- Page 1 The Premier DAC User Guide Check our website for the most recent user guides, firmware and drivers at: www.msbtechnology.com Technical support email is: Hello@msbtechnology.com 04.12.2023...
- Page 3 Any Premier DAC support videos, as well as other related product videos, can be found online by visiting the URL listed below or by scanning the following QR Code. https://www.youtube.com/playlist?list=PLA1wHoJozHNd2zY- bva4EuA1jdLbzXoD_ This user guide is modeled after the following firmware revisions: The Premier DAC: 22.14 The Premier Digital Director: 11.11...
-
Page 4: Setup And Quick Start
Use both cables to connect each of the power connectors located on the Premier Powerbase to both of the power connectors located on the back of the Premier DAC. How to Disconnect Dual-link Cables To disconnect a Dual-link cable, simply pinch the portion of the cable where the flat portion and arrow symbol are located and pull the shoulder of the cable directly back from the jackpanel. - Page 5 Step 3. Connect the Analog outputs of your Premier DAC to the power amplifier(s) in your audio system. Step 4. Connect all of your desired digital audio sources to the matching digital inputs on your Premier DAC. The DAC will automatically switch to any active digital input source.
- Page 6 DAC User Interface Menu The Menu button is single purpose. It will enter the Button setup menu at the top of the menu tree. If in the setup menu (it doesn’t matter where) this button will exit the setup menu and return to the normal audio listening function.
- Page 7 Premier Powerbase The powerbase contains isolation technology. The powerbase detects the input voltage and switches to 120 volt or 240 volt operation. It’s also available in a fixed 100 volt configuration. This powerbase has over-voltage protection. Two fuses are provided: - 5A 250V Slow blow - 5 mm x 20 mm miniature fuse - 100mA 250V Slow blow - 5 mm x 20 mm miniature fuse (Internal standby supply only).
- Page 8 The MSB Remote Power On/Off Powerbase on and off. When the powerbase is linked to an amplifier or MSB product, this button will turn off the entire system Indicator LED While in use: White - Command Sent Red and White - Command Sent and Low Battery Red Flashing - Needs Charging While charging:...
-
Page 10: Phase Invert
Saving Menu and Startup Settings When changing settings in the menu, use the enter button in the center of your volume wheel on the remote, or the right arrow on the DAC faceplate to confirm settings in the DAC menu. After you have made your changes in the DAC menu, use the menu button to exit the DAC menu completely to save the changes you have made while in the DAC menu. - Page 14 About the Two Input Module Slots The DAC has two input module slots. They are labeled A and B. Input modules can be placed in any position. Each module is completely self contained. It is recognized by the DAC and identified on the display.
- Page 15 Available Digital Input Modules If the standard digital inputs available on the Premier DAC do not fulfill your full digital input requirements, a list of the currently available modules and their intended uses are listed below. A full digital list of these inputs, as well as a comprehensive list of pros and cons for each input format, can be found on our website by scanning the QR code or visiting the URL listed below.
-
Page 16: Updating Firmware
Updating Firmware The following firmware instructions are for updating DAC and Digital Director firmware. If you do not have a Digital Director installed in your system, then ignore any Digital Director instructions. The firmware files are .WAV audio files. Updating DAC Firmware - Before Digital Director Install To start, if you have not installed your digital director in your system, first begin by updating the DAC firmware. - Page 17 Updating Firmware with a Digital Director (cont.) Now, play the DAC firmware update. After the DAC firmware is installed and complete, you can now play the Digital Director firmware. Finally, go back into the menu and enable the Digital Director filtering again. After the firmware updates are complete, you can check for a successful connection between the Digital Director and DAC indicated by a small “+”...
- Page 18 Premier Powerbase - Advanced Setup The Premier Powerbase comes with a few features that are not required for basic operation. These features are mainly used for altering your system setup and slight ease-of-use improvements. The 12-volt trigger is a network of 3.5mm mini-jack connections that can make your Premier Powerbase power button turn on/off your MSB amplifier(s) using the power button located on the faceplate or the power button on your remote to create a single power control for your entire MSB...
- Page 19 Shielding Ground - Enhanced Operation The Enhanced Operation provides isolation for both the DAC and the amplifier. This gets you the full isolation available. With the jumper disconnected, connect the supplied ground wire from the AMPLIFIER GROUND lug to the chassis of the amplifier. Note this connection is dependent on the amplifier, so you will have to look for the best place to attach the wire.
- Page 20 Premier DAC Specifications Supported Formats 44.1kHz to 3,072kHz PCM up to 32 bits (Input dependent) 1xDSD, 2xDSD, 4xDSD, 8xDSD Supports DSD via DoP on all inputs Digital Inputs 1x XLR 1x Coaxial RCA 2x Toslink 1x Word-Sync Output (BNC) 2x Advanced isolated input module slots XLR Analog Output 3.57Vrms Maximum Galvanically isolated 150 Ohm Balanced (High Gain)
- Page 21 Premier Powerbase Specifications AC Voltage 100 / 120 / 240V (Auto Switching) Power 45 Watts with fully configured Discrete DAC Consumption Chassis Dimensions Width: 17 in (432 mm) Depth: 12 in (305 mm) Height without feet: 2 in (51 mm) Stack height: 2.65 in (68 mm) Weight: 18 lbs (8.2 kg) Product Feet: M6X1 Thread...
-
Page 22: Technical Support
Technical Support If you are experiencing any issues with your MSB product, please contact your nearest dealer or try our support page at www.msbtechnology. com/support. Please be sure you have the most current edition of your products’ firmware installed. If your issue persists, please feel free to contact MSB directly. - Page 23 The Premier DAC Limited Warranty Warranty includes: • MSB warranty covers the unit against defects in materials and workmanship for a period of 3 years from the date the unit was originally shipped from MSB. • This warranty covers parts and labor only; it does not cover shipping charges or tax/duty.
