- Page 1 RF6933-N Outdoor Wireless Curtain Dual Tech Detector Installation Sheet 20 cm 2 - 2.5 m Side View 12 m Top View 12 m © 2023 Carrier P/N 466-6842-EN • REV B • ISS 13JUN23 1 / 4...
- Page 2 2 - 2.5 m Top View Side View T-Bracket Optional Accessory 6932AMP-TB 6932 AMP-TB P/N 466-6842-EN • REV B • ISS 13JUN23 2 / 4...
- Page 3 * 6932AMP-SB Pulse Pulse count 1 count 2 12 m EN: Installation Sheet Basic installation, beam outward from surface See Figures 2, 6, 10, 11. Installation guidelines Fix the detector to the wall using mounting holes A (see Figure 10). Do not obstruct the detector field of view.
- Page 4 8 seconds to cause an alarm. new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info Specifications Part number RF6933-N Wireless Dual Tech Curtain Contact information Detector, white firesecurityproducts.com or www.aritech.com Detection selectable range 3, 6, 9, 12 m...
