Weighing systems
Load cells
SIWAREX WL200
Operating Instructions
7MH5102 / 7MH5103 / 7MH5104 / 7MH5105 /
7MH5106 / 7MH5107 / 7MH5108 / 7MH5110 /
7MH5111 / 7MH5113 / 7MH5114 / 7MH5117 /
7MH5118 / 7MH5120 / 7MH5121 / 7MH5122 /
7MH5134
07/2024
A5E02199611B-14
Introduction
Safety instructions
Description
Installing
Connecting
Commissioning
Service and maintenance
Error messages and
troubleshooting
Technical data
Dimension drawings
Product documentation
and support
1
2
3
4
5
6
7
8
9
10
A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7MH5134 and is the answer not in the manual?

Questions and answers

Related Manuals for Siemens 7MH5134

Summary of Contents for Siemens 7MH5134

  • Page 1 Dimension drawings Product documentation and support 7MH5102 / 7MH5103 / 7MH5104 / 7MH5105 / 7MH5106 / 7MH5107 / 7MH5108 / 7MH5110 / 7MH5111 / 7MH5113 / 7MH5114 / 7MH5117 / 7MH5118 / 7MH5120 / 7MH5121 / 7MH5122 / 7MH5134 07/2024 A5E02199611B-14...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Table of contents Introduction ............................7 Purpose of this documentation .................... 7 Document history ........................ 7 Checking the consignment....................7 Cybersecurity information ....................7 Transportation and storage ....................8 Notes on warranty ....................... 9 Safety instructions ..........................11 Prerequisites for safe use....................11 2.1.1 Laws and directives ......................
  • Page 4 Table of contents 6.2.1 Planning ..........................31 6.2.2 Transverse forces and overload protection ................33 6.2.3 Lengthening and shortening the connecting cable ............. 35 Adjustment and initial commissioning................37 6.3.1 Height compensation......................37 6.3.1.1 When is height compensation necessary?................37 6.3.1.2 Procedure for height compensation..................
  • Page 5 Table of contents Approval to OIML R60 ......................74 Electromagnetic compatibility .................... 75 Certificates and approvals for explosion protection ............. 75 Dimension drawings ..........................77 10.1 SIWAREX WL260 SP-S AA....................77 10.2 SIWAREX WL260 SP-S AB ....................78 10.3 SIWAREX WL260 SP-S AE ....................78 10.4 SIWAREX WL260 SP-S CA....................
  • Page 6 Table of contents SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 7: Introduction

    Risk of explosion in hazardous areas. • Do not use damaged or incomplete devices. Cybersecurity information Siemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 8: Transportation And Storage

    Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure...

  • Page 9: Notes On Warranty

    The content reflects the technical status at the time of publishing. Siemens reserves the right to make technical changes in the course of further development.
  • Page 10 Introduction 1.6 Notes on warranty SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 11: Safety Instructions

    Safety instructions Prerequisites for safe use This device left the factory in good working condition. In order to maintain this status and to ensure safe operation of the device, observe these instructions and all the specifications relevant to safety. Observe the information and symbols on the device. Do not remove any information or symbols from the device.

  • Page 12: Improper Device Modifications

    Note Operation under special ambient conditions We highly recommend that you contact your Siemens representative or our application department before you operate the device under special ambient conditions as can be encountered in nuclear power plants or when the device is used for research and development purposes.
  • Page 13 Safety instructions 2.4 Use in hazardous areas WARNING Use in hazardous area Risk of explosion. • Only use equipment that is approved for use in the intended hazardous area and labeled accordingly. • Do not use devices that have been operated outside the conditions specified for hazardous areas.

  • Page 14: Damage To Load Cells, Measurement Errors

    IS CL I, ZN 0, AEx/Ex ia IIC T4 Ga UK Importer : II 3G Ex nA IIC T4 Gc CL I,II,III, DIV 2, GP A,B,C,D,F,G, T4 Siemens plc, Manchester M20 2UK, UK US & CA II 3D Ex tc IIIC T73°C Dc CL I, ZN2, GP IIC T4 Refer to manual -20°C ≤...
  • Page 15 Safety instructions 2.6 Specific conditions of use Note The use of multiple entity-Approved/Certified associated apparatus / barriers which have not been Approved/Certified in combination with one another is restricted to the following conditions: • The associated apparatus /barriers shall all have DC outputs of the same polarity. •...
  • Page 16 Safety instructions 2.6 Specific conditions of use SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 17: Description

    Description Range of application SIWAREX load cells are used for measuring forces and weights statically and dynamically. You can use SIWAREX load cells for almost all applications in industrial weighing technology. Examples include: • Container weighers, hopper scales or platform scales, •...
  • Page 18 Description 3.2 Design and principle of operation Principle of operation The basic component in each case is a special type of spring body. The application of force elastically deforms the spring body. The ohmic resistance of the strain gauges changes as a result.

