ITX-P-C444
Install mPCIe MiniCard
1
(A) Slide the MiniCard device into the MiniCard slot on the
top of the SBC at a 30° angle.
(B) Secure the device using the two (2) supplied
M2 x 4mm bolts.
Note: Do NOT install a MiniCard while power is applied
to the ITX-P-C444.
Install microSD Card
2
(A) Insert the the microSD card into the microSD slot with
the pins facing up until it clicks and locks into place.
(B) To remove the microSD card from the ITX-P-C444,
press the microSD into the connector until it clicks, then
release to safely remove the card.
Attach USB Peripherals
3
Attach a keyboard/mouse and/or bootable USB stick to the
USB 3.1 Gen 1 and USB 2.0 ports on the front panel of the SBC.
Video Output
4
Connect a monitor using an HDMI cable to HDMI connector
on the SBC.
Power Connection
5
Attach the power supply conductors to the power connector
using the screw terminals.
(Power supply requirements: 9V to 36V DC)
