- Page 1 Dekala Sunstone™ ACA-003-S Instructions Please read the instructions carefully before use and keep it with proper storage (V1.0)
- Page 2 -Scan QR Code to Download APP- Precaution Please read this manual carefully before using the product and keep it in a safe place for future reference. *For the first use of ACA-003-S, remove the pull tab on the battery compartment and then connect the adapter to turn on the alarm clock.
-
Page 3: Table Of Contents
Content Product 1-1. Product Overview 1-1-1. Package List 1-1-2. Front View 1-1-3. Back View 1-1-4. Holder Installation and Removal App Control 2-1. Download App 2-2. Connect your phone to 2.4 GHz Wi-Fi 2-3. Make Alarm Clock Enter into WiFi Connecting Mode 2-4. -
Page 4: Product
Product 1-1. Product Overview 1-1-1. Package List Sunrise Alarm Clock*1 Holder*4 USB Cable*1 Adapter*1 User Manual*1 1-1-2. Front View Snooze/Night Light Switch Setting "-"/Volume "-" Setting "+"/Volume "+" Sleep-aid Alarm 1/Alarm 2 Display Brightness/Time Setting Light Brightness Adjustment FM Radio Tuning Light Switch FM Radio Switch... -
Page 5: Back View
1-1-3. Back View Button Battery *Use for saving setting , Can not backup alarm clock . USB Output Reset FM Radio Antenna Micro USB Input 1-1-4. Holder Installation and Removal ① Install the stand: Insert the stand directly into ② Remove the stand:Hold the stand and gently press down to remove it.(as shown in Fig. -
Page 6: App Control
App Operations 2-1. Download App Download "Dekala Home or Smart Life" from App Store / Google Play or Scan the QR code, sign up and log in. 2-2. Connect your phone to 2.4 GHz Wi-Fi ① Most routers provide 2 Wi-Fi channels (2.4 GHz and 5 GHz), your phone probably automatically connects to the 5 GHz Wi-Fi most of the time, to find and connect to 2.4 GHz;... -
Page 7: Make Alarm Clock Enter Into Wifi Connecting Mode
③ For further questions regarding 2.4 GHz, please scan the QR code for tutorial. Split Wi-Fi into dual band 2.4 GHz & 5 GHz 2-3. Make Alarm Clock Enter into WiFi Connecting Mode ① Plug in to power, the flashing " "... -
Page 8: Connect Device To App
2-4. Connect Device to App Note: (1) Turn on GPS location, Wi-Fi(2.4 GHz only) and Bluetooth(App finds device by Bluetooth) on your smartphone before connecting device to your Wi-Fi(2.4 GHz only); (2) Please make sure the alarm clock has entered the WiFi Connecting Mode(please refer to the previous point - Make Alarm Clock Enter into WiFi Connecting Mode) - the flashing Wi-Fi icon shows the device is ready to connect to Wi-Fi (2.4 GHz only). - Page 9 (make sure the smartphone your 2.4 GHz Wi-Fi, click connecte to your 2.4 GHz and Smart Life app are both "Next"; Wi-Fi, tap on "Done" to connected to 2.4 GHz Wi-Fi); complete the Wi-Fi setup process; Dekala 2.4G...
- Page 10 ⑥ You can see the added device, click "Wake Up ⑦ "Wake Up Light Ⅱ" Home Page. Light Ⅱ" enter to Home Page;...
-
Page 11: App Usage
2-5. App Usage 2-5-1. Button Introduction Snooze Sleep-aid Alarm Clock Setting Light FM Radio Display... -
Page 12: Light Setting
2-5-2. Light Setting ① Click " " to choose the light display color and adjust the light brightness. - Page 13 ② If you turn on the Colorful Light, Tap "switch" to change the light color. You can choose 2 Light Mode： 1.colorful light dynamic loops 2. Choose 1 certain color light .
-
Page 14: Alarm Setting
2-5-3. Alarm Setting ① Click " " or " " to set alarm. *There are 4 alarms in total, and the way of setting 4 alarms is the same. Set alarm clocks by buttons to refer to Page 15. (Take alarm 1 as the example) Note: After changing the alarm settings, you need to click "Save"... -
Page 15: Snooze Setting
2-5-4. Snooze Setting ① Click " " to set snooze; ② When the alarm clock rings, click "Snooze" to snooze; ③ Click "Setting" to set snooze. You can snooze sound and keep light . - Page 16 ④-A. Click "Snooze Mode" to set. You can choose to turn off lights or sound during snooze. ④-B. Click "Snooze Time" to set. You can choose the snooze time range: 8-15 minutes.