  • Page 19: Nameplate Layout

    IS CL I, ZN 0, AEx/Ex ia IIC T4 Ga CL I,II,III, DIV 2, GP A,B,C,D,F,G, T4 II 3G Ex nA IIC T4 Gc Siemens plc, Manchester M20 2UK, UK US & CA II 3D Ex tc IIIC T73°C Dc...
  • Page 20 Description 3.3 Nameplate layout See also Adjustment and initial commissioning (Page 37) Design of nameplate with NEPSI approval ① Ex marking (NEPSI) ② Types of protection according to NEPSI Figure 3-6 NEPSI nameplate SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 21: Installing

    Installing Basic safety instructions Load cells are precision components and must therefore be handled carefully. Particular care must be taken during transport and installation. DANGER Danger to life from falling loads • Load cells are not machine components which have been constructed with the normal safety factors.

  • Page 22: Procedure For Mounting The Device

    The mounting components normally allow so much room for movement that heat expansion will not result in lateral loading. • Protect the load cell against higher impact energy levels by using Siemens mounting accessories. NOTICE Destruction of load cells Proceed carefully with installation.

  • Page 23: Mounting A Load Cell With Hygienic Design

    Installing 4.3 Mounting a load cell with hygienic design Mounting a load cell with hygienic design NOTICE Observe the following points when mounting the load cell: • Make sure that overloading of the load cell capacity is prevented at all times. If possible, install mechanical overload protection.

  • Page 24: Dismantling

    Installing 4.4 Dismantling Installation instructions 1. Fasten the bottom of the load cell using the respective mounting holes. Dimension drawing (Page 92) ③ To avoid microbial contamination, the gap between the bottom of the load cell and the lower mounting plate must be sealed. The sealing ring has FDA approval (silicone rubber RH200-50).

  • Page 25: Connecting

    Connecting Basic safety instructions WARNING Insufficient isolation of intrinsically safe and non-intrinsically safe circuits Risk of explosion in hazardous areas. • When connecting intrinsically safe and non‑intrinsically safe circuits ensure that isolation is carried out properly in accordance with local regulations for example IEC 60079-14. •...

  • Page 26: Connecting Principle

    Connecting 5.2 Connecting principle Connecting principle Load cells can be equipped with connecting cables with four or six cores. WARNING Risk of explosion Please observe that in the case of shielded cables of intrinsically safe circuits in hazardous areas only one grounding is permissible. If grounding is to be on both sides an equipotential bonding conductor with at least 4 mm²...
  • Page 27 Connecting 5.2 Connecting principle Load cells with four-wire system Do not shorten or length connecting cables in the four-wire system, because the cable resistance is temperature compensated. When the length of the connecting cable is altered, the input and output resistances change. This change can be corrected by adjusting the scale, but temperature-dependent resistance changes are not compensated for the missing or additional length of cable.
  • Page 28 Connecting 5.2 Connecting principle Load cells with six-wire system For connecting cables in the six-wire system, the supply voltage is fed back to the weighing module as the reference voltage. Shortening or lengthening has no effect on the measuring result. Figure 5-2 Connecting principle for load cells with six-wire system SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 29: Connecting Up

    Connecting 5.3 Connecting up Connecting up Signal assignment for the load cell connecting cables Identifying colors and signal assignment for the connecting cables of load cells not listed: See the data sheet for the appropriate load cell. Table 5-1 Signal assignment for the load cell connecting cables Load cell Function/color of connecting cable EXC+...
  • Page 30 Connecting 5.3 Connecting up Load cell Function/color of connecting cable EXC+ EXC- SIG+ SIG- Sense+ Sense- Shield not connected to the load cell body SIWAREX WL280 Pink Gray Brown White n.a. n.a. Trans‐ RN-S SA parent SIWAREX WL290 Black Green White n.a. n.a.

  • Page 31: Commissioning

    Commissioning Basic safety instructions WARNING Improper commissioning in hazardous areas Device failure or risk of explosion in hazardous areas. • Do not commission the device until it has been mounted completely and connected in accordance with the information in Technical data (Page 51). •...
  • Page 32 Commissioning 6.2 Application planning Parallel connection of load cells In weighing systems, one or more load cells are connected to a weighing module for evaluation of the measured signal. Several load cells of a scale are connected in parallel to a junction box to supply a joint output signal.

