WIRELESS BRIDGE
Tips:
Thank you for ordering and using ULNA CPE412 Wireless Bridge, please read
the manual carefully before use. If there are any problems during the use,
please contact us in time.
The installation of this device requires some network knowledge. If you can't
install it, please let us know or contact a professional.
Customer Service Email:
USER MANUAL
Model: CPE-412
support01@ulnastore.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPE-412 and is the answer not in the manual?

Questions and answers

Related Manuals for ULNA CPE-412

Summary of Contents for ULNA CPE-412

  • Page 1 USER MANUAL Model: CPE-412 Tips: Thank you for ordering and using ULNA CPE412 Wireless Bridge, please read the manual carefully before use. If there are any problems during the use, please contact us in time. The installation of this device requires some network knowledge. If you can't install it, please let us know or contact a professional.

  • Page 2: Table Of Contents

    Contents 1. Overview 1.1 Introduce 1.2 Highlights 1.3 specifications 2. Package Included 3. Interface Details 4. LED Indicator Details 5. Quick Start 5.1 PoE Power Supply 5.2 Point to Point Pairing 5.3 Point to Multipoint Pairing 6. Installation 6.1 Pole mount 6.2 Wall-mounted 6.3 Connect to the device 7.

  • Page 3: Overview

    1. Overview 1.1 Introduce ULNA CPE412 is a long-distance 5.8G wireless transmission device. It uses wireless communication technology to transmit network data using air as a medium to perform long-distance point-to-point or point-to-multipoint interconnection. The working data link layer realizes the interconnection of local area networks.

  • Page 4: Specifications

    1.3 Specifications Brand ULNA Model CPE-412 MT7620A+7612E Flash 8MByte DRAM DDR2 128MByte Interface 10/100Mbps LAN*1 & 10/100Mbps LAN*1 11a:54M,48M,36M,24M,18M,12M,9M,6Mbps 11n:7.2M,14.4M,21.7M,28.9M,43.3M,57.8M,65M, Data rate 72.2M,14.4M 28.9M,43.3M,57.8M,86.7M,115.6M,130M,144.4Mbps Transfer method Direct Sequence Spread Spectrum(DSSS) Modulation OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK Protocol standard IEEE802.11ac IEEE802.11n,IEEE802.11a ,IEEE802.3u CSMA/CA,TCP/IP,IPX/SPX,NetBEUI,DHCP,NDIS3, Agreement NDIS4,NDIS5 4900～6100MHz...

  • Page 5: Package Included

    USER MANUAL Model: CPE-609 Tips: Thank you for ordering and using ULNA CPE609 Wireless Bridge, please read the manual carefully before use. If there are any problems during the use, please contact us in time. The installation of this device requires some network knowledge. If you can't install it, please let us know or contact a professional.

  • Page 6: Led Indicator Details

    4.LED Indicator Details Transmitter A Mode Receiver B Mode LED Light Description Signal Lights After the bridge is connected successfully, the WLAN light will be on, not connected the WLAN light will not be lit. LAN1/LAN2 The data connection is successful, the LED light is on, otherwise, it is not bright.

  • Page 7: Quick Start

    5.Quick Start 5.1 PoE Power Supply The CPE412 wireless bridge adopts a PoE power supply, which is easy to install and manage while saving costs. 1.1. According to the requirements, prepare a long enough network cable （Recommended within 20 meters, must Cat 5e or up）to connect the wireless bridge and the PoE power supply.

  • Page 8: Point To Multipoint Pairing

    5.3 Point to Multipoint Pairing Step: e.g. 1 master bridge with 3 slave bridges 1. Switch one unit to A(Master Bridge) and 3 units to B(Slave Bridge); 2. Connect the POE to each unit using the Ethernet cable and plug the POE in; 3.

  • Page 9: Wall-Mounted

    6.3 Connect to the device 1. Choose to pole mount or wall-mounted, adjust the CP bracket is not included in the package. Recommended ULNA Universal Bracket (ASIN: B0B5TWYHWC). 2. Please, prepare a long enough network cable to connect the PoE adapter and CPE, the network cable is connected to the LAN port of the CPE, and the other end is connected to the PoE port of the PoE adapter.

  • Page 10: Application Case

    Note: For point-to-point installation, the line of sight of the 2 wireless bridge brackets must be clear and cannot pass through the wall. The signal transmission angle of the bridge is 60 degrees. For point-to-multipoint installation, the angle of the slave bridge needs to be adjusted to ensure that it is within the 60-degree signal range of the main bridge.

  • Page 11: Point-To-Multiple Point Extended Surveillance Cameras Range

    7.3 Case 3: Point-to-multiple point extended surveillance cameras range 7.4 Case 4: Point-to-point extended surveillance cameras range support01@ulnastore.com...

  • Page 12: Advanced Settings

    8.Access to the WEB interface Tips： No need to enter the WEB interface wireless bridge can be used normally 1. Computer Access Wireless Bridge, connect the CPE to the computer Refer to the figure left to connect the CPE to the computer through a PoE adapter and an Ethernet cable.
  • Page 13 3. Change your computer's IP address to 192.168.255.xxx (192.168.255.xxx cannot be the same as the IP of the CPE), then the entry IP address is 192.168.255.xxx, the subnet mask is 255.255.255.0(Autofill), the Default gateway is 192.168.255.xxx, Preferred DDS server 192.168.255.xxx. You can use 192.168.255.105(xxx=5) in the reference picture to set.
  • Page 14 5. Login successful Digital & IP & WiFi Correspondence Chart You can check the SSID and password through this chart. support01@ulnastore.com...

  • Page 15: Troubleshooting

    9.Troubleshooting 1. Wireless interference 1. Use WiFi analysis to 2. Distance is too long, choose the best channel or there are some walls 2. CPE should be in the Packet Latency between them normal distance, and avoid 3. CPE's angle in the the wall wrong direction, weak 3.
  • Page 16 1. Packet Latency 1. Adjust the distance, angle 2. Ethernet cable circuit and channel to decrease 3. Network virus attack latency Low transmission 4. Too much access users 2. Check if port isolated to Rate 5. Network Cables type avoid network virus and lower than Cat 5e? broadcast storm 4.

  • Page 17: Technical Support And Service

    10.Technical Support and Service A. Thank you for your order and for using ULNA Wireless Bridge, please read the manual carefully before use. If there are any problems during the use, please contact us in time; B. The installation of this device requires some network knowledge. If you can't install it, please let us know or contact a professional.
