Antennas Direct CLEARSTREAM ECLIPSE CTVECL Installation Instructions

1
Reset Button

2. Connect ClearStream TV to the TV Antenna

Connect one end of the 12 . Coaxial Cable
other end of the Coaxial Cable (3) to the ClearStream TV (2).
Clean any surface before applying Sure Grip to a window or wall. Peel the film from the
white side of the Sure Grip Strip (4) and place it on the antenna
the film from the clear side of the Sure Grip Strip
flat surface facing the broadcast towers. Press firmly on the antenna along the strip area,
so it has a good grip to the surface.
4
NOTE: Sure Grip is removable and can be repositioned on any smooth, flat surface and in
various locations. Dust and debris can weaken the ability of Sure Grip. Clean the Sure Grip
Strip with clear water to remove any dirt or debris and restore to like-new performance.
Do not allow water to get into the plastic housing area where the coaxial cable is attached; doing so can cause permanent damage
to the antenna.
Be sure the antenna is positioned in the best location to receive broadcast signals and ClearStream TV is within 20 . of the WiFi router with no
obstructions, to facilitate proper reception.

3. Power Setup

Before connecting ClearStream TV
end to ClearStream TV.
When the device powers on, you will see blue and red status lights. This indicates ClearStream TV is starting up. When the status light turns green, this means ClearStream TV
is on and ready for use.
It may take 1-3 minutes before the status light turns green.

4. WiFi Setup

Launch the ClearStream TV
companion app and select
"Connect CLEARSTREAM TV"
in the Settings menu.

5. Scan for Channels

To scan for the available channels in your area, go into "Settings" and select "Scan for Channels".
Depending on the broadcast signal strength and the number of available channels in your area, the channel scan can take 5-7 minutes.
Helpful Tips:
- Be ready to experiment with various locations in your home for the best signals. During the initial WiFi Setup, the best placement for the ClearStream TV is within 20 . of your WiFi router.
For the TV Antenna, the best placement is on a window or wall facing the broadcast towers.
- Record a live TV channel on a compatible iOS/Android smartphone or tablet or Amazon Fire TV device with su icient storage capabilities. Record your favorite broadcast TV shows to
watch on-the-go, no Internet connection required.
- You can Set a Reminder to watch or record an upcoming show (within 24 hours). In the ClearStream TV app, go into the Program Guide, select a TV show, then select
You'll get a notification 5 minutes before the TV show begins, so you can watch or start recording live tv on time!
- If some channels are bu ering, go into Settings, then Video Quality, and then change the setting to 'Standard Definition' .
- The Program Guide shows you a complete list of networks and TV shows available. In Settings, you can sort the channels, move your favorite channels to the top of the list, or delete
unwanted channels.
- If you have multiple ClearStream TV devices, you can change the name of each device, i.e. "Living Room", "Bedroom", etc. Go into Settings and select the ClearStream (XXXX) device
name to change it.

Quick Start Assembly/Installation Instructions

CLEARSTREAM ECLIPSE™
Before beginning assembly, make sure all parts needed are present.
Before attaching the antenna to any surface, TEST RECEPTION in that area.
2
3
Let's Get Started

1. Download the App

Power Jack
Download the FREE ClearStream TV companion app from the app store.
ROKU USERS: Roku streaming devices do not support the initial WiFi Setup of the
Status Lights
ClearStream TV. Complete the initial WiFi Setup with an iOS or Android smartphone or
tablet. For detailed instructions, go to www.antennasdirect.com/clearstreamtv/roku
MINIMUM OS REQUIREMENTS: Android 4.2 or above, iOS 8.4 or above, tvOS 10.2 or above, Roku v7.50 b4099
or above, and Amazon Fire devices from 2013 or newer.
Register your device at www.antennasdirect.com/clearstreamtv/register
(3) to the connector on the antenna
(1) as shown below. Peel
(4) and place the antenna on any smooth,
(2) to a home WiFi network, the device needs to be powered on. First, plug the Power Adapter
Select
and then choose
"CLEARSTREAMTV_XXXX" from the
list of available wireless networks.
This will allow you to connect the
ClearStream TV as an access point,
so you can connect ClearStream TV
to your home WiFi network in the
Wireless TV Antenna
with Sure Grip™
4
5
(1) and the
5
"Get Connected"
following steps.
The ClearStream ECLIPSE™ Wireless TV
Antenna comes with:
1) ClearStream ECLIPSE TV Antenna
2) ClearStream TV WiFi Tuner Adapter
3) 12 . Coaxial Cable
4) Sure Grip Strip
5) Power Adapter
1
2 3
(5) into a wall outlet, and then connect the other
Return to the
ClearStream TV
app and tap
"Next"
Select your Home WiFi
network to connect the
ClearStream TV, and
enter your home WiFi
password.
ClearStream TV will
reboot to finalize the
WiFi Setup process.
.
