment

    15. Running indicator: When the device is working normally, the running indicator lights up. 3.3.2 LED light switch equipment Toggle the LED light switch to ON, LED light will be turned on, otherwise turned off. The base of LED light is magnetic to placed freely. During operating, the different positions need different lighting direction.
  • Page 14 During grinding, do be sure to connect a vacuum cleaner. It is suggested to use the vacuum cleaner produced by XINGYI to ensure vacuuming efficiency. Bad vacuum cleaner is likely to clog the dust in the forward / reverse switch, resulting in a switch failure.

  • Page 15: Usb Charge(Clock)

    3.3.4 USB charge (clock) There is a watch shape of the device on the control panel. The clock is convenient for users to see the current time. Turning up the clock, we can see a USB interface, which can be used to charge mobile phone or other device.

  • Page 16: 6The Angle Adjustment Of Swing Lever

    Note: 1. When plugging out the pin, sometimes it will be caught, and the pin can be pulled out by shaking the support wheel. 2. When the handle adjustment bolt is automatically reset, the hole may not be aligned, just rotate up and down 3.
  • Page 17 ①Lifting position ②Working position ③Packaging position Note: After adjusting the position of the swing rod, it is necessary to check whether the swing rod has been limited before operating the machine.

  • Page 18: Water Tank

    3.4 Water tank There is a water inlet on the side of the water tank (open the water injection port as shown below). The heat dissipation openings on both sides of the water tank make the heat dissipation of the inverter box of the equipment faster and can extend the service life of the electrical appliances inside the inverter box.

  • Page 19: Front Wheel

    3.6 Front wheel 3.6.1 Disconnecting the front wheel. The supporting wheel is assembled before transporting, which can make the steering smoother. When transporting the machine, sometimes it is necessary to move the machine forward and backward, so it is more convenient and labor-saving to install the supporting wheel to carry out the movement of the grinding machine.

  • Page 20: The Lifting And Lowering Of Front Wheel

    Note: When plugging out the pin, sometimes it will be caught, and the pin can be pulled out by shaking the support wheel. When pulling out the latch, hold the support wheel with one hand to prevent the support wheel from suddenly turning down.

  • Page 21: Additional Weight

    3.Insert the locating pin into the r-type cotter pin and fix the locating pin. ① Supporting wheel ② R-shaped bolt ③ Supporting wheel bolt Note: The support wheel must be lowered to the lowest position before it can be turned over. When the plug is pulled out, it may get stuck.

  • Page 22: Clutch Device

    3.8 Clutch device The clutch device (the device composed of the clutch rubber sleeve and clutch pin is collectively referred to as clutch device) has two main states: Unlocking state: When the machine is not working, loosen the clutch device, then pull out the clutch pin, rotate the clutch pin sleeve, and stuck the clutch pin in the limit device of the clutch pin sleeve to tighten the clutch device.
  • Page 23 Locking state: When the machine starts working, loosen the clutch device, then pull out the clutch pin, rotate the clutch pin sleeve, and clamp the clutch pin on the limiting device 2 to tighten the clutch device. ④ Limiting position 2 Note: 1.

  • Page 24: Reserve Battery Charge

    3.9 Inverter box 1. Power socket: connected to an external power, supply power to the machine 2. Timer: shows the total running time of the device. 3. Charging hole: for the device's own internal battery to charge. Charge the internal battery of the machine 4.

  • Page 25: Machine Operating

    inverter box. Open the cover of the charging port and use the charger provided by the manufacturer to charge. 4. Machine operating 4.1 Overview The following part mainly describes the grinder in different positions when the mode is switched to manual operation, the main operation of the grinder and how to install the grinding abrasive.

  • Page 26: Machine Position Description

    4.2 Machine position description. 4.2.1 Machine working position. During grinding, pull out the spring pin on the additional weight, reach the gasoline motor, gently lower the additional weight to the proper position, adjust the handle and swing lever position to achieve the most proper working position.

  • Page 27: Machine Carriage Position

    4.2.2 Machine carriage position During transportation, adjust the additional weight, swing lever and handle to the transport position. Then, pull the clutch pin out. Lower and rotate the support wheels to lock, adjust the height of the support wheel so that the disc is off the ground for easy transportation. Note Do not rotate the support wheel to an excessive position to prevent it from falling off, which may cause dangerous accidents.

  • Page 28: Machine Upright Position

    4.2.4 Machine upright position Adjust the bolt of the extra weight so that the extra weight is in tilted position, and adjust the handle, pedal and swing lever position to the lifting position. (Recommended best tilting position) Hold the handle with both hands and place one foot on the additional weight to force the machine down.

