- Page 1 SBC25-C466 2.5” Single Board Computer with ® Intel Atom™ x6413E Processor, Dual 2.5 Gbit Ethernet, LPDDR4 RAM Product Manual WINSYSTEMS, Inc. | 2890 112th Street, Grand Prairie, Texas 75050 | 817-274-7553 | info@winsystems.com | www.winsystems.com...
- Page 2 Copyright 2022, WINSYSTEMS, Inc. No part of this document may be copied or reproduced in any form or by any means without the prior written consent of WINSYSTEMS, Inc. The information in the document is subject to change without notice. The information furnished by WINSYSTEMS, Inc.
-
Page 3: Table Of Contents
SBC25-C466 Table of Contents Before You Begin........... 5 1.1 Warnings . - Page 4 SBC25-C466 7.3.14 USBC - USB 3.2 Gen 1 - Type C (Bottom)....... . . 22 7.3.15 USB1-USB5 - USB 2.0 Headers .
-
Page 5: Before You Begin
Atom™ x6413E processor and is a perfect choice for applications requiring low power and Intel performance in a small form factor package with industrial connectors and I/O. The SBC25-C466 provides 8 GB of LPDDR4 SDRAM soldered down to the board with a data transfer rate of 3200 MHz. v1.2 www.winsystems.com... -
Page 6: Features
SBC25-C466/Features Considering the small size of the SBC25-C466, it is packed with I/O features often lacking from larger single board computers. It includes dual 2.5 Gbit Ethernet controllers based on the Intel i225V family with Wake On Lan and PXE capabilities, providing connectivity and control for network devices. - Page 7 SBC25-C466/Features Ethernet • 2x Intel i225V 2.5 Gbps Ethernet controllers Storage • 1x SATA port • 1x M.2 B key with SATA support Serial Interface • 1x RS-232/422/485 serial ports • 3x RS-232 serial ports • 5x USB 2.0 •...
-
Page 8: General Operation
General Operation System Block Diagram The SBC25-C466 features the Intel Atom (Elkhart Lake) dual core or quad core system on chip (SOC). Its robust design, small size, and extended operational temperature make it ideal for use in industrial IoT applications and embedded systems for industrial controls, transportation, Mil/COTS, and energy markets. -
Page 9: Specifications
Enterprise, Windows 10 IoT Core, Linux, and some real-time operating systems. Drivers are available from the WINSYSTEMS website. Specifications The SBC25-C466 adheres to the following specifications and requirements. Table 1: SBC25-C466 specifications Electrical Wide range voltage input +9 to 36VDC... -
Page 10: Configuration
SBC25-C466/Configuration Configuration This section describes the SBC25-C466 components and configuration. Component Layout 7.1.1 Top View JLPP AUDIO Ethernet 1 Ethernet 2 JEPP USB Touchscreen status LEDs status LEDs HDMI ETH1 ETH2 BKLT USB1,2,3,4,5 LVDS JPWR PWROUT USBC (Bottom) JCMOS SATA... - Page 11 SBC25-C466/Configuration Table 2: Board components Item Description Reference Configuration Jumpers and LEDs JCMOS CMOS data clear page 12 JPWR Power in always page 12 JLPP LCD panel power select page 12 JEPP eDP panel power select page 13 LEDE1, LEDE2...
