TMG -PSM36 Product Manual

36” cutting capacity portable sawmill with 21hp honda v-twin engine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TMG-PSM36
PRODUCT MANUAL
v2023.10.04
36" CUTTING CAPACITY
PORTABLE SAWMILL
WITH 21HP HONDA V-TWIN ENGINE
Please read and understand the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TMG-PSM36 and is the answer not in the manual?

Questions and answers

Related Manuals for TMG TMG-PSM36

Summary of Contents for TMG TMG-PSM36

  • Page 1 TMG-PSM36 PRODUCT MANUAL v2023.10.04 36” CUTTING CAPACITY PORTABLE SAWMILL WITH 21HP HONDA V-TWIN ENGINE Please read and understand the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Do not return the product to dealer.

  • Page 2: Table Of Contents

    Contents GENERAL SAFETY RULES..................................3 GENERAL MAINTENANCE INFORMATION.............................7 SAWMILL ASSEMBLY INSTRUCTIONS..............................8 Inspection......................................8 Tracks........................................8 Log Dog & Supports.....................................10 Carriage Assembly....................................12 Electric Wire Connect..................................25 Engine........................................26 SAWMILL SET-UP PROCEDURES.................................27 Belt Tension......................................27 Blade Tracking.....................................28 Blade Guide Adjustment..................................32 Blade Tension......................................33 SAWMILL MAINTENANCE...................................35 Changing the Blade....................................35 Replacing Belts....................................35 TROUBLESHOOTING....................................37 DIAGRAMS-ENSEMBLE..................................37 Diagrams(A)-Bandwheel Housing.............................38...

  • Page 3: General Safety Rules

    Thank you very much for choosing the TMG-PSM36 Portable Sawmill. For future reference, please complete the owner’s purchase date: Save the receipt for warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.
  • Page 4 SAVE THESE INSTRUCTIONS WORK AREA Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. Do not use your sawmill where there is a risk of causing a fire or an explosion, e.g. in the presence of flammable liquids, gasses, or dust.
  • Page 5 Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable for another sawmill may create a risk of injury when used on the TMG-PSM36 sawmill.
  • Page 6 Always operate machine with all safety devices and guards in place and in working order. DO NOT modify or make changes to safety devices. DO NOT operate machine if any safety devices or guards are missing or inoperative. Never leave sawmill running unattended. Coiled blades can spring apart with considerable force and unpredictably in any direction.

  • Page 7: General Maintenance Information

    GENERAL MAINTENANCE INFORMATION Proper and routine maintenance is critical to operator safety, achieving good milling results and to prolonging the life of your investment. 1. Band wheel Bearings — Should be inspected before use to ensure they are not worn. Bearings are sealed and do not need to be greased.

  • Page 8: Inspection

    Hexagon flange bolts M10*30 Guide rail beam 1.2m Hexagon lock nut M10 Hexagon nut M20 Note: If you have purchased TMG-PSM36-Mjack, do not Leveling feet M20 need to install the foot, directly install the trailer jack seat Rail connecting plate...
  • Page 9 2. Connect the two components installed in the first step, two reinforcement plates and a middle crossbeam are needed in this step. PART NO. DESCRIPTION Hexagon flange bolts M10*30 Hexagon lock nut M10 Reinforcement plate Middle crossbeam 3. Bolt the guide rails , anti roll plate and limit plate to the base, the anti roll plate is under the guide rail. PART NO.

  • Page 10: Log Dog & Supports

    5. Install hydraulic jack seat and hydraulic jack as shown in the figure. PART NO. DESCRIPTION Hexagonal flange bolt M10X30 Hexagon flange nuts M10 Jack adjustment shaft welding T-screw M10*40 Hydraulic jack 1Ton Hydraulic jack seat #3 – LOG DOG & SUPPORTS 1.
  • Page 11 2. Insert vertical support into crossbeam plate and secure with T-screw. PART NO. DESCRIPTION Vertical support T-screw M10X40 We recommend tex screwing the leveling legs to sleepers once the mill has been made level. So before tex screwing the mill to the sleepers, it is highly recommended that you run a string line down both sides of the mill, to make sure the track is straight and level.

