5
OTHER FUNCTIONS

Channel Set mode operation

This function is convenient to rewrite Frequency, CTCSS tone, and DTCS code which are not assigned to the
memory channel�
L The Frequency can be changed from 16 channels�
z Procedures
Setting a CTCSS tone (p� 5-4)
1� Turn OFF the transceiver�
2� Hold down [Side], [
• "CH ST," and then channel number is displayed�
1. Selecting a channel
3� Push [▲] or [▼] to select a desired channel.
4� Push [CH/SET] to set the channel�
2. Selecting an operating frequency
5� Push [▲] or [▼] to select a desired frequency number.
• "FT" and the currently selected frequency number
are displayed�
6� Push [CH/SET] to set the number�
• Frequency number list
Number Frequency (MHz)
1 446�006250
2 446�018750
3 446�031250
4 446�043750
5 446�056250
6 446�068750
7 446�081250
8 446�093750
Turning ON the transceiver (p� 5-3)
Selecting a channel (p� 5-3)
Selecting an operating frequency (p� 5-3)
Selecting a tone type (p� 5-4)
], and [ ] to turn ON the transceiver and enter the Channel Set mode�
Number Frequency (MHz)
9 446�106250
10 446�118750
11 446�131250
12 446�143750
13 446�156250
14 446�168750
15 446�181250
16 446�193750
FELLECS-TECH | inbox@fellecs-tech.com | www.fellecs-tech.com
Setting a DTCS code (p� 5-5)
5-3