-
Page 12: Jumpers
Enable/disable the clear CMOS function hardware circuit, by placing or removing the jumper from JCMOS as needed. To reset the BIOS CMOS configuration to the factory default settings: 1. Remove power from the SBC25-C466. 2. Find JCMOS. 3. Remove jumpers from pins 1-2. -
Page 13: Jepp - Edp Panel Power Select
SBC25-C466/Configuration Layout and Pin Reference 3 2 1 3 2 1 *+3.3V Description *2-3 +3.3V 7.2.4 JEPP - eDP Panel Power Select Select the appropriate VCC setting using this jumper. Layout and Pin Reference 3 2 1 3 2 1 *+3.3V... -
Page 14: Connectors
SBC25-C466/Configuration Connector Information • Molex 53047-0410 Matching Connectors (cable housing) • Molex 51021-0400 Connectors 7.3.1 PWR - Power Input Layout and Pin Reference DC 9V~36V 1x4 pin (2.0 mm) connector pin 1 Description DC-IN (12V) Connector Information • JST B4B-PH-K-S Matching Connector (cable housing) •... -
Page 15: Bklt - Lvds Backlight Power
SBC25-C466/Configuration Connector Information • JST B4B-PH-K-S Matching Connector (cable housing) • JST PHR-4 7.3.3 BKLT - LVDS Backlight Power Backlight power 5-pin (2.0 mm) connector Layout and Pin Reference pin 1 Description +12V PWM dimming ENBKL (3.3V) ENBKL (5V) Note: Pin 3 back light dimming controls, provided 200 Hz / 275 Hz / 380Hz / 20 kHz / 25 kHz /100 Hz and adjust PWM duty cycle by software program. -
Page 16: M2 - M.2 Socket 3, With B Key, Type 2242/3042 Sata Support
SBC25-C466/Configuration Connector Information • Molex 053047-0210 Matching Connector (cable housing) • Molex 51021-0200 7.3.5 M2 - M.2 Socket 3, with B Key, Type 2242/3042 SATA Support The M.2 expansion socket provides support for B key, 2242/3042 form factor modules. The M.2, B key interface provides PCIe Gen 2 x2, 1x SATA channel, 1x USB 2.0, and 1x USB 3.2 Gen 1. -
Page 17: Sata1 - Serial Ata Interface
SBC25-C466/Configuration 7.3.6 SATA1 - Serial ATA Interface SATA1provides a serial ATA 6 Gbps 7-pin connector for interfacing with hard disk drives and solid state disk drives. 7.3.7 HDMI - HDMI Video Output 2x5 pin (1.25 mm) connector Layout and Pin Reference... -
Page 18: Lvds - Lvds Video Output
SBC25-C466/Configuration 7.3.8 LVDS - LVDS Video Output LVDS 2x15 pin (1.25 mm) connector Layout and Pin Reference Description Description pin 1 PWM dimming +LCD (5V or 3.3V) +LCD (5V or 3.3V) Channel-1-DATA3+ Channel-0-DATA3+ Channel-1-DATA3- Channel-0-DATA3- Channel-0-DATA2+ Channel-0-CLK+ Channel-0-DATA2- Channel-0-CLK- Channel-0-DATA1+... -
Page 19: Edp - Embedded Displayport (Edp)
SBC25-C466/Configuration 7.3.9 eDP - Embedded DisplayPort (eDP) 2x10 pin (1.25 mm) connector Layout and Pin Reference pin 1 Description Description Lane-0-DATA- +12V Lane-0-DATA+ +12V Lane-1-DATA- Lane-1-DATA+ Backlight enable PWM dimming C data +LCD (5V or 3.3V) C clock +LCD (5V or 3.3V) eDP Aux+ +LCD (5V or 3.3V) -
Page 20: Audio - Audio I/O
SBC25-C466/Configuration 7.3.10 AUDIO - Audio I/O Line-out/line-in/mic-in/SPDIF-out 2x5 pin (1.25 mm) connector Layout and Pin Reference pin 1 Description Description Line-out-R MIC-IN Line-in-R SPDIF-OUT Line-in-L Line-out-L MIC-IN Connector Information • HIROSE DF13-10DP-1.25V Matching Connectors (cable housing) • HIROSE DF13-10DS-1.25C 7.3.11 AMP - Audio Amplifier Amplifier line-out right/left channel 4-pin (1.25 mm) connector... -
Page 21: Fph - Front Panel Header
SBC25-C466/Configuration 7.3.12 FPH - Front Panel Header Front panel header 2x5 pin (1.25 mm) connector Layout and Pin Reference pin 1 Description Description Power button pin Power button GND Reset pin Reset GND Power LED- Power LED+ HDD LED- HDD LED+... -
Page 22: Usbc - Usb 3.2 Gen 1 - Type C (Bottom)
SBC25-C466/Configuration Matching Connectors (cable housing) • JST PHDR-08VS0 7.3.14 USBC - USB 3.2 Gen 1 - Type C (Bottom) One USB 3.2 Gen 1 (5 Gbps) port is supported with a Type-C onboard connector. 7.3.15 USB1-USB5 - USB 2.0 Headers 1x4 pin (1.25 mm) connector... -
Page 23: Ser1, 2 - Serial Rs-232/422/485 Port 1 And Serial Rs-232 Port 2
SBC25-C466/Configuration 8-wire type pin define Description Description Bottom Bottom sense Top sense Right Right sense Left Left sense Note: To configure for 8-wire touch setup, short pins 3 and 4 together. 4-wire type pin define Description Description Bottom Right Left Note: To configure for 4-wire touch setup, short pins 3 and 4 together. - Page 24 SBC25-C466/Configuration Layout and Pin Reference pin 1 Description Description SER1 SER2 Connector Information • HIROSE DF13-20DP-1.25V Matching Connectors (cable housing) • HIROSE DF13-20DS-1.25C v1.2 www.winsystems.com Page 24...
