- Page 1 Cantilever Patio Umbrella Owner’s Manual MODEL: EURU001 EURU002 EURU003 EURU004 EASTOAK.COM OWNER’S MANUAL...
- Page 2 Questions? Comments? Reach out to us for expert support! support@eastoak.com eastoak.com 1-833-EAST-OAK ( USA ) ( 1-833-327-8625 ) Mon-Fri 8am-8pm EST Follow eastoakliving on Claim your 3-year warranty Please scan the QR code to view the installation video at eastoak.com/warranty CANTILEVER PATIO UMBRELLA EASTOAK.COM OWNER’S MANUAL...
-
Page 3: Important Caution
IMPORTANT CAUTION SAFETY GUIDE Please check all parts and components to ensure no damage or missing items • Please read these instructions carefully before assembly. before starting the product’s construction. If you have any problems or discover • Aluminum is soft metal and over tightening may strip thread or break the part. any missing parts, please contact customer service at support@eastoak.com. -
Page 4: Parts List
PARTS LIST PARTS LIST Lower Cross Base Upper Cross Base Sleeve Crank X 1 PC X 1 PC X 1 PC X 1 PC Main Frame and Canopy Revolving Base M10 Washer Wrench S8 X 1 PC X 1 PC X 8 PCS X 1 PC WHAT’S IN THE BOX... - Page 5 ASSEMBLY INSTRUCTIONS Install the revolving base on the base cross frame. Install the base cross frame: Lock the upper cross base E X 4PCS H X 1PC onto the lower cross base. G X 4PCS J X 1PC M10*25mm CANTILEVER PATIO UMBRELLA EASTOAK.COM OWNER’S MANUAL...
- Page 6 Install the sleeve on the revolving base. Put the cover on the revolving base. D X 4PCS G X 4PCS I X 1PC K X 1PC J X 1PC M10*20mm CANTILEVER PATIO UMBRELLA EASTOAK.COM OWNER’S MANUAL...
- Page 7 It is recommended that two people lift the Install the crank main frame of the umbrella, insert the pole F X 2PCS into the sleeve, and tighten the screws. J X 1PC L X 1PC Clamp the lever and slide the umbrella up or down along the pole to achieve the desired angle.
- Page 8 To open the canopy, turn the crank clockwise until the canopy Step on the foot pedal switch, rotate the umbrella to the desired is fully open. position, and then release the switch to lock the foot pedal in place. 360° TIPS: During the opening process, when the canopy is close to being fully open, release the crank.
- Page 9 Tilt the umbrella to the desired angle. To close the umbrella Turn the crank counterclockwise until the canopy is fully closed. Clamp the the lever and then slide down the umbrella along the pole and release the handle to lock it in place. 60°...
-
Page 10: Warranty Policy
WARRANTY POLICY GUARANTEED 3-YEAR WARRANTY Thank you for choosing East Oak. This product is covered by our company warranty for up to 3 years from its original purchase date. CLAIM WARRANTY If you’d like to claim your product’s warranty, register your new product on our website at www.eastoak.com/warranty. - Page 11 support@eastoak.com eastoak.com 1-833-EAST-OAK (USA) CANTILEVER PATIO UMBRELLA...
