Battery - Asus TUF Gaming A15 Series Service Manual

Disassembly Notice Please be sure to pull out adapter and disconnect the battery.
Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage.
Step 1 : Use the non-conductive pry tool to push iron sheet.
Step 2 : Use the non-conductive pry tool to disconnect battery connector.
Step 3 : Remove the screws *3pcs.
Step 4 : Remove the BATTERY.
Step 5 : Disconnect the BATTERY CABLE from the BATTERY.
BATT-56W
3
BATT-90W

BATTERY

1
2
Screws QTY
3 M2*4L (5,0.8) (K) #1
4
5
Disconnect
Spec Torque(kgf-cm)
2.0
12
