- Page 1 LUKA series USER MANUAL V. 05.07...
- Page 2 Lynx Pro Audio S.L. shall not be liable to the purchaser of this product or to third parties for any damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of an accident, misuse, or abuse of this product, nor for any modifications, repairs, or alterations to it, or for failing to strictly adhere to the operating and maintenance instructions of Lynx Pro Audio S.L.
-
Page 3: Table Of Contents
2. SET UP AND CONNECTION Connectors and connections..................9 LUKA dimensions ......................9 3. FUNCTIONAL DESCRIPTION Block diagrams ......................10 4. OPERATING INSTRUCTIONS Operating procedures ....................11 Display , buttons and encoders ................11 Navigation buttons description................13 Configuration panel....................14 5. SPECIFICATIONS...............................17 6. TROUBLESHOOTING............................18 LYNX PRO AUDIO GUARANTEE........................19... - Page 4 WELCOME Just contact the new generation of digital processors LUKA, designed and manufactured by Lynx Pro Audio S.L. Before working with the processor we recommend that you read this manual, in its pages you will find instructions for use, programming examples and practical advice that will be of great help.
- Page 5 Before unpacking your new processor, verify that the box does not show any damage or deformation. If this happens, please claim the damage to your fordwarder. Once unpacked and verified its correct operation, keep the original box in case you need to ship it back to your provider. LUKA Series | User Manual...
- Page 6 Additionally, the LUKA Series features a set of backup inputs, allowing you to have several inputs available and prioritise one at any given moment, ensuring continuity of the event without interruptions.
- Page 7 For editing parameters, this function allows you to select the desired editing mode. It can also be used to mute the sound directly. 06. USB USB connection from the frontal to set parameters OCS software. LUKA Series | User Manual...
- Page 8 13. FUSE HOLDER A 1A fuse is a safety device that protects electrical circuits from overheating and potential fire damage. Always replace with equivalent fuses. LUKA Series | User Manual...
-
Page 9: Set Up And Connection
2. SET UP AND CONNECTION Connectors and connections XLR SOCKET CONNECTORS INPUTS OUTPUTS 1- GROUND 1- GROUND 2- SIGNAL (+) 2- SIGNAL (+) 3. SIGNAL (-) 3. SIGNAL (-) OVERHEAD XLR CONNECTORS LUKA Dimensions (in mm) LUKA Series | User Manual... -
Page 10: Functional Description
LUKA one of the processors in the market with the best technical characteristics. The process diagram within the LUKA DSPs is as follows: LUKA Series | User Manual... -
Page 11: Operating Procedures
3. FUNCTIONAL DESCRIPTION LUKA Series | User Manual... - Page 12 LED illuminates when the signal exceeds a user-defined threshold, adjustable within the processor’s global configuration. The high-quality compression ensures a smooth and gradual transition to limiting, maintaining pristine audio clarity at all times. This eliminates the harshness often associated with conventional limiters. LUKA Series | User Manual...
-
Page 13: Operating Instructions
In the case that we have entered into the edit menu, these push buttons will help us to select the input or output for editing. The input or output editing will blink in red. LUKA Series | User Manual... -
Page 14: Configuration Panel
This screen lets you configure the matrix of your sound processor. Select the level of complexity that suits you best: Simple, Basic, or Advanced. At the basic level you can select 1, 2, 3, 4,1+2 or 3+4. LUKA Series | User Manual... - Page 15 On this screen, you can view the sound processor’s delay time and access its various configuration options. This screen allow you to open the snapshot preset. The edit screen allows you to select from your existing saved user memories for each input process. LUKA Series | User Manual...
- Page 16 The screen allows you to reset to factory settings. The last screen shows you some general information regarding the processor’s components. Here you can see the processor model, its serial number, DSP firmware and hardware versions. LUKA Series | User Manual...
-
Page 17: Specifications
Band, AllPass order 1, AllPass order 2. Crossover Linkwitz Riley with 12, 24, 48 dB/oct. Delay Input / output: up to 206 ms (70 m) Butterworth and Bessel with 6, 12, 18, 24, 30, 36, 42 and 48 dB/oct. LUKA Series | User Manual... -
Page 18: Troubleshooting
7 – I can not connect by Ethernet Check that the USB cable is not connected, it has priority and internally disables the Ethernet connection. If this is not the case, check the Ethernet connection. LUKA Series | User Manual... -
Page 19: Lynx Pro Audio Guarantee
Lynx Pro Audio S.L. In the case that the product could not be returned to the factory for checking and repairing, Lynx Pro Audio S.L. - Page 20 DECLARATION OF CONFORMITY Lynx Pro Audio S.L. declares that ionic series are in conformity with the following EC directives: Low Voltage Directive 2006/95/EC Electromagnetic Compatibility EMC 2004/108/EC RoHS Directive 2002/95/EC In accordance with Harmonized European Norms: EN 60065:2002 Audio, video and similar electronic apparatus. Safety requirements EN 55103-1:1996 Electromagnetic compatibility.
- Page 21 LYNX Pro Audio S.L. Calle 1. Pol. Ind. Picassent, Picassent, Valencia 46220 España +34 961 109 601 www.lynxproaudio.com...