  • Page 29: Lift The Machine

    XINGYI company does not assume any responsibility for machine damage and personal injury caused by improper operation. Note: After lifting up the machine, remember to stand next to the grinding head, slightly press the grinding head to see if the machine is stable for personal safety.

  • Page 30: Precautions

    4.2.6 Precautions 1. Improper operation may lead to the grinding machine being overturned and damaged, even endanger personal safety. 2. When the handle adjustment pin is pulled out, it may get stuck. Just shake the handle and pull out the pin. 3.
  • Page 31 ① Limiting position 1...
  • Page 32 Note： 1. When the clutch pin is pulled out, it may get stuck. Just shake the machine and pull out the clutch pin. 2. Pay attention to your own safety when lifting the machine, be sure to do no more than you can. 3.

  • Page 33: Automatic

    4.3.2 Automatic Rotating the support wheel handle can lower the support wheel and raise the grinding device from the working area. It is recommended that the lowest position of the grinding disc be 1” (25mm) above the ground 1. Adjusting the handle and swing lever to working position, and additional weight to transport position.

  • Page 34: Transportation And Storage

    Note: 1. The emergency stop switch should be screwed or pressed and cannot be pulled. The manufacturer does not compensate for any loss caused by improper operation. 2. Take out the grinding pads to prevent it drops and loss before transport. 3.

  • Page 35: Start And Stop The Grinder

    4.4 Start and stop the grinder. 1. Start the grinder （1）Firstly adjust swing lever, handle and additional weight to the corresponding working position, place the supporting wheel device in the lowest position and invert it or disassemble it (as shown in the figure below).

  • Page 36: Replace Abrasives

    （3） Turn on the emergency stop switch, rotate the speed regulator to adjust the rotation speed of the motor, turn the switch to the left to rotate the motor forward (rotate to the right to reverse the motor) (turn on the water switch before water grinding) ress the emergency stop switch and unplug the power to stop the machine 2.
  • Page 37 Note: 1. Please ensure that the machine won’t tip forward before replacing the abrasive. 2. After the machine has been running for a period, the abrasive, grinding disc and the gear box will generate high temperature. Be careful to be burn when you replace the abrasive. 3.

  • Page 38: Grinding Route(For Reference)

    4. Please use the correct power supply. Note: The machine model of the above picture can be ignored, the grinding route and winding method are for reference only. 4.7 Grinding route (for reference) When grinding the ground, it should be in accordance with the # method to grind the ground to get better effect.

  • Page 39: Equipment Maintenance

    5. Equipment maintenance 5.1 Overview We recommend that the grinding machine be checked regularly to extend the service life. Note: During the maintenance and repair process, the power of the grinder must be disconnected. Wear protective equipment such as safety shoes, protective gloves, protective masks, etc. 5.2 Daily check 5.2.1 Check the switches The emergency stop switch should be rotated along the rotation direction of the switch.

  • Page 40: Long-Term Storage Of Batteries

    Note: Be sure to wear protective equipment for maintenance checking such as protective gloves, protective masks, insulated shoes, etc. The maintenance operation must be done when the emergency stop pressed and the power unplugged. When the machine is tilted, make sure that the machine is flat and then check the operation of the grinding disc.

  • Page 41: Clean Up The Grinding Plate And Conversion Block

    Remove the vacuum tube connection, illuminate the dust nozzle with a flashlight, clean the dust nozzle with brush. So that it will not clog the dust nozzle and affect dust collection efficiency. 5.3.3 Clean up the grinding plate and conversion block Tilt the machine and use a cross screwdriver to remove the pads, and use shovel to remove dust.

  • Page 42: Overloading

    5.5 Maintenance Any repairs must be performed by Xingyi Service Center training service personnel and use original Xingyi accessories. If your machine needs repair, please contact your retailer. 6. Frequently Asked Questions and Solutions This chapter describes some of the possible failures and how to handle them.
  • Page 43 consumption is large grinder and operator Field voltage is lower than 350v Battery power is used to 0 Charge with a single-phase electric charger Unable to charge for 1 hour The battery is damaged, or the times of Replace the battery impulse electricity it has been exceeds its life.

  • Page 44: Technical Parameter

    7. Technical parameter The table and picture show the technical data and dimensions of the grinder. 680-4A Engine power P 220 P 380 Rated voltage Rated current 22.3A Input hertz HZ 60 Inverter power Working width Diameter of grinding disk Grinding speed Dimension(rear ...

  • Page 45: Warranty

    8.Warranty Xingyi does not bear the cost of machine damage caused by improper transportation, unpacking and improper use. Local distributors may be subject to specific warranty terms, please contact your local distributor for specific warranty terms.
