1. Features
USB 2.0-USB-IF certified (TID # 40000085)
■
enCoRe™ II USB - "enhanced Component Reduction"
■
Crystalless oscillator with support for an external clock. The
❐
internal oscillator eliminates the need for an external crystal
or resonator.
Two internal 3.3V regulators and an internal USB pull up
❐
resistor
Configurable IO for real world interface without external com-
❐
ponents
USB Specification compliance
■
Conforms to USB Specification, Version 2.0
❐
Conforms to USB HID Specification, Version 1.1
❐
Supports one low speed USB device address
❐
Supports one control endpoint and two data endpoints
❐
Integrated USB transceiver with dedicated 3.3V regulator for
❐
USB signalling and D– pull up.
Enhanced 8-bit microcontroller
■
Harvard architecture
❐
M8C CPU speed is up to 24 MHz or sourced by an external
❐
clock signal
Internal memory
■
Up to 256 bytes of RAM
❐
Up to eight Kbytes of Flash including EEROM emulation
❐
Interface can auto configure to operate as PS/2 or USB
■
No external components for switching between PS/2 and
❐
USB modes
No General Purpose IO (GPIO) pins required to manage dual
❐
mode capability
Low power consumption
■
Typically 10 mA at 6 MHz
❐
10 μA sleep
❐
In system reprogrammability:
■
Allows easy firmware update
❐
GPIO ports
■
Up to 20 GPIO pins
❐
2 mA source current on all GPIO pins. Configurable 8 or
❐
50 mA/pin current sink on designated pins.
Each GPIO port supports high impedance inputs, config-
❐
urable pull up, open drain output, CMOS/TTL inputs, and
CMOS output
Maskable interrupts on all IO pins
❐
A dedicated 3.3V regulator for the USB PHY. Aids in signalling
■
and D– line pull up
Cypress Semiconductor Corporation
Document 38-08035 Rev. *K
Low Speed USB Peripheral Controller
125 mA 3.3V voltage regulator powers external 3.3V devices
■
3.3V IO pins
■
4 IO pins with 3.3V logic levels
❐
Each 3.3V pin supports high impedance input, internal pull
❐
up, open drain output or traditional CMOS output
SPI serial communication
■
Master or slave operation
❐
Configurable up to 4 Mbit/second transfers in the master
❐
mode
Supports half duplex single data line mode for optical sensors
❐
2-channel 8-bit or 1-channel 16-bit capture timer registers.
■
Capture timer registers store both rising and falling edge times.
Two registers each for two input pins
❐
Separate registers for rising and falling edge capture
❐
Simplifies the interface to RF inputs for wireless applications
❐
Internal low power wakeup timer during suspend mode:
■
Periodic wakeup with no external components
❐
12-bit Programmable Interval Timer with interrupts
■
Advanced development tools based on Cypress PSoC® tools
■
Watchdog timer (WDT)
■
Low voltage detection with user configurable threshold
■
voltages
Operating voltage from 4.0V to 5.5V DC
■
Operating temperature from 0–70°C
■
Available in 16 and 18-pin PDIP; 16, 18, and 24-pin SOIC;
■
24-pin QSOP, and 32-pin QFN packages
Industry standard programmer support
■
1.1 Applications
The CY7C63310/CY7C638xx is targeted for the following
applications:
PC HID devices
■
Mice (optomechanical, optical, trackball)
❐
Gaming
■
Joysticks
❐
Game pad
❐
General purpose
■
Barcode scanners
❐
POS terminal
❐
Consumer electronics
❐
Toys
❐
Remote controls
❐
Security dongles
❐
•
198 Champion Court
CY7C63310, CY7C638xx
,
•
San Jose
CA 95134-1709
Revised December 08 2008
