LUTEC 6222-D2D Owner's Manual

Led floodlight
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

LED FLOODLIGHT
Owners Manual
MODEL #6222-D2D
IMPORTANT,
RETAIN FOR FUTURE REFERENCE:
READ CAREFULLY
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6222-D2D and is the answer not in the manual?

Questions and answers

Marcel Sawyer
June 17, 2025

How do you attach the foam pad to the mounting plate? With a screw?

0

Subscribe to Our Youtube Channel

Related Manuals for LUTEC 6222-D2D

Summary of Contents for LUTEC 6222-D2D

  • Page 1 LED FLOODLIGHT Owners Manual MODEL #6222-D2D IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY...

  • Page 2: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fixture HARDWARE CONTENTS (not shown actual size) Screw Wire Nut Mounting Rubber Foam Plate Plug Qty. 3 Qty. 1 Qty. 1 Qty. 1 Qty. 2...

  • Page 3: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. WARNING: • Consult a qualified electrician if you are not certain about the installation process. Always install wiring connections in accordance with local code, ordinances and the National Electric Code. •...
  • Page 4 2. Remove the screw pre-assembled in the mounting plate (CC). Put the screw a side as they will be used later. 3. Attach the mounting plate to the junction box (not included) using the two screws (AA). Then attach the foam pad (EE) to the mounting plate.
  • Page 5 5. Attach the light fixture (A) to the mounting plate using the screw previously removed in step 2. Then insert the rubber plug (DD). 6. After mounting the fixture, apply silicone caulking compound completely around the perimeter of the cover plate where the back of the cover plate meets the mounting surface.

  • Page 6: Care And Maintenance

    OPERATING INSTRUCTIONS The photocell in the fixture is designed to detect light and prevent the fixture from turning on when it senses daylight. At dusk, the light will turn on throughout the night until dawn. At dawn, the light will turn off throughout the day until dusk. Note: To check if the fixture is operating properly, cover the photocell with your fingers so no daylight can reach the photocell.

  • Page 7: Year Limited Warranty

    PRODUCT. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES SO THE ABOVE EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU. LUTEC USA LLC: 149B Houston Rd Troutman NC 28166 Ningbo UTEC Electric Co.,LTD CN8, Far East Industry Park, Yuyao, China www.lutec.com...

This manual is also suitable for:

6222w-d2d