  • Page 33: Transverse Forces And Overload Protection

    Commissioning 6.2 Application planning Grounding protection NOTICE Damaging of load cells Undesirable electrical currents can arise during welding or lightning. To protect the load cells against such currents, bridge the load cells using highly flexible grounding cables. 6.2.2 Transverse forces and overload protection Overloading of load cells NOTICE Risk of overloading...
  • Page 34 Commissioning 6.2 Application planning Dimensioning for overload When step changes in load cannot be excluded during measuring, for example, due to application of a load in free fall, you must take appropriate precautions to avoid damage to the load cell, e.g. by using elastomer bearings or load cells dimensioned for higher rated loads. When dimensioning load cells, include a safety margin to guard against overloading: •...

  • Page 35: Lengthening And Shortening The Connecting Cable

    Commissioning 6.2 Application planning 6.2.3 Lengthening and shortening the connecting cable Load cells can be equipped with connecting cables with four or six cores. Note Measurement errors Connecting cables are only permitted to be extended using electro-magnetically compatible housings, such as the SIWAREX JB junction box. Single load cells If a scale is equipped with a single load cell, the scale can be directly connected to the weighing module if space permits.
  • Page 36 For connecting the junction box to the weighing module, to extend a load cell connecting cable or for cross-connection of two junction boxes, a shielded, six-core cable must be used, e.g. Li2Y2x0.75St+2x(2x0.34St)-CY Siemens Order No.: 7MH4 702‑8AG or, for intrinsically safe Ex applications, 7MH4 702‑8AF.

  • Page 37: Adjustment And Initial Commissioning

    Commissioning 6.3 Adjustment and initial commissioning Adjustment and initial commissioning WARNING Missing type of protection and loss of approval If the load cell is not operated with an intrinsically safe power supply, the type of protection - intrinsically safe is no longer guaranteed and the intrinsically safe approval may be revoked. Permanently erase, therefore, the irrelevant types of protection on the rating plate before commissioning, so that erroneous deployment can be avoided.

  • Page 38: Initial Commissioning

    Commissioning 6.3 Adjustment and initial commissioning 6.3.2 Initial commissioning 1. Align the load cell site horizontally and level over the complete area. 2. Clean the load cell site and load cell base until both are absolutely clean. 3. Grease the contact surfaces of the force transfer elements with bearing grease. 4.

  • Page 39: Example For Corner Load Adjustment

    Commissioning 6.3 Adjustment and initial commissioning The corner load errors can be electrically compensated. This is done by matching the individual measured values to the smallest measured value by connecting additional resistors. For details of how to do this see section Example for corner load adjustment (Page 39) ...
  • Page 40 Commissioning 6.3 Adjustment and initial commissioning Procedure 1. Measure the output resistances R of the load cells LC. Alternatively: Use the values from the corresponding data sheet. Example: Load cells Example values LC 1: 1004.52 Ω LC 2: 1003.64 Ω LC 3: 1010.70 Ω LC 4: 1028.12 Ω 2. Place the test weight on all four corners: Note the measured values Load cells Example values LC 1:...
  • Page 41 Commissioning 6.3 Adjustment and initial commissioning 4. Calculate the compensating resistance: Use the following formula: Determined compensation resistance, to be connected in the signal cable SIG+ Output resistance of the load cells; can also be measured under load Weight error: Differential value from the lowest weight value Test load;...
  • Page 42 Commissioning 6.3 Adjustment and initial commissioning SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 43: Service And Maintenance

    Service and maintenance Basic safety instructions Servicing and maintenance of the load cells The load cells are in general maintenance free. Regular inspection and checking of the mechanisms for force transfer, oscillation limitation, lifting and overloading will however improve their reliability. The inspections should also be performed after serious environmental events such as storms, floods or earthquakes.

  • Page 44: Cleaning A Load Cell With Hygienic Design

    Service and maintenance 7.3 Return procedure 7.2.1 Cleaning a load cell with hygienic design The hygienic load cell is suitable for food, medical and biological applications. The load cell corresponds to the EHEDG design principles and is therefore easy to clean and designed in such a way that liquids drain away unimpeded.

  • Page 45: Disposal

    Service and maintenance 7.4 Disposal Required forms • Delivery note • Return document (http://www.siemens.com/processinstrumentation/returngoodsnote) with the following information: – Product (item description) – Number of returned devices/replacement parts – Reason for returning the item(s) • Decontamination declaration (http://www.siemens.com/sc/declarationofdecontamination) With this declaration you warrant "that the device/replacement part has been carefully cleaned and is free of residues.
  • Page 46 Service and maintenance 7.4 Disposal SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 47: Error Messages And Troubleshooting

    Error messages and troubleshooting Repair Note Unnecessary costs for repairs Please only return faulty load cells to our repair center accompanied by an accurate description of the fault. This simplifies the diagnostics. Error messages Rated load exceeded If load cells are loaded beyond their rated load, this can result in an error message in the weighing module.

