* Water pump bracket installation
*
泵
架安
* Installation du support de pompe à eau
* Installation der Wasserpumpenhalterung
* Instalación del soporte de la bomba de agua
*ウォーターポンプブラケッ トの取り付け
Water pump bracket 1 installation
g
k
Water pump bracket 3 installation
g
Position can
be adjusted
m
Suitable for 240/360 mm water cooling radiator
Water pump bracket 2 installation
g
l
Suitable for 240/280 mm water cooling radiator
Position can
be adjusted
- 11 -
Position can
be adjusted
p