-
Page 25: Ser3, 4 - Serial Rs-232
SBC25-C466/Configuration 7.3.18 SER3, 4 - Serial RS-232 2x10 pin (1.25 mm) connector Layout and Pin Reference pin 1 Description Description SER3 SER4 Connector Information • HIROSE DF13-20DP-1.25V Matching Connectors (cable housing) • HIROSE DF13-20DS-1.25C v1.2 www.winsystems.com Page 25... -
Page 26: Dio - 4X Digital Input/4X Digital Output
SBC25-C466/Configuration 7.3.19 DIO - 4x Digital Input/4x Digital Output 2x5 pin (1.25 mm) connector Layout and Pin Reference pin 1 Description Description DI-0 DO-3 DI-1 DO-2 DI-2 DO-1 DI-3 DO-0 Notes: 1. By default, there is a 10k Ohm pull up resistor to +5V. -
Page 27: Mc - Mpcie Socket (Mini Card)
1. Insert a USB flash drive containing the BIOS update program into a USB socket on the SBC25-C466 platform. 2. Turn on the SBC25-C466 and press the ESC or DEL key during the boot process, which starts the BIOS setup utility. -
Page 28: Accessories And Cables
One passive heat spreader • One power cable adapter • One power supply Accessory List WINSYSTEMS cables simplify connection to the SBC25-C466. The following table lists available items. Table 3: Cable specifications Part Number Description CBL-SET-466-1 Cable set, includes power, digital I/O, Ethernet, USB 2.0, USB 3.2 Gen 1, serial, audio, and front panel... -
Page 29: Software Drivers
SBC25-C466/Software Drivers Standoff kits are available and recommended for use with the SBC25- C466. The following table lists the items contained in each kit. Table 4: Standoff kits Component Description KIT-PCM-STANDOFF-4 Standoff Nylon 0.25” hex, 0.600” long male/female 4- 4 pc. nylon hex standoff kit... -
Page 30: Best Practices
The SBC25-C466 requires +9V to +36V (+- 5%) to operate. Verify the power connections. Incorrect voltages can cause catastrophic damage. The SBC25-C466 has a single power connector at J17. A single 9V-36V DC input and ground is required to power the board. - Page 31 Power Supply OFF—Always turn off the power supply before connecting to the I/O Module. Do not hot-plug the SBC25-C466 on a host platform that is already powered. I/O Connections OFF—Turn off all I/O connections before connecting them to the embedded computer modules or any I/O cards.
- Page 32 Avoid cutting the SBC25-C466—Never use star washers or any fastening hardware that cut into the SBC25-C466. Avoid over-tightening of mounting hardware—Causing the area around the mounting holes to compress could damage interlayer traces around the mounting holes.
- Page 33 Contact an applications engineer—If a diagram or chart in a manual does not seem to match your board, or if you have additional questions, contact a WINSYSTEMS Applications Engineer at +1-817-274-7553. v1.2 www.winsystems.com Page 33...
-
Page 34: Mechanical Drawings
SBC25-C466/Mechanical Drawings Appendix B. Mechanical Drawings SBC25-C466 Mechanical Drawings v1.2 www.winsystems.com Page 34... -
Page 35: Warranty Information
Customer for the purchase of Products or licensing of Software hereunder. In the event this Order is placed in the hands of an attorney or collection agency by WINSYSTEMS to collect any sums due hereunder to WINSYSTEMS, Customer shall pay all reasonable attorney's fees, expenses, collection and court costs incurred by WINSYSTEMS.