  • Page 48: Checking The Load Cells

    Error messages and troubleshooting 8.4 Checking the load cells Checking the load cells NOTICE Damaging of load cells Do not use an Ohmmeter to measure resistances that feeds a higher voltage into the load cell than is permitted in the specifications. Locate and check faulty load cells 1.

  • Page 49: Measures In The Event Of Overloaded Load Cells

    Error messages and troubleshooting 8.5 Measures in the event of overloaded load cells Measure the input and output resistance 1. Disconnect the load cell. 2. Measure the input voltage between EXC+ and EXC-. 3. Measure the output voltage between SIG+ and SIG-. The resistances must correspond to the values specified in the data sheet or in the specifications.
  • Page 50 Error messages and troubleshooting 8.5 Measures in the event of overloaded load cells SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 51: Technical Data

    Technical data Functional data 9.1.1 SIWAREX WL260 SP-S AA Table 9-1 Technical specifications SIWAREX WL260 SP-S AA Variable Value Type series WL260 Designation SP-S AA Construction type Single-point load cell Possible applications Platform scales, small conveyor scales Rated load E 3; 5; 10; 20; 50; 100 kg Accuracy class according to OIML R60 Max.

  • Page 52: Siwarex Wl260 Sp-S Ab

    Technical data 9.1 Functional data Variable Value Degree of protection according to EN 60 529 IP65 Maximum tightening torque of the fixing screws 15 ... 20 Nm Cable connection Six-core, shielded PVC cable 3 m 9.1.2 SIWAREX WL260 SP-S AB Table 9-2 Technical data SIWAREX WL260 SP-S AB Variable Value Type series...

  • Page 53: Siwarex Wl260 Sp-S Ca

    Technical data 9.1 Functional data Variable Value Maximum tightening torque of the fixing screws 35 ... 40 Nm Cable connection Six-core, shielded PVC cable 3 m SIWAREX WL260 SP-S AB is not approved for legal-for-trade operation. 9.1.3 SIWAREX WL260 SP-S CA Table 9-3 Technical specifications SIWAREX WL260 SP-S CA Variable Value Type series...

  • Page 54: Siwarex Wl260 Sp-S Ae

    Technical data 9.1 Functional data Variable Value Degree of protection according to EN 60 529 IP67 Maximum tightening torque of the fixing screws 166 Nm Cable connection Six-core, shielded PVC cable 3 m 9.1.4 SIWAREX WL260 SP-S AE Table 9-4 Technical data SIWAREX WL260 SP-S AE Variable Value Type series...

  • Page 55: Siwarex Wl260 Sp-S Sa

    Technical data 9.1 Functional data Variable Value Maximum tightening torque of the fixing screws 1.3 Nm Cable connection Four-core, shielded PVC cable 0.4 m SIWAREX WL260 SP-S AE is not approved for legal-for-trade operation 9.1.5 SIWAREX WL260 SP-S SA Table 9-5 Technical data SIWAREX WL260 SP-S SA Variable Value Type series...

  • Page 56: Siwarex Wl260 Sp-S Sb

    Technical data 9.1 Functional data Variable Value Degree of protection according to EN 60 529 IP67 Maximum tightening torque of the fixing screws   for E = 5; 10; 20; 50; 100 kg 14 Nm for E = 200 kg 16 Nm Cable connection Six-core, shielded PU cable 1 m 9.1.6 SIWAREX WL260 SP-S SB...

  • Page 57: Siwarex Wl260 Sp-S Sc

    Technical data 9.1 Functional data Variable Value Insulation resistance R ≥ 5000 MΩ at 50 V DC Rated temperature range B - 10 to + 40 °C Operating temperature range B - 35 to + 65 °C Storage temperature range B - 35 to + 65 °C Sensor material Stainless steel, mat. no. 1.4542 Degree of protection according to EN 60 529 IP68 Cable connection Six-core, shielded PU cable...