-
Page 17: Sleep-Aid Setting
2-5-5. Sleep-aid Setting ① Click " " to set sleep-aid; ② Click "Setting" to set details; ③ Click " " or " " to turn on/off Sleep-aid. -
Page 18: Time Setting
2-5-6. Time Setting ① Click " " or "Time Display" to set time & 12/24H; ② Click "Time Display Brightness" to select display brightness mode: Day Mode, Automatic Mode and Close Mode; ③ Device automatically calibrates with real time after successful Wi-Fi connection. -
Page 19: Radio Setting
2-5-7. Radio Setting ① Click " " to set FM Radio; ② When the FM Radio is turned on, you can adjust the volume and stations from list; ③Tap "Search" to search radio stations automatically. -
Page 20: Button Operations
Button Operations 3-1. Time & 12/24H Setting Setting ① Press and hold "Setting / " for 2s to adjust the hour; ② Press " " to adjust number. Setting ① Press "Setting / " again to set Minute; ② Press " "... -
Page 21: Display Brightness Setting
3-2. Display Brightness Setting Press "Seeting / " to switch 3 display brightness mode -- Off Mode / Day Mode / Atuo Mode 。 *Default Brightness: Day. Setting Setting Setting Day Mode Atuo Mode Off Mode 3-3. Alarm Clock Setting Note: (1) You can only set alarm 1 and alarm 2 by buttons. - Page 22 3-3-1. Alarm Setting (Alarm 1 as the example) There are total 7 Steps to Set Alarm Clock with Sunrise Simulation: 1st: Long press Alarm button to enter Alarm Clock Setup 2nd: Set Alarm Clock--Hour 3rd: Set Alarm Clock-- Minute 4th: Choose Alarm Ringtone 5th: Adjust Ringtone Volume 6th: Choose Brightness of Sunrise effect 7th: Set Sunrise Simulation Time---The time means how long to start the sunrise simulation before...
- Page 23 Step 3: ① Press "Alarm 1 / " again to set ringtone; Alarm 1 ② Press " " to adjust type. *8 sound effects: S-01~S-07 and Radio. S-00: NO sound. S-01~S-07: built-in natural sounds. The last one is FM radio. Step 4: ①...
-
Page 24: Snooze/Stop Alarm Clock
Step 6: Alarm 1 Sunrise Simulation (light up prior to alarm) ① Press "Alarm 1 / " again to set Minute(10-60min); ② Press " " to adjust number; ③ Press "Alarm 1 / " finally to complete the alarm setting. 3-4. -
Page 25: Night Light/Bedside Light/Color Light
3-5. Night Light/Bedside Light/Color Light 3-5-1. Night Light Snooze Press "Snooze / " to tun on/off the night light. Note: Night light brightness is L-02(Can not adjust); it is recommended to use at night. *If alarm is working, press "Snooze / "... -
Page 26: Sleep-Aid Function
3-5-3. Color Light Light Double Press "Light / " to turn on color light; *The icon will illuminate and auto color-change mode. will be activated. Light ① Press " " to choose a certain color of light, ② Press and hold " "... - Page 27 Sleep-aid Step 1: ① Press and hold "Sleep-aid / " for 2s to to enter sleep-aid setting; ② Press " " to adjust sleep-aid duration. * Time range (10-120 min) Step 2: Sleep-aid ① Press "Sleep-aid / " again to set Light Brightness;...
-
Page 28: Fm Radio Setting
Step 4: Sleep-aid ① Press "Sleep-aid / " again to set Volume; ② Press " " to adjust level. *16 adjustable volume levels: U-01~U-16. If you choose S-00 in the previous step, this step will be omitted. Sleep-aid Step 5: ①... - Page 29 FM Radio Double Press "FM Radio / " to search radio station automatically; Long Press When the FM mode is turned on, press " " to adjust frequency (0.1 MHz); press and hold " " to Change Radio Station. When the FM mode is turned on, press "...
-
Page 30: Specification
Specification Model ACA-003-S Size 165×160×60mm 412g Weight Material ABS、PC、Electronic components FM radio frequency 87.5-108MHz Button Control +App Control +Voice Control Control mode Adaptor 5V-2A/100-240V Certification 1. Why can't I turn the alarm clock on ? Connect the adapter to activate the alarm clock for the first use. 2. -
Page 31: Notes
4. Can the light color be changed ? The light colors can be changed, but you need to change it in the app. (There are 7 different colors in total.) 5.How many kinds of sound effect are there and can I change it ? There are 10 kinds of sound effect can be changed.
