- Page 1 The Cascade DAC User Guide Check our website for the most recent user guides, firmware and drivers at: www.msbtechnology.com/support Technical support email is: Hello@msbtechnology.com 07.17.2024...
- Page 3 The Cascade DAC Support Page All Cascade DAC support topics, as well as a full PDF version of this user guide, can be found online by scanning the following QR Code or by visiting the URL listed below. www.msbtechnology.com/dacs/cascade-support/ Cascade Series YouTube Playlist...
-
Page 4: Setup And Quick Start
Setup and Quick Start The Cascade DAC interface is simple with few user controls. The input source defaults to auto switching and the display will let you know if you have an active input. Make the necessary connections, power on your system and turn the volume knob up until you hear music. - Page 5 Step 3. Use the included single mode fiber cable to connect the Cascade Link on the Digital Director to the Cascade Link on the Analog Converter. Step 4. Connect the balanced analog outputs of the Analog Converter to the power amplifier(s) or preamplifier. If using an external preamplifier, make sure to bypass the volume control by using the “Preamp Off”...
- Page 6 Step 5. Connect all of your desired digital audio sources to the matching digital inputs on your Digital Director. The Digital Director will automatically switch to any active digital input source. Once a source has been switched to, the Frequency of the incoming digital source will be displayed on the unit.
- Page 7 Digital Director User Interface Menu The Menu button is single purpose: it will enter the Button setup menu at the top of the menu tree. If in the setup menu (it doesn’t matter where), this button will exit the setup menu and return to the normal audio listening function.
- Page 8 Display Variations and Information There are two variations of the display depending on what informa- tion you would like to have visible at any given time. There are also a few details that can be found on the display indicating certain options or settings have been chosen.
- Page 9 The Powerbase The powerbase will detect the input voltage and switch to 120 volt or 240 volt operation as needed. It is also available in a fixed 100 volt configuration. The powerbase has over-voltage protection that will help protect the unit. Fuse - 2.5A 250V SLO BLO - 5 mm x 20 mm mini fuse on the jack panel.
- Page 10 The MSB Remote Power On/Off Powerbase on and off. When the powerbase is linked to an amplifier or MSB product via the 12 volt trigger system, this button will turn off the entire system. Indicator LED While in use: White - Command Sent Red and White - Command Sent and Low Battery Red Flashing - Needs Charging...
- Page 12 Saving Menu and Startup Settings When changing settings in the menu, use the enter button in the center of your volume wheel on the remote or the right arrow on the Digital Director to confirm settings in the menu. In oder to save the changes you have made in the menu, use the “menu button”...
- Page 16 About the Input Module Slots The Digital Director has four input module slots. They are labeled A through D. Input modules can be placed in any position. Each module is completely self-contained. It is recognized by the Digital Director and identified on the display. When the module is not in use, it is disabled.
- Page 17 Available Input Modules If the digital inputs in the Digital Director do not fulfill your full digital input requirements, a list of the currently available modules and their intended uses are listed below. A full digital list of these inputs, as well as a comprehensive list of pros and cons for each input format, can be found online by scanning the following QR Code or by visiting the URL listed below.
- Page 18 1: RS-232 The Digital Director features an RS-232 control port on the back of the unit that can be used with whole home control systems and for home theater integration. A full list of commands and coding can be found using the QR code below.
-
Page 19: Updating Firmware
Updating Firmware The following instructions are for updating the firmware in the Cascade DAC. Simply play the firmware files (which are .WAV audio files) like normal audio files to update your Cascade DAC. The most up-to-date instructions can be found online. Updating Firmware Begin by downloading the firmware. -
Page 20: Troubleshooting Error Codes
Troubleshooting Error Codes Error codes report on the display in the top left corner instead of sample rate. “Pwr Err” • Problem with the Analog Converter or Powerbase power. Contact MSB. “Bad Power” • Indicates that there is a problem with the power in the digital director. -
Page 21: Display Messages
Display Messages The following messages will be displayed during power up: “Waiting for DAC” • On power up of the director, it’s looking for a connected and powered on Analog Converter. If it persists, check that you have properly connected the Cascade Link and have powered on your Analog Converter. - Page 22 The Cascade DAC Warranty Registration All MSB Technology products come with a standard 2-year warranty. Details are defined below. We offer an additional 3 years of extended warranty for the original owner (a total of 5 years) if the following warranty registration form is completed within one year of the manufacture date.
- Page 23 The Cascade DAC Limited Warranty Warranty includes: • MSB warranty covers the unit against defects in materials and workmanship for a period of 2 years from the original manufacture date. • This warranty covers parts and labor only; it does not cover shipping charges or tax/duty.
-
Page 24: Technical Support
Technical Support If you are experiencing any issues with your MSB product, please contact your nearest dealer or try our support page at www.msbtechnology. com/support. Please be sure you have the most current edition of your products’ firmware installed. If your issue persists, please feel free to contact MSB directly. - Page 25 Cascade DAC Specifications Supported Formats 44.1kHz to 3,072kHz PCM up to 32 bits (Input dependent) 1xDSD, 2xDSD, 4xDSD, 8xDSD Supports DSD via DoP on all inputs Digital Inputs 4x Advanced isolated input module slots XLR Analog Inputs 50K Ohm Balanced 6Vrms Maximum Isolated when not selected XLR Analog Outputs 3.32Vrms Maximum (Digital Input)
