Summary of Contents for nfortec SCULPTOR X
- Page 1 S C U L P T O R X A RGB C P U A I R C OOLER INSTALLATION MANUAL Click on your language to get started...
- Page 2 Warning! ¡Atencion! Only trained personnel may replace or repair components Sólo el personal capacitado puede reemplazar o reparar or elemnets of the product. To avoid damage to property or los componentes o elementos del producto. Para evitar personal injury, please read the enclosed manual carefully daños materiales o personales, lea detenidamente el before proper assembly and installation.
-
Page 3: Technical Specifications
Connector Fan Airflow 73,59CFM±10% 12v power 4pin (PWM) Static Pressure 2,02mm H2O ± 10% Plate Material Aluminium, Copper, Nickel Fan noise level 16.2~31dB(A)±10% 1x Sculptor X Parts Bearing Type Hydro Bearing 1x Installation set for Intel/AMD with thermal paste included... - Page 4 S C U L P T O R X A RGB CP U AI R C O OLER Installation guide for: Intel brackets & AMD brackets SETUP...
- Page 5 ACCESORY BAG Heatsink Fans Fans clips Backplate Intel Intel brackets AMD brackets Intel/AMD screws Screws Standoffs Thermal Grease...
- Page 6 BASIC INSTALLATION Intel Intel LGA 115X/1366/1200/1700...
- Page 7 BASIC INSTALLATION AM4/AM5...
- Page 8 S C U L P T O R X A RGB CP U AI R C OOLER Installation guide for: Intel/AMD Universal bracket SETUP...
- Page 9 ACCESORY BAG Heatsink Fans Fans clips Intel/AMD screws Backplate Intel Intel/AMD bracket AMD Screws Standoffs Intel Screws Standoffs Thermal Grease...
- Page 10 BASIC INSTALLATION Previous steps Tear off protect film before installation. Remove the old thermal paste, and apply the new thermal paste...
- Page 11 BASIC INSTALLATION Intel: LGA1700/1200/115x/1366 1.Adjust the bracket to fit to the Intel CPU socket 3.Install the INTEL locking nuts 2.Plug the bracket at the back of the motherboard 4.Plug the bracket on the INTEL locking nuts 5.Use screws to fix the bracket...
- Page 12 BASIC INSTALLATION AMD: AM4/AM5 1.Remove the motherboard original bracket 2.Install the AMD locking nuts 3.Put the E bracket on AMD locking nuts 4.Use screws to fix the bracket...
- Page 13 BASIC INSTALLATION Fixing the fan 1.Plug the CPU on the motherboard 2.Tear off CPU Cooler protection film, plug it socket, and apply thermal paste on the motherboard and tighten the screws 3.Fix the fan on the radiator with the fan wire buckles, pay attention that fan logo should be visible after installation...
- Page 14 S C U L P T O R X A RGB CP U AI R C OOLER...