  • Page 58: Siwarex Wl250 St-S Sa

    Technical data 9.1 Functional data Variable Value Rated measuring path h   For E = 10 kg: ≤ 0.03 mm For E = 20 kg: ≤ 0.08 mm For E = 50 kg: ≤ 0.15 mm For E = 100 kg: ≤ 0.12 mm For E = 200 kg: ≤ 0.15 mm For E = 300 kg: ≤ 0.18 mm For E = 400 kg:...
  • Page 59 Technical data 9.1 Functional data Variable Value Possible applications Tension and compression applications, suspended scales, hybrid scales, container scales Rated load E 50; 100; 250; 500 kg 1; 2.5; 5; 10 t Accuracy class according to OIML R60 Max. scale interval n 3000 Min. scale interval V  ...

  • Page 60: Siwarex Wl230 Bb-S Sa

    Technical data 9.1 Functional data 9.1.9 SIWAREX WL230 BB-S SA Table 9-9 Technical data SIWAREX WL230 BB-S SA Variable Value Type series WL230 Designation BB-S SA Construction type Bending beam Possible applications Platform scales, overhead rail scales, container weighers, conveyor scales Rated load E 10; 20; 50; 100; 200; 500 kg Accuracy class according to OIML R60 Max.

  • Page 61: Siwarex Wl230 Sb-S Ca

    Technical data 9.1 Functional data 9.1.10 SIWAREX WL230 SB-S CA Table 9-10 Technical data SIWAREX WL230 SB-S CA Variable Value Type series WL230 Designation SB-S CA Construction type Shear beam Possible applications Platform scales, overhead rail scales, container scales, conveyor scales Rated load E 100; 250; 500 kg 1; 2; 3; 5; 10 t Accuracy class according to OIML R60...

  • Page 62: Siwarex Wl230 Sb-S Sa

    Technical data 9.1 Functional data Variable Value Operating temperature range B -35 to +65 °C Storage temperature range B -40 to +80 °C Sensor material Steel, nickel-plated Degree of protection according to EN 60 529 IP67 Maximum tightening torque for the fixing bolts for E = 100; 250; 500 kg, 1 t, 2 t 75 Nm for E = 3;...

  • Page 63: Siwarex Wl270 Cp-S Sa

    Technical data 9.1 Functional data Variable Value Rated measuring path h   For E = 500 kg: 0.13 mm For E = 1 t: 0.21 mm For E = 2 t: 0.29 mm For E = 5 t: 0.38 mm Recommended supply voltage 5 to 12 V DC Rated characteristic value C 2.0 ± 0.002 mV/V  1)

  • Page 64: Siwarex Wl270 Cp-S Sb

    Technical data 9.1 Functional data Variable Value Temperature coefficient Characteristic value T 0.017% C / 10 K Zero signal T 0.023% C / 10 K Min. initial loading E 0 kg Maximum working load L 150% E Break load L 300% E Maximum lateral load L 75% E Rated measuring path h at E...

  • Page 65: Siwarex Wl270 Cp-S Sc

    Technical data 9.1 Functional data Variable Value Temperature coefficient Characteristic value T 0.017% C / 10 K Zero signal T 0.023% C / 10 K Min. initial loading E 0 kg Maximum working load L 150% E Break load L 300% E Maximum lateral load L 10% E Rated measuring path h at E...

  • Page 66: Siwarex Wl270 K-S Ca

    Technical data 9.1 Functional data Variable Value Maximum working load L 150% E Break load L 300% E Maximum lateral load L 10% E Rated measuring path h at E 0.36 mm Recommended supply voltage 5 to 12 V DC Rated characteristic value C 2.0 ± 0.02 mV/V Rated Tolerance of zero signal D...
  • Page 67 Technical data 9.1 Functional data Variable Values Maximum working load L 120% E Break load L 300% E Maximum lateral load L 10% E Rated measuring path h at E 0.23 to 3.11 mm Supply voltage Recommended 5 to 12 V DC   Maximum 15 V Rated characteristic value C 1.5 ± 0.008 mV/V Rated Tolerance of zero signal D...
  • Page 68 Technical data 9.1 Functional data Variable   Values Min. initial loading E   0 t Hysteresis   ≤ ± 0.300% C  ≤ ± 0.500 % C ≤ ± 2.000% C Creep error F 30 min ≤ ± 0.300% C  ≤ ± 0.400 % C ≤ ± 4.000% C Temperature coefficient Characteristic value T ≤ ± 0.250% C / 5 °C ≤ ± 0.250% C / 5 °C ≤ ± 0.500% C / 5 °C Zero signal T ≤ ± 0.250% C / 5 °C ≤ ± 0.500% C / 5 °C...

