Antennas Direct ELEMENT Quick Start Assembly/Installation Instructions

Advertisement

Quick Links

READ BEFORE INSTALLATION:
Before permanently attaching the antenna to any surface, TEST RECEPTION in that area.
move the antenna and rescan for the available channels.
3
2
4
SET UP THE ANTENNA:
Coaxial cable and antenna mast sold separately.
1
Unfold the elements
as shown
Make sure the front of
the antenna is facing the
broadcast towers.
Mast and Coaxial Cable (sold separately)
Now that you've installed your antenna, you are ready to scan for channels. See
Congratulations! You're watching HDTV for FREE! Welcome to the Antennas Direct cord-cutting family.
ELEMENT
Connect the antenna to the TV or converter box and run a full channel scan. If reception is not as desired,
1)
Antenna
2)
Mast Clamp
3)
U-Bolt
4)
2 - Wing Nuts
INSTALLATION:
IMPORTANT: CHECK THE RECEPTION IN THE
LOCATION WHERE YOU INTEND TO INSTALL
THE ANTENNA PRIOR TO ATTACHING A MAST
TO ANY SURFACE.
Before installing the antenna on a mast,
adjust the mast so it is in a vertical
position. Mast sold separately.
You will need to adjust the antenna a er it
is mounted for the best reception.
Antenna Input
USB Port
ANT-IN
Pr
Pb
Y
USB
Antenna Input
USB Port
R
L
CVBS
HDMI
TV or Converter Box
"Scanning for channels"
in the troubleshooting guide.
