- Page 1 Installation and Operation Manual XCM–COMPACT MULTIFLOW ERV XCM125 – XCM1225 Manufactured Manufactured by Armcor by Armcor...
-
Page 2: Table Of Contents
Contents Equipment Application Safety Location of Equipment Minimum Access Requirements for Maintenance Noise Levels Fresh Air Inlet and Exhaust Air Outlet Drainage Installation Instructions Unpacking and Inspection Unit Handling Lifting with a Crane Lifting with a Forklift Suspending the Unit Hanging Bracket Fixing Equipment Connections Ductwork... -
Page 3: Equipment Application
Every proposed installation must be subject to an engineered design by a mechanical services consultant. Armcor Air Solutions is not responsible for performance of equipment in applications for which the equipment was not designed or specified. XCM Specifications... -
Page 4: Safety
Check with Armcor Air Solutions for any information required on this equipment. Danger Electrical shock can cause personal injury or death. -
Page 5: Location Of Equipment
• Every proposed installation must be subject to Drainage an engineered design by a mechanical services consultant. Armcor Air Solutions is not responsible for installation of equipment in situations for which Due to different moisture content levels of incoming the equipment was not designed or specified. -
Page 6: Installation Instructions
If damage is evident it should be noted on the freight few centimetres off the ground level and checking docket and contact is to be made with the Armcor stability before lifting any further or before Air Solutions sales office. A claim should be lodged transporting the unit. -
Page 7: Equipment Connections
(available levels. The unit should be situated as close as on our website armcor.com.au) and are on the possible to the point of use to prevent unnecessary identification/serial no. plate attached to each unit. -
Page 8: Equipment Layout
Equipment Layout The Armcor Compact Multiflow ERV is designed to provide multiple options for duct connection and access to fans/filters. Interchangeable panels can be removed and repositioned on-site to provide options for every installation. Return Air Air that is drawn from conditioned area. -
Page 9: Options For Every Installation
OPTIONS FOR EVERY INSTALLATION Exhaust Air Fresh Air Exhaust Air Fresh Air ENERGY RECOVERY ENERGY RECOVERY Supply Air Return Air Supply Air Return Air Fresh Air Exhaust Air Fresh Air Exhaust Air ENERGY RECOVERY ENERGY RECOVERY Return Air Supply Air Supply Air Return Air Exhaust Air... - Page 10 Fresh Air Exhaust Air Fresh Air Exhaust Air ENERGY RECOVERY ENERGY RECOVERY Supply Air Supply Air Return Air Return Air Fresh Air Exhaust Air Fresh Air Exhaust Air ENERGY RECOVERY ENERGY RECOVERY Return Air Supply Air Return Air Supply Air Exhaust Air Exhaust Air Fresh Air...
-
Page 11: Xcm With Centrifugal Fans
XCM With Centrifugal Fans Step by step directions for changing fan discharge direction on-site. Step 1 Remove the duct spigot panel to expose the fan mounting plate. Step 2 Remove the fan access panel. Step 3 Remove the 4x fan plate mounting bolts. Step 4 Rotate the fan to become side discharged and reattach with the 4x fan plate mounting bolts. -
Page 12: General Maintenance
• Check all cabinet panels for correct fitting, alignment • Armcor Air Solutions are pleased to provide expert and seals, and clean cabinets as required. Ensure no advice on special service maintenance requirements insulation has been detached from the panels. -
Page 13: Pre-Start Checklist
Pre-start Checklist Unit Installation And Connections Check that equipment is fully installed in accordance with the installation instructions Visually check that air flows will not be obstructed Electrical Visually check all field wiring Tighten all electrical connections including all factory wiring connections Ensure supply cable is correct size Check the required supply voltage is available on all phases... -
Page 14: Commissioning Checklist
Commissioning Checklist General Air Filters: Overall Size and Number Drainpipe Traps and Vents fitted to Indoor Unit as per Y / N Installation Instructions Check Vibration of Unit OK / EXCESSIVE Cabinet Panel Finish Checked and Repaired Y / N Ducting Total Return Air Flow (L/s) Total Fresh Air Inlet Air Flow (L/s) -
Page 15: Troubleshooting Guide
Troubleshooting Guide Problem Probable Cause Correction Method Check phase voltage and Voltage Problem rectify Insulation breakdowns Replace faulty component Lock Out Due to Electrical Trip Tighten or replace as Loose Terminals necessary Dirty contactor controls Clean and/or replace Short circuit Trace and correct Earth leakage or over heating Meggar and replace as... -
Page 16: Warranty
Sale. These are available on our • Any appliance plate is altered or removed. website – armcor.com.au • Armcor Air Solutions has not been notified within 48 hours of any fault occurring which may require What The Warranty Policy Covers warranty work. - Page 17 Notes ........................................................................................................................................................................................................................................................Armcor_XCM–Compact Multiflow ERV Installation and Operation Manual 2021...
- Page 18 Notes ........................................................................................................................................................................................................................................................Armcor_XCM–Compact Multiflow ERV Installation and Operation Manual 2021...
- Page 19 ADDITIONAL INFORMATION The XCM series is a compact, horizontal low profile heat recovery unit designed for installation within a roof space, underfloor or in a plant room. Read more here. See our product brochure. Armcor_XCM–Compact Multiflow ERV Installation and Operation Manual 2021...