  • Page 69: Siwarex Wl270 Cp-H Sd

    Technical data 9.1 Functional data 9.1.16 SIWAREX WL270 CP-H SD Table 9-17 Technical specifications SIWAREX WL270 CP-H SD Variable Value Type series WL270 Designation CP-H SD Construction type Hygienic compression load cell Possible applications Hygienic applications Rated load (E 5; 10; 20 t Accuracy class Max.

  • Page 70: Siwarex Wl280 Rn-S Sa

    Technical data 9.1 Functional data Table 9-18 Product features Designation Value Components Load cell Material Stainless steel EN 1.4542   RH200-50 (sealing ring, coating cup) Silicon rubber H9300 (filler) Silicone Estane R190-5 (cable jacket) Polyurethane Weight of load cell 2.9 kg Degree of protection according to EN 60 529 IP68 Maximum tighten‐...
  • Page 71 Technical data 9.1 Functional data Variable Value Max. scale interval n 3000 Minimum scale interval V for E = 0.06; 0.13; 0.28 t  / 16000 for E = 0.5; 1; 2; 3.5; 5; 10; 13; 28; 60 t  / 17500 Combined error F ≤ ± 0.02% C comb Min.

  • Page 72: Siwarex Wl290 Db-S Ca

    Technical data 9.1 Functional data Variable Value Degree of protection acc. to EN 60 529, IEC 60529 IP66 and IP68 Maximum tightening torque for fixing screws for E = 0.06; 0.13; 0.28 t 8 Nm for E = 0.5; 1; 2; 3.5; 5 t 14 Nm 10 Nm for E = 10 t...
  • Page 73 Technical data 9.1 Functional data Variable Value Rated measuring path h   For E = 2.3 t: 0.5 mm For E = 4.5 t: 0.6 mm For E = 9.1 t: 1.1 mm For E = 13.6 t: 0.5 mm For E = 18 t: 0.5 mm For E = 23 t: 0.5 mm For E = 27 t:...

  • Page 74: Energy Limitation Parameters

    Technical data 9.3 Approval to OIML R60 Energy limitation parameters Load cell type Type of protection ia and ic WL230 BB-S SA  = 20 V DC  = 20 V DC  = 20 V DC -20 °C ≤ T  ≤ +40 °C WL230 SB-S SA  = 420 mA -20 °C ≤ T  ≤ +40 °C WL230 SB-S CA  = 4.2 W WL250 ST-S SA  = 40 µH WL260 SP-S SA  = 12 nF WL260 SP-S SB -20 °C ≤ T  ≤ +40 °C WL260 SP-S SC...

  • Page 75: Electromagnetic Compatibility

    Technical data 9.5 Certificates and approvals for explosion protection The above statements do not apply to load cells outside the standard product range. Descriptions of load cell variants that are not included in the standard product range can be found on the appropriate data sheet. Electromagnetic compatibility To maintain the electromagnetic compatibility: •...
  • Page 76 Technical data 9.5 Certificates and approvals for explosion protection Explosion protection   SIWAREX WL230 BB-S SA SIWAREX WL280 RN-S SA SIWAREX WL230 BB-S SA SIWAREX WL230 BB-S SA SIWAREX WL230 SB-S SA SIWAREX WL230 SB-S SA SIWAREX WL230 SB-S SA SIWAREX WL250 ST-S SA SIWAREX WL270 CP-S SA SIWAREX WL230 SB-S CA SIWAREX WL260 SP-S SA...

  • Page 77: Dimension Drawings

    Dimension drawings The dimensions in the dimension drawings are in mm. 10.1 SIWAREX WL260 SP-S AA Figure 10-1 SIWAREX WL260 SP-S AA dimension drawing Threaded holes Designation Thread Thread depth ① 15 mm SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 78: Siwarex Wl260 Sp-S Ab

    Dimension drawings 10.3 SIWAREX WL260 SP-S AE 10.2 SIWAREX WL260 SP-S AB Figure 10-2 SIWAREX WL260 SP-S AB dimension drawing 8 threaded holes Designation Thread Thread depth ① 15 mm 10.3 SIWAREX WL260 SP-S AE Figure 10-3 Dimension drawing of SIWAREX WL260 SP-S AE SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 79: Siwarex Wl260 Sp-S Ca

    Dimension drawings 10.4 SIWAREX WL260 SP-S CA 10.4 SIWAREX WL260 SP-S CA   50 kg ∼ 1 t 1.5 t ∼ 2 t 150 (5.91) 150 (5.91) 77 (3.03) 88 (3.46) 46 (1.81) 55 (2.17) 68 (2.68) 76 (2.99) 38 (1.50) 42 (1.65) Figure 10-4 Dimension drawing SP-S CA, dimensions in mm (inch) SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 80: Siwarex Wl260 Sp-S Sa