  • Page 12: Carriage Assembly

    #4 – CARRIAGE ASSEMBLY 1. Place a moving blanket on the shipping pallet that the sawmill crate was strapped to. The blanket will prevent the blade guard covers from becoming scratched. Using a minimum of two people or a mechanical advantage system, remove the head assembly from the sawmill crate and place face down on the blanket.
  • Page 13 4. Install the wheel assembly onto the lifting square tube as shown in the figure, secure it with the provided bolts and nuts. PART NO. DESCRIPTION Plain washer Ø12 Non-metallic insert hex lock nut Hexagon head bolt M12X80 half wire B109 Left wheel assembly Right wheel assembly...
  • Page 14 6. Install the connecting clamping plate, uper arch and steel cable roller,using wrench to hold the nut, tighten the bolt PART NO. DESCRIPTION Plain washer Ø12 Hex nut M10 Plain washer Ø10 Non-metallic insert hex lock nut Lifting wheel Hexagon head bolt M10X75 half wire Connecting plate 3 Connecting plate 1...
  • Page 15 8. Install the lifting system,using wrench to hold the nut ,tighten the bolt. B111 PART NO. DESCRIPTION Hex nut M10 Plain washer Ø10 Hexagon head bolt M10X75 half wire Hexagon head bolt M10X95 Pulley frame seat Lifting system B111...
  • Page 16 9. Place the measuring scale assembly, the assembly include ruler and height indicator. A. install ruler,using wrench to hold the nut ,tighten the bolt. B. Install the square indicator rod to the sawmill using the two bolts and tighten. Slide the scale indicator over the square rod and tighten.
  • Page 17 10. Install the push handle onto the rear post of the machine using provided U-bolts and nuts, the installation height can be adjusted. Tighten the nuts in a position suitable for the operator. B112 B102 PART NO. DESCRIPTION Hex nut M10 Plain washer Ø10 Spring washer Ø10 U-bolt...
  • Page 18 11. Install the water tank onto the upper crossbeam as shown in the figure, using the provided fasteners. PART NO. DESCRIPTION Hexagon head bolt M8X105 Water tank rack Water tank Plain washer Ø8 Hex nut M8 12. Install the fuel tank bracket onto the machine using the provided fasteners. PART NO.
  • Page 19 13. When the installation of the machine is completed, use lifting equipment such as forklifts and cranes to lift the machine head onto the installed track. Be cautious when taking this step. 14. Install the anti roll hook using provided fasteners. PART NO.
  • Page 20 15. Route the cables on both sides as shown in the below image.
  • Page 21 16. Connect the water pipe. After the connection is completed, check to ensure that there is no water leakage at the joints. Please Note: We recommend adding some dishwashing liquid to the tank to help lubricate the wood – two to three capfuls.
  • Page 22 17. Connect the oil pipe as shown in the figure, a pliers is required at this step.
  • Page 23 18. Add waterproof grease to the threads of the blade tension “T” handle and to the washer face that it meets before use. Proper blade tension is achieved when the blade deflects no more than a total of 1/8” - 1/4” up/down. *Note –...
  • Page 24 20. Push the saw head up and down the track system to ensure that the width of the track allows for the saw head to move freely. If it binds, the “L” rails will need to be set further or closer together to achieve a consistent width along the entire track system.

  • Page 25: Electric Wire Connect

    #5 – ELECTRIC WIRE CONNECT 1. Find the show 1 and 3 connection terminals on gas engine 2. Find the electric card of the Emergency Stop Switch and the Microswitch 3. Connect the 1 and 1, 2 and 2, 3 and 3 4.
  • Page 26 #6– ENGINE Refer to the engine manual before using your sawmill. Please note that the engine does not contain any petrol or engine oil when it is shipped. Furthermore, the engine is equipped with an oil alert system, meaning that if the crankcase oil level is low or empty, the power is cut to the spark plug and it will not start.

  • Page 27: Sawmill Set-Up Procedures

    SAWMILL SET-UP PROCEDURES #1 – BELT TENSION To check the belt tension, with your hand, firmly try to deflect the belt up and down. There should be no more than 1/4” of deflection in both directions (1/2” total). If the belt deflects more than this, it will need to be tightened as described below.

  • Page 28: Blade Tracking

    Now that the engine is free to slide on the engine mounting plate, turn the 16mm nut on the horizontal stud in the clockwise direction. This will pull the engine towards the stud and apply more tension on the belt. Do this step incrementally while checking the belt for proper deflection.
  • Page 29 Loosen the blade guide assembly bolt with a socket. The round shaft should now be free to slide rearward and out of the way. Perform this step on both guide assemblies. This will ensure that the guide bearings do not influence tracking of the blade while adjusting.
  • Page 30 The alignment bolt can now be turned to change the angle of the bandwheel and track the blade. To move the blade more rearward on the bandwheel, this bolt will need to be turned clockwise. Alternatively, turning the bolt in the counter-clockwise direction would force the blade to run more forward on the bandwheel.
  • Page 31 Adjusting The Left Hand Side Vertical Bolt Vertical Nut Bottom Bottom Vertical Nut Vertical Bolt To adjust the left side of the sawmill, again start by taking the tension off of the blade by turning the “T” handle one turn in the counter-clockwise direction. Using a 16mm wrench, loosen the “ vertical nut ” a ½ turn. Do the same on the “bottom vertical nut”...

  • Page 32: Blade Guide Adjustment

    Moving The Blade Rearward Using a 16mm wrench, hold the “horizontal bolt” stationary with a wrench and turn the “horizontal outside nut” counter-clockwise a ½ turn. Still holding the “horizontal bolt” stationary, turn the “horizontal inside nut” clockwise a ½ turn. This step has now shifted the “horizontal bolt” and bandwheel shaft, causing the blade to track more forward.

  • Page 33: Blade Tension

    Saw Chuck Shaft Seat Saw Block Thickness of a sheet of paper Saw Blade Thickness of a sheet of paper Loosen the blade guide assembly bolt with a 16mm socket. The round shaft should now be free to slide back and forth.
  • Page 34 When tensioning the blade, make sure the tracking adjustment bolt sitting behind the T handle (pictured) is sitting back in its recess after you have finished and before the mill is run. Failure to do this will result in the blade being thrown and possibly broken.

  • Page 35: Sawmill Maintenance

    SAWMILL MAINTENANCE #1 – CHANGING THE BLADE Never attempt the below with the engine running. As a safety precaution, remove the spark plug cap. Gloves and safety glasses must be worn when changing the blade. Remove the tension in the blade by turning the “T” handle in the counter-clockwise direction and then open the blade guard cover.
  • Page 36 Remove the tension in the blade by turning the “T” handle in the counter-clockwise direction and then open the blade guard cover. The blade should now be loose and free to pull straight out the front. To change the drive side belt, loosen the four bolts that secure the engine to the engine mount using a 16mm wrench.

  • Page 37: Troubleshooting

    TROUBLESHOOTING Problem/Issue Possible Causes Resolution Options Inadequate blade tension. Tighten blade. Refer to page 32. Producing wavy cuts. Improper blade guide set Gap between guide blocks and blade are incorrect. Refer to page 31. Improper blade tracking. Adjust blade tracking. Refer to page 27. Sap build up on blade.

  • Page 38: Diagrams-Ensemble
