- Page 1 Installation and Operation Manual XCC – Compact Multiflow ERV with Coils Unit XCC425 – XCC925 Manufactured Manufactured by Armcor by Armcor...
-
Page 2: Table Of Contents
Contents Equipment Application Safety Location of Equipment Minimum Access Requirements for Maintenance Noise Levels Fresh Air Inlet and Exhaust Air Outlet Drainage Installation Instructions Unpacking and Inspection Unit Handling Lifting with a Crane Lifting with a Forklift Suspending the Unit Equipment Connections Ductwork Filters... -
Page 3: Equipment Application
Equipment Application The XCC series is a low profile heat recovery unit with the addition of an add-on-coil. Designed for installation in a roof space, these ERV units utilize the Xchange plate heat exchanger with either enthalpy or sensible media. -
Page 4: Safety
Check with Armcor Air Solutions for any information required on this equipment. DANGER Electrical shock can cause personal injury or death. -
Page 5: Location Of Equipment
Location of Equipment It is important that the selected location for the equipment is suitable and can adequately accommodate the unit physical size, the unit weight and has safe and suitable access for correct operation and future maintenance requirements. Minimum Access Requirements Fresh Air Inlet and Exhaust for Maintenance Air Outlet... -
Page 6: Installation Instructions
If damage is evident it should be noted on the freight Wear safety goggles, work gloves, work boots and docket and contact is to be made with the Armcor protective clothing. Air Solutions sales office. A claim should be lodged •... -
Page 7: Equipment Connections
(available at until the final connection is made. Purge pipes using Nitrogen during brazing. Follow guidelines of the armcor.com.au) and are on the identification/serial Airconditioning Manufacturer in relation to pie sizing, no. plate attached to each unit. -
Page 8: Standard Equipment Layout
Standard Equipment Layout XCC – Ceiling Mount Fan Coil Unit Installation and Operation Manual... - Page 9 XCC – Ceiling Mount Fan Coil Unit Installation and Operation Manual...
-
Page 10: General Maintenance
• Armcor Air Solutions are pleased to provide expert • Cleanable Filters. advice on special service maintenance requirements If filters are cleanable, they should be cleaned once a for particular installations. -
Page 11: Warranty
Warranty The Armcor Air Solutions Warranty Policy should be read in conjunction with the Terms and Conditions of Sale. These are available on our website armcor.com.au What The Warranty Policy Covers • Any warranty work performed by Armcor Air Solutions outside of Melbourne metro area will... -
Page 12: Pre-Start Checklist
Pre-start Checklist Unit Installation and Connections Check that equipment is fully installed in accordance with the installation instructions Visually check that air flows will not be obstructed Electrical Visually check all field wiring Tighten all electrical connections including all factory wiring connections Ensure supply cable is correct size Check the required supply voltage is available on all phases Check overload settings are correct (if applicable) -
Page 13: Commissioning Checklist
Commissioning Checklist General Air Filters: Overall Size and Number Drain Pipe Traps and Vents fitted to Indoor Unit as per Installation Instructions Y / N Drain is Clearing Water Properly Y / N Check Vibration of Unit OK / EXCESSIVE Belt Tensioning Adjusted Y / N Paint Finish Checked and Repaired... - Page 14 Notes ........................................................................................................................................................................................................................................................XCC – Ceiling Mount Fan Coil Unit Installation and Operation Manual...
- Page 15 Notes ........................................................................................................................................................................................................................................................XCC – Ceiling Mount Fan Coil Unit Installation and Operation Manual...
- Page 16 E: sales@armcor.com.au P: (03) 8301 9200 109–111 Northcorp Blvd Broadmeadows Vic 3047 © 2024 Armcor Air Solutions reserves the right to alter products and specifications without notice and does not accept responsibility for possible errors and omissions in published documentation.
