- Page 1 VIEW XV9M USER MANUAL For more information on the Xview range go to our website xviewdrive.com.au INCLUSIONS: Mirror Monitor, Rear Camera, Camera Lead With Trigger Wire, USB Cable, 12/24V Car Charger & Mounting Hardware 01-03-24...
-
Page 2: Product Features And Specifications
1. PRODUCT FEATURES AND SPECIFICATIONS Thank you for purchasing the Xview XV9M Mirror Monitor. This product is a convenient and durable traveling video and data recorder. Please ensure that you have read the product manual and instructions in full, prior to installation and use. Failure to do so may result in product failure/damage or incorrect operation and therefore impact the product performance. -
Page 3: Table Of Contents
2. TABLE OF CONTENTS Product features and specifications........2 Table of contents..............3 Package components............4 Optional Accessories (sold separately)........5 Product structure..............6 Installation of Mirror Monitor..........7 Touch screen functions............8 Other Mirror Functions............9 Settings..............10 Video playback mode............11 Connecting to a computer..........11 G-sensor sensitivity............11 Reversing guide lines............12 Formatting SD card............12 Infringement of copyright warning........12 Product specifications............13... -
Page 4: Package Components
3. PACKAGE COMPONENTS XV9M Mirror Monitor USB cable Rear Camera 12/24V charging adapter Camera Lead with Trigger Wire Mounting screws & 3M adhesive Mirror protector pads & for butterfly camera rubber mounting clips... -
Page 5: Optional Accessories (Sold Separately)
4. OPTIONAL ACCESSORIES (sold separately) XVHWC – Hard Wire Kit Allows the Monitor to be powered via the vehicle fusebox. Includes fuse taps for simple installation and also includes voltage cut off detection to prevent battery drain. -
Page 6: Product Structure
5. PRODUCT STRUCTURE 1) LCD touch screen 4) Rear camera input 2) Power button 5) Power input (Mini USB) 3) Micro SD card slot 6) Mounting clip-on system... -
Page 7: Installation Of Mirror Monitor
6. INSTALLATION OF THE MIRROR MONITOR 1. Clip on mirror design securely mounts on the existing rear view mirror in the vehicle by stretching the bands at the back. There are two positions based on thickness of existing mirror. 2. Insert Micro SD card into the Mirror Monitor 3. -
Page 8: Touch Screen Functions
7. TOUCH SCREEN FUNCTIONS 1) Recording indicator: Flashes red when recording. 2) Settings: Press to access the settings menu, see details on page 10 (turn off recording function to access). 3) Playback: Press to access recorded video files (turn off recording function to access). -
Page 9: Other Mirror Functions
8. OTHER MIRROR FUNCTIONS Turn Device On/Off: Long press the power button to turn mirror ON/OFF. Turn Off Display: Short press the power button while recording to turn off the display (recording will continue). Display Brightness: Touch the screen and swipe left or right to change brightness. -
Page 10: Settings
9. SETTINGS Press settings icon to enter video settings. Select function and select settings to make changes. Press arrow icon to exit the function. Function Description Movie Mode 1080P/720P Movie Clip Time 1/2/3 Min Sound Record On/Off Mirror On/Off Clock Settings Date/Time Stamp Date+Logo/Date/Logo/Off... -
Page 11: Video Playback Mode
10. VIDEO PLAYBACK MODE When not recording press the playback icon to select recorded and locked recorded video footage. Press on the file to view on screen. You can press icons on screen to lock/ unlock/ back/ forward/ pause and delete recorded video files. Press return arrow to exit to menu files. -
Page 12: Reversing Guide Lines
13. REVERSING GUIDE LINES When triggered, the reversing guide lines only assist a driver with backing into a parking space or aligning with an object behind the vehicle. They do not measure distance. You should always get out of the vehicle and visually check the distance to aid the driver when using guide lines. -
Page 13: Product Specifications
16. PRODUCT SPECIFICATIONS Display 9.35" High-resolution LCD touch screen Color Black Video HD 1920*1080 @ 25FPS Resolution Frequency 50HZ/60HZ Mstar8336 Rear Camera Surface mount butterfly camera Viewing Angle 110 Degree wide angle lens Functions G-Sensor, Loop recording OSD Language English/Russian/Chinese Audio Built-in Microphone and speaker Storage... -
Page 14: Troubleshooting Guide
17. TROUBLESHOOTING GUIDE If there are problems with the device, please refer to the following methods to resolve. Cannot record video? Please check whether there is enough space on the micro SD card or internal storage. Stopping automatically while recording? Due to the high amount of HD video data being recorded, please use a high-speed Micro SD card. -
Page 15: Safety Information & Warnings
Please pay attention to cleaning the lens surface, use a moist soft cloth to clean the lens before use, to avoid poor video footage. Xview is NOT responsible for the loss of any recorded video during operation. Although designed to withstand high impact of car collision, Xview does NOT guarantee recording of accidents where the impact may cause the device to be damaged. -
Page 16: User Support
19. USER SUPPORT If you need assistance setting up or have an issue regarding the use of Product specifications your Xview product contact Xview Customer Support. Australian Agent: TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST Please retain this user guide for future reference.
Need help?
Do you have a question about the XV9M and is the answer not in the manual?
Questions and answers
I have installed an XV9m reversing camera in my vehicle and installed by a qualified auto electrician and has been functioning very well for the last 9 months. However, now the camera image when reversing shows objects that on either the right or left side of the vehicle displaying on the screen opposite to what they should be. Would appreciate advice on how this issue can be corrected.
