- Page 1 User Manual Gear Driven 20 Qt. Commercial Mixer Models: 177MX20H 7/2022 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
-
Page 2: Table Of Contents
User Manual Index Safety instructions .............. 3 Installation and cleaning ............. 4 Removal and refitting instructions mixer safety guard..5 Parts overview ..............6 Operating instructions ............7 Mixer capacity chart and Specifications ......8 Accessories ................. 9 Troubleshooting ..............10 Warranty information ............11 www.AvantcoEquipment.com... -
Page 3: Safety Instructions
User Manual Important Safety Instructions When using electrical appliances, basic safety precautions should be followed, including the following: Read all instructions carefully and completely. For commercial use only. Protect against electrical shock by keeping all cords, plugs, and other electrical components away from water or other liquids. -
Page 4: Installation And Cleaning
User Manual Installation 1. Prior to installation the electrical supply to the unit must be checked to ensure it complies to the electrical rating of the machine as detailed on the serial plate. 2. The unit must be positioned to ensure there is sufficient space around the machine to operate the controls and to raise and lower the mixing bowl. -
Page 5: Removal And Refitting Instructions Mixer Safety Guard
User Manual REMOVAL AND REFITTING INSTRUCTIONS MIXER SAFETY GUARD 1. To remove the wire guard adjust the position to align the edge of the wire guard with the single indentation marker on the fixed rear guard. See figure 1. Figure 1 2. -
Page 6: Parts Overview
User Manual PARTS CATALOG OVER Parts Overview ITEM DESCRIPTION #12 Hub ITEM Mixing Speed Handle Safety Guard Mixing Device (Not shown in drawing) Bowl Lift Handle Bowl Timer Power Switch NOTE • Do no • Do no opera • Unlpu Notes: suppl •... -
Page 7: Operating Instructions
STANDARD ACCESSORIES OPERATION INSTR User Manual FIGURE 10 Please ensure power supply m Please ensure power supply m NEMA 5015P 110V 110V FOR CHANGING THE SPEED: before changing speed in order t Operating Instructions for Normal Using STANDARD ACCESSORIES OPERATION INSTRUCTION FOR CHANGING THE SPEED: before changing speed in order t FIGURE 10... -
Page 8: Mixer Capacity Chart And Specifications
• 2nd Speed should never be used on mixtures with less than 50% AR. When calculating the correct size mixer for your application, here are some helpful weights & measures: • 8.3 lb. = 1 gallon of water – 2.08 lb. = 1 Quart. 177MX20H Type Capacity... -
Page 9: Accessories
STANDARD ACCESSORIES OPERATION INSTR User Manual FIGURE 10 Please ensure power supply m Please ensure power supply m NEMA 5015P 110V 110V FOR CHANGING THE SPEED: Standard Accessories before changing speed in order t STANDARD ACCESSORIES OPERATION INSTRUCTION FOR CHANGING THE SPEED: before changing speed in order t FIGURE 10 MIXING: According to the diff... -
Page 10: Troubleshooting
User Manual Troubleshooting Trouble Possible Causes Solution The axles can’t work when operating Poor contact of the electrical Check the Plug the machine equipment The mixing bowl is out of position Moving direction is not correct Change Leaks oil Sealing washer is damaged Change Difficult to move the bowl up and down Slideway is rusted... -
Page 11: Warranty Information
Limited Warranty Avantco Equipment warrants its equipment to be free from defects in material and workmanship for the prescribed time listed below, when purchased from an authorized dealer and appropriately installed in the United States. This is the sole and exclusive warranty made by Avantco covering your Avantco brand equipment. A claim under this warranty must be made within the prescribed time from the original date of delivery of the equipment. - Page 12 Limited Warranty Coverage Limitations This limited warranty does not cover: • Equipment used for residential or non-commercial purposes. • Equipment not purchased directly from an authorized dealer. • Equipment where the serial number plate has been removed or altered. • Equipment that has been altered, modified, or repaired by anyone other than an authorized service agency. •...
