Summary of Contents for MSB Technology The Premier Digital Director
- Page 1 The Premier Digital Director User Guide Check our website for the most recent user guides, firmware, and drivers: www.msbtechnology.com Technical support email is: techsupport@msbtechnology.com 12.13.2022...
-
Page 3: Technical Specifications
Technical specifications Supported Formats 44.1kHz to 3,072kHz PCM up to 32 bits (Input dependent) 1xDSD, 2xDSD, 4xDSD, 8xDSD Supports DSD via DoP on all inputs Digital Inputs 4x Advanced isolated input module slots Controls 12 Volt trigger IR remote control Fuse 2.5A 250V SLO BLO - 5 mm x 20 mm fuse. -
Page 4: Setup And Installation
*** ATTENTION! *** Before installing your new digital director, your DAC firmware must be updated to 3.0.2.1 for Select, 30.21 for Reference, and 20.14 for Premier or later. Otherwise, The Digital Director will not function. Setup and installation Step 1 - New firmware If needed, update your DAC firmware to the latest available version. - Page 5 Step 2 - Swap digital input modules ***POWER OFF YOUR AUDIO SYSTEM*** Install the provided Pro ISL input module into slot ‘B’ of your DAC and install the provided Control Link module into slot ‘A’. Then, install any other digital inputs from your DAC into your Digital Director. When installing and removing input modules please use the tips below for proper handling to reduce risk or damage to your MSB system.
- Page 6 Step 3 - Make cable connections After swapping your input modules, the last step is to make a few connections. A description of each connection can be found in the table below as well as a detailed connections diagram on the following page.
- Page 7 When installed properly, your system should look like the example above. The digital inputs installed in your digital director may vary depending on what sources are in your system, However; the only modules that should be installed in the DAC will be the provided Pro ISL and Control Link modules as well as any analog input modules you may have in your system.
- Page 8 Digital Director menu options The following menu options will be viewable in your DAC menu when a digital director is detected in your system. The Digital Director needs to be set to the ‘passthrough’ setting whenever you are updating the firmware in your DAC with the digital director connected.
- Page 9 This page left intentionally blank by MSB Technology...
-
Page 10: Technical Support
Technical Support If you are experiencing any issues with your MSB product, please contact your nearest dealer or try our support page at www.msbtechnology. com/support. Please be sure you have the most current edition of your products firmware installed. If your issue persists please feel free to contact MSB directly. - Page 11 The Digital Director Limited Warranty Warranty includes: • MSB warrants the unit against defects in materials and workman- ship for a period of 1 year from the date the unit was originally shipped from MSB. • This warranty covers parts and labor only, it does not cover shipping charges or tax/duty.
