Installing the Card and Related Hardware

To install the card and related peripherals:
1. Switch off your system and all peripheral devices, and unplug
2. Touch a metal plate on your system to ground yourself and
3. Remove your system's cover.
4. If you have a memory daughterboard, you may want to mount
5. Find a free 16-bit expansion slot in your system. Remove the
1-4 Setting Up Your Audio Card
If you want to install this Plug and Play (PnP) card in a non-PnP
environment such as DOS/Windows 3.1x or Windows 95
MS-DOS Mode, you must first install a PnP configuration
manager. For more details, refer to the documentation that
comes with your PnP configuration manager.
the power cord from the wall outlet.
discharge any static electricity.
it onto your audio card now, as shown in Figure 1-3.
Connector Pins
Audio Card
Figure 1-3: Mounting the DRAM Upgrade daughterboard.
metal plate from the slot you have chosen and put the screw
aside. The screw will be used in a later step.
Housing
DRAM Upgrade
Daughterboard
