BV -BF-03 Operation Instructions And Parts Manual

BATHROOM
EXHAUST FANS
OPERATION INSTRUCTIONS AND PARTS MANUAL
READ AND SAVE THESE INSTRUCTIONS
1. Electric service supply must be 120 V 60 Hz
2. Follow all local building,safety and electrical codes as well as NEC(National Electrical Code) and OSHA(Occupational Safety and Health Act).
3. This unit must be properly grounded.
4. Always disconnect the power supply prior to servicing the fan, motor or junction box.
5. Do not bend or kink the power wires.
6. Do not install where the room air temperature will exceed 104ºF (40ºC).
7. This ventilation fan is approved for use in a ceiling over a bathtub or shower when installed o n a ground-fault circuit interrupter (GFCI)
protected circuit. Do not use fan over a bathtub or shower that is not approved for that application and marked accordingly.
8. Do not use to exhaust hazardous or explosive vapors.
9. Do not install in a cooking area.
10. Use this unit in the manner intended by the manufacturer. If you have any questions,please call customer service.
11. Installation work must be carried out by a qualifed person, in accordance to all local a nd safety codes, including the rules
for fire-rated constructions.
12. Exercise care not to damage existing wiring when cutting or drilling into walls or ceilings.
13. Fans should always be vented to the exterior and in compliance with local codes.Do not vent exhaust air in spaces within walls,
ceiling, attic, crawl space or garage.
14. Do not use this fan with any solid state control device.
15. Prior to service or cleaning this unit, shut off power supply at the panel and lock to prevent the power from being turned on.
If the panel cannot be locked, clearly mark the panel with a warning tag to prevent the power from being turned on.
16. Duct work should be installed in a straight line with minimal bends.
17. Duct work size must be a minimum of the discharge and should not be reduced. Reducing the duct size can increase fan noise.
18. The switch should not be accessible from inside of bathtub or shower.
19. The fan is to be mounted at least 7 feet (2.1 m) above the foor.
BEFORE YOU BEGIN
1.
Carefully unpack and remove the unit from the carton.
2. Check to make sure you have all components listed in the tables shown below.
3. If any components are missing,please contact the manufacturer.
ITEM
Long Wood Screw
(4 x 30mm)
Short Wood Screw
(4 x 6mm)
150CFM SKU: BV-BF-03
PICTURE QUANTITY
ITEM
8
Fan Unit
4
Grill
Suspension
Bracket 1
Suspension
Bracket 2
150CFM SKU: BV-BF-03
QUANTITY
1
1
2
2
Page 1 of 6