    Dimension drawings 10.5 SIWAREX WL260 SP-S SA 10.5 SIWAREX WL260 SP-S SA Figure 10-5 SIWAREX WL260 SP-S SA dimension drawing Threaded holes Designation Thread Thread depth Hole depth ① 15 mm 18 mm SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 81: Siwarex Wl260 Sp-S Sb

    Dimension drawings 10.6 SIWAREX WL260 SP-S SB 10.6 SIWAREX WL260 SP-S SB Figure 10-6 Dimensional drawing SIWAREX WL260 SP-S SB Rated load in kg 6  12  30  60  A in mm 18.5 18.5 18.5 23.5 Threaded holes M6x1, 8 mm deep SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 82: Siwarex Wl260 Sp-S Sc

    Dimension drawings 10.7 SIWAREX WL260 SP-S SC 10.7 SIWAREX WL260 SP-S SC Figure 10-7 Dimension drawing SIWAREX WL260 SP-S SC 10 ... 50 kg Figure 10-8 Dimension drawing SIWAREX WL260 SP-S SC 100 ... 500 kg SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 83: Siwarex Wl250 St-S Sa

    Dimension drawings 10.8 SIWAREX WL250 ST-S SA 10.8 SIWAREX WL250 ST-S SA Figure 10-9 SIWAREX WL250 ST-S SA dimension drawing Rated load Dimensions in mm   50 kg, 50.8 61.0 11.7 15.1 100 kg 250 kg, 50.8 61.0 18.0 21.4 500 kg 1 t 50.8 61.0 24.4 27.8...

  • Page 84: Siwarex Wl230 Bb-S Sa

    Dimension drawings 10.9 SIWAREX WL230 BB-S SA 10.9 SIWAREX WL230 BB-S SA Figure 10-10 SIWAREX WL230 BB-S SA dimension drawing Rated load d in mm D in mm H in mm 10; 20; 50; 100; 200 kg 500 kg 10,3 SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 85: Siwarex Wl230 Sb-S Ca

    Dimension drawings 10.10 SIWAREX WL230 SB-S CA 10.10 SIWAREX WL230 SB-S CA Figure 10-11 Dimensional drawing SIWAREX WL230 SB-S CA Rated Dimensions in mm load Ø F   0.1 t ... 2.0 15.8 25.4 76.2 31.8 13.5 15.8 31.8 54.2  t 3.0 t to 5.0 171.5 19.1 38.1...

  • Page 86: Siwarex Wl230 Sb-S Sa

    Dimension drawings 10.11 SIWAREX WL230 SB-S SA 10.11 SIWAREX WL230 SB-S SA Figure 10-12 SIWAREX WL230 SB-S SA dimension drawing Rated Dimensions in mm load   500 kg 25,4 20,5 1.0 t 25,4 20,5 2.0 t 25,4 20,5 5.0 t 38,1 20,5 30,2 SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 87: Siwarex Wl270 Cp-S Sa

    Dimension drawings 10.12 SIWAREX WL270 CP-S SA 10.12 SIWAREX WL270 CP-S SA Figure 10-13 SIWAREX WL270 CP-S SA dimension drawing Rated load Dimensions in mm   0.5 t; 1 t; 2 t; 5 t; 10 t; 20 t; 30 t 50 t SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 88: Siwarex Wl270 Cp-S Sb

    Dimension drawings 10.13 SIWAREX WL270 CP-S SB 10.13 SIWAREX WL270 CP-S SB Figure 10-14 SIWAREX WL270 CP-S SB dimension drawing SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 89: Siwarex Wl270 Cp-S Sc

    Dimension drawings 10.14 SIWAREX WL270 CP-S SC 10.14 SIWAREX WL270 CP-S SC Figure 10-15 SIWAREX WL270 CP-S SC dimension drawing SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 90: Siwarex Wl270 K-S Ca

    Dimension drawings 10.15 SIWAREX WL270 K-S CA 10.15 SIWAREX WL270 K-S CA Single Figure 10-16 Dimension drawing for SIWAREX WL270 K-S CA Rated load Dimensions in mm   ∅d ∅D 1.3 to 2.8 t, 16.7 40.5 6 t 13 t 24.5 45.5 28 t 60 t 52.7 130 t 77.5...
  • Page 91 Dimension drawings 10.15 SIWAREX WL270 K-S CA With double bridge Figure 10-17 Dimension drawing SIWAREX WL270 K-S CA with double bridge Rated load Dimensions in mm   ∅d ∅D 13 t 24.5 45.5 28 t 60 t 52.7 130 t 77.5 78.5 280 t 100.5 350 t 500 t SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 92: Siwarex Wl270 Cp-H Sd

