Wharfedale Pro T-Sub-AX12B Quick Start Manual

Your full user manual can also be downloaded from
www.wharfedalepro.com
Congratulations on the purchase of your T-Sub-AX12B. We take great pride in engineering and building every Wharfedale Pro product
and wish to thank you for entrusting us with your audio.
From the time Gilbert Briggs built his first loudspeaker in 1932, to the present day, we have maintained the same standard of quality in
components, workmanship and performance.
Please take the time to read this guide completely in order to get the most from your new system.
Specifications
Frequency Response (+/-3 dB)
Frequency Response (+/-10 dB)
Sensitivity @ 1 w / 1 meter
Maximum SPL (peak @ 1 meter) Half space.
Low Frequency Transducer
Size (mm / inches)
Coil Size (mm / inches)
Low-Frequency Power Amplifier (Class D) 500 W Continuous / 1000 W Peak
Crossover Frequency
Amplifier Protection
Power On Protection
Thermal Protection Amplifier shutdown, auto reset
Driver Protection
Short Protection
Limiter Indicator
Input Connector
Input Impedance
Maximum Input Level
Input Sensitivity
Link Output Connector
Polarity Switch Selection
AC Power details
AC Power Options
Power Indicator Green (back) / Blue logo (front)
Enclosure Material
Pole Mount (Top)
Dimensions (Unpacked)(mm / inches)
Dimensions (packed)(mm / inches)
Net Weight (kg / lbs)
Gross Weight (kg / lbs)
Note : Specifications may be subject to change without notice.
Model Name T-Sub-AX12B
System Type Active 12" Subwoofer
50 Hz-200 Hz
45 Hz-250 Hz
97 dB
130 dB
305 mm / 12"
Quad layer 51.3 mm / 2"
Impedance
Amplifier
LPF 80-200 Hz (adjustable)
Controls
Power switch on / off mute
DC Protection
Red LED
Input type Balanced
2 x socket XLR
47 kΩ Balanced
-10 dBu
2 x pin XLR
0° / 180°
Power Supply SMPS
100 V-120 V and 200 V-240 V
Enclosure
15 mm Plywood
Colour Black
Paint
Tough-Tone
Grille 1.5 mm steel
35 mm
Height 378 mm / 14.9"
Width 493 mm / 19.4"
Depth 468 mm / 18.4"
Height 475 mm / 18.7"
Width 563 mm / 22.2"
Depth 538 mm / 21.2"
Weight
21.0 kg / 46.2 lbs
25.5 kg / 56.1 lbs
T-Sub-AX12B
QUICK START GUIDE
Product Features
• 500 Watts Continuous
• 1000 Watts Peak
• 130 dB Max SPL @ 1 meter
• Birch plywood construction
• Illuminated LED front logo badge
• Convection cooled Class D amplifier
• Adjustable low pass filter
4 Ω
• 2.0" voice coil
• Quad layer driver design
• Tough-Tone paint finish
• 35 mm pole socket & durable handles
Yes
Yes
Yes
Yes
5 V
Overview
493.0
468.0
410.0
