OPERATING GUIDE
PMR446 TRANSCEIVER
|U20SR
Ihr Partner für Funktechnik
www.fellecs-tech.com
inbox@fellecs-tech.com
INTRODUCTION
1
PANEL DESCRIPTION
2
BASIC OPERATION
3
ADVANCED OPERATION
4
USER SET MODE
5
OTHER FUNCTION
6
OPTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-U20SR and is the answer not in the manual?

Questions and answers

Summary of Contents for Icom IC-U20SR

  • Page 1 OPERATING GUIDE INTRODUCTION PANEL DESCRIPTION PMR446 TRANSCEIVER BASIC OPERATION |U20SR ADVANCED OPERATION USER SET MODE OTHER FUNCTION OPTIONS Ihr Partner für Funktechnik www.fellecs-tech.com inbox@fellecs-tech.com...
  • Page 2 SAVE THIS OPERATING GUIDE— This operating guide contains additional important operating instructions for the IC-U20SR. Icom is not responsible for the destruction, damage to, or performance of any Icom or non-Icom equipment, if the malfunction is because of: • Force majeure, including, but not limited to, fires,...
  • Page 3: Table Of Contents

    Section PANEL DESCRIPTION Front, top and left side panels ����������������������������������������������������������1-2 D Operating keys �����������������������������������������������������������������������������������������1-2 D About the Software Key functions ������������������������������������������������������������1-2 Right side panel ��������������������������������������������������������������������������������1-3 Function display �������������������������������������������������������������������������������1-3 D Connectors �����������������������������������������������������������������������������������������������1-3 Assignable Software Key functions ��������������������������������������������������1-4 FELLECS-TECH | inbox@fellecs-tech.com | www.fellecs-tech.com...
  • Page 4: Section 1 Panel Description

    PANEL DESCRIPTION Front, top and left side panels DOperating keys [PTT] switch [Top]* Hold down to transmit, release to receive� Antenna [ ] key Hold down for 1 second to turn the transceiver ON or OFF� Speaker [CH/SET] key [PTT] •...
  • Page 5: Right Side Panel

    PANEL DESCRIPTION Right side panel DConnectors SPEAKER MICROPHONE JACK To connect an optional speaker microphone or headset� USB CONNECTOR (Type-C) [USB] For only charging the battery� L The USB connector does not support USB Power Delivery (USB PD) or data communication� Speaker microphone jack CAUTION: DO NOT use the transceiver without...
  • Page 6: Assignable Software Key Functions

    PANEL DESCRIPTION Assignable Software Key functions Null No function� Emergency 1� Hold down during the Emer SW ON Timer period to enter the Emergency mode� 2� After the Reminder Timer period has passed, an Alert-Ring call is automatically transmitted once or repeatedly�...
  • Page 7 Section BASIC OPERATION Turning ON the transceiver ��������������������������������������������������������������2-2 D Turning ON the transceiver ����������������������������������������������������������������������2-2 D Adjusting the audio level ��������������������������������������������������������������������������2-2 Selecting a channel ��������������������������������������������������������������������������2-2 D Selecting an operating channel ����������������������������������������������������������������2-2 Receiving and transmitting ���������������������������������������������������������������2-3 D Receiving �������������������������������������������������������������������������������������������������2-3 D Transmitting����������������������������������������������������������������������������������������������2-3 D Transmitting notes ������������������������������������������������������������������������������������2-3 Call-Ring operation ���������������������������������������������������������������������������2-4 Smart-Ring operation �����������������������������������������������������������������������2-4 FELLECS-TECH | inbox@fellecs-tech.com | www.fellecs-tech.com...
  • Page 8: Section 2 Basic Operation

    BASIC OPERATION Turning ON the transceiver Selecting a channel DTurning ON the transceiver DSelecting an operating channel 1� On the Standby screen, push [CH/SET]� NOTE: Before using the transceiver for the first time, • Enters the Channel Select mode, and the channel the battery pack must be fully charged for optimum number blinks�...
  • Page 9: Receiving And Transmitting

    BASIC OPERATION Receiving and transmitting DTransmitting notes DReceiving When a call is received, the antenna icon is displayed� Transmit inhibit function z Push [▲] or [▼] to adjust the audio output level to a The transceiver has several inhibit functions which comfortable listening level�...
  • Page 10: Call-Ring Operation