    Dimension drawings 10.16 SIWAREX WL270 CP-H SD 10.16 SIWAREX WL270 CP-H SD Figure 10-18 Dimension drawing SIWAREX WL270 CP-H SD See also Mounting a load cell with hygienic design (Page 23) SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 93: Siwarex Wl280 Rn-S Sa

    Dimension drawings 10.17 SIWAREX WL280 RN-S SA 10.17 SIWAREX WL280 RN-S SA Dimension drawing for SIWAREX WL280 RN-S SA load cell for 60, 130, 280 kg The dimension drawing also contains the dimensions of the pressure piece. The pressure piece is included in the scope of delivery of the load cell. Figure 10-19 Dimension drawing for SIWAREX WL280 RN-S SA, rated load 60 kg, 130 kg, 280 kg Dimension drawing for SIWAREX WL280 RN-S SA load cell for 0.5, 1 t...
  • Page 94 Dimension drawings 10.17 SIWAREX WL280 RN-S SA The pressure piece is included in the scope of delivery of the load cell. Figure 10-20 Dimension drawing for SIWAREX WL280 RN-S SA, rated load 0.5 t, 1 t Dimension drawing for SIWAREX WL280 RN-S SA load cell for 2, 3, 5 t The dimension drawing also contains the dimensions of the pressure piece.
  • Page 95 Dimension drawings 10.17 SIWAREX WL280 RN-S SA Figure 10-21 Dimension drawing for SIWAREX WL280 RN-S SA, rated load 2 t, 3 t, 5 t Dimension drawing for SIWAREX WL280 RN-S SA load cell for 10 t The dimension drawing also contains the dimensions of the pressure piece. The pressure piece is included in the scope of delivery of the load cell.
  • Page 96 Dimension drawings 10.17 SIWAREX WL280 RN-S SA Figure 10-22 Dimension drawing for SIWAREX WL280 RN-S SA, rated load 10 t SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...
  • Page 97 Dimension drawings 10.17 SIWAREX WL280 RN-S SA Dimension drawing for SIWAREX WL280 RN-S SA load cell for 13 t Figure 10-23 Dimension drawing for SIWAREX WL280 RN-S SA, rated load 13 t SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...
  • Page 98 Dimension drawings 10.17 SIWAREX WL280 RN-S SA Dimension drawing for SIWAREX WL280 RN-S SA load cell for 28 t and 60 t Figure 10-24 Dimension drawing for SIWAREX WL280 RN-S SA, rated load 28 t and 60 t Rated load ∅ A in mm B in mm ∅...

  • Page 99: Siwarex Wl290 Db-S Ca

    Dimension drawings 10.18 SIWAREX WL290 DB-S CA 10.18 SIWAREX WL290 DB-S CA Dimension drawing of the load cell SIWAREX WL290 DB-S CA for 2.3; 4.5; 9.1; 13.6; 18; 23; 27; 34; 45; 68; 91; 113 t Figure 10-25 Dimension drawing of WL290 DB-S CA Table 10-1 Dimensions WL290 DB-S CA Rated...
  • Page 100 Dimension drawings 10.18 SIWAREX WL290 DB-S CA SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...

  • Page 101: Product Documentation And Support

    Additional information on our technical support can be found at Technical Support (http:// www.siemens.com/automation/csi/service).   Service & support on the Internet In addition to our technical support, Siemens offers comprehensive online services at Service & Support (http://www.siemens.com/automation/serviceandsupport). SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...
  • Page 102 Product documentation and support A.2 Technical support Contact If you have further questions about the device, contact your local Siemens representative at Personal Contact (http://www.automation.siemens.com/partner). To find the contact for your product, go to "all products and branches" and select "Products &...

  • Page 103: Index

    Index Calibration approval, 35 Laws and directives Catalog Disassembly, 11 Technical data sheets, 101 Personell, 11 Certificates, 11, 101 Load cells with six-wire system, 27, 28 Cleaning, 43 Connecting cable in four-wire system, 35 Connecting cable in six-wire system, 36 Corner load adjustment, 38 Maintenance, 43 Customer Support, (Refer to Technical support) Manuals, 101 Modifications correct usage, 12...
  • Page 104 Index Technical data, 51, 52 Technical support, 101 partner, 102 personal contact, 102 Temperature error, 35 Test certificates, 11 Transverse forces, 34 Warranty, 9 Wheatstone bridge, 18 SIWAREX WL200 Operating Instructions, 07/2024, A5E02199611B-14...