    BASIC OPERATION Call-Ring operation Smart-Ring operation This function sends the preset ringer to your group This function can judge whether the other station members� is within range or out of range� A transceiver that z Hold down [S-Ring/C-Ring] for 1 second to send receives a Smart-Ring call from another transceiver the preset ringer�...
  • Page 11 Section ADVANCED OPERATION Emergency function ��������������������������������������������������������������������������3-2 D Transmitting an Alert-Ring call �����������������������������������������������������������������3-2 FELLECS-TECH | inbox@fellecs-tech.com | www.fellecs-tech.com...
  • Page 12 ADVANCED OPERATION Emergency function IMPORTANT: It is recommended that the dealer sets up an Emergency channel to provide a reliable Emergency Alert-Ring call operation� NOTE: Depending on the presetting, the following functions may be automatically activated� Auto RX function After transmitting an Alert-Ring call, the transceiver stands by in the Audible mode for a preset period of time� DTransmitting an Alert-Ring call •...
  • Page 13 Section USER SET MODE User Set mode description ���������������������������������������������������������������4-2 D Operation in the User Set mode ��������������������������������������������������������������4-2 User Set mode items ������������������������������������������������������������������������4-2 D Ringer type of Smart Ringer ���������������������������������������������������������������������4-4 FELLECS-TECH | inbox@fellecs-tech.com | www.fellecs-tech.com...
  • Page 14 USER SET MODE User Set mode description User Set mode items The user can enter the “User Set Mode” to customize Item Display certain transceiver setting� Backlight Beep DOperation in the User Set mode Beep Level Example: Changing the Beep level 1 to 4� Ringer Level 1�...
  • Page 15 USER SET MODE User Set mode items Turns the VOX function ON or OFF� When the VOX function is ON, receiving and transmitting are automatically switched by detecting sounds� NOTE: To use the function, a headset and the optional OPC-2006LS plug adapter cable required (purchase separately)�...
  • Page 16 USER SET MODE User Set mode items DRinger type of Smart Ringer Options Ringer type Description Null The state of the ringer does not change� Turns OFF the ringer� One high ring sounds once� PiPi Two high rings sound once� One high long ring sounds once�...
  • Page 17 Section OTHER FUNCTIONS ID Set mode operation ���������������������������������������������������������������������5-2 Channel Set mode operation ������������������������������������������������������������5-3 Reassigning a key function ��������������������������������������������������������������5-6 VOX function ������������������������������������������������������������������������������������5-7 D Optional unit connection ���������������������������������������������������������������������������5-7 D Turning the VOX function ON or OFF ������������������������������������������������������5-7 FELLECS-TECH | inbox@fellecs-tech.com | www.fellecs-tech.com...
  • Page 18: Section 5 Other Functions

    OTHER FUNCTIONS ID Set mode operation PTT ID function on the MDC 1200 system can send an Own ID with an Alert-Ring call to identify the callers� (p� 3-2) You can rewrite the Own ID with the transceiver� 1� Turn OFF the transceiver� 2�...
  • Page 19: Channel Set Mode Operation

    OTHER FUNCTIONS Channel Set mode operation This function is convenient to rewrite Frequency, CTCSS tone, and DTCS code which are not assigned to the memory channel� L The Frequency can be changed from 16 channels� z Procedures Turning ON the transceiver (p� 5-3) Selecting a channel (p�...
  • Page 20 OTHER FUNCTIONS Channel Set mode operation 3. Selecting a tone type 7� Push [▲] or [▼] to select a desired tone type. 8� Push [CH/SET] to set the tone type� When you select the CTCSS tone: • The current CTCSS tone number is displayed� ➥Go to ʽ4.
  • Page 21 OTHER FUNCTIONS Channel Set mode operation 5. Setting a DTCS code 11� Push [▲] or [▼] to select the desired DTCS code number. 12� Push [CH/SET] to set the number� • DTCS code number list Code Code Code Code Code 01/101 21/121 41/141...
  • Page 22: Reassigning A Key Function

    OTHER FUNCTIONS Reassigning a key function You can reassign another function to the [Side] and [Top] programmable function keys� 1� Turn OFF the transceiver� 2� Hold down [ ], [Top], and [ ] to enter the Key Assignment mode� • “KY ST” is displayed� 3�...
  • Page 23: Vox Function

    OTHER FUNCTIONS VOX function The VOX function toggles the transceiver between transmit and receive by your voice� This function provides hands-free operation� To use the VOX function, the optional OPC-2006LS and an optional headset (HS-94, HS-95, plug adapter cable or HS-97) are required� DOptional unit connection 1�...
  • Page 24 Section OPTIONS Battery charging �������������������������������������������������������������������������������6-2 D Battery charging ���������������������������������������������������������������������������������������6-2 D Charging directly ��������������������������������������������������������������������������������������6-2 D Charging on the cradle �����������������������������������������������������������������������������6-2 D Rapid charging the battery pack ��������������������������������������������������������������6-3 FELLECS-TECH | inbox@fellecs-tech.com | www.fellecs-tech.com...
  • Page 25 OPTIONS Battery charging DBattery charging • Fully charge the transceiver before using it for the first time, or if it has not been used for more than 2 months� The charger automatically restarts charging when the battery voltage drops� • Disconnect the AC adapter from the outlet when not charging the battery� •...
  • Page 26 OPTIONS Battery charging DRapid charging the battery pack You can charge the battery pack with the optional BC-264 � battery charger Install the supplied battery pack so that the terminals of the battery pack and the battery charger meet� Charging time: Approximately 3�8 hours with 5 V/1 A input NOTE: Charging time will be longer in extremely hot or cold environments�...
  • Page 27 How the World Communicates Ihr Partner für Funktechnik www.fellecs-tech.com inbox@fellecs-tech.com A7725-7EU-1 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan © 2023 Icom Inc. Jun. 2023...
