greenMachine
callisto
Dual Channel Universal Video and Audio Processing Platform
The greenMachine callisto is a dual channel universal video and audio processing
platform that can process video signals up to 3Gbit.
As a standalone piece of hardware, callisto has a very basic set of functions that
allow a fundamental configuration (e.g. IP settings) and I/O signal monitoring.
Additional processing functionality can be added by installing the required APPs that
can be purchased on the LYNX Technik AG greenStore.
greenStore
www.lynx-technik-greenstore.com
LYNXTechnik
www.lynx-technik.com
Quick
®
Reference
™
AG
Advertisement
Table of Contents
Related Manuals for Lynx greenMachine callisto
Summary of Contents for Lynx greenMachine callisto
- Page 1 Dual Channel Universal Video and Audio Processing Platform The greenMachine callisto is a dual channel universal video and audio processing platform that can process video signals up to 3Gbit. As a standalone piece of hardware, callisto has a very basic set of functions that allow a fundamental configuration (e.g.
- Page 2 UNPACKING THE greenMachine callisto The greenMachine callisto comes with the following items: WHAT‘S IN THE BOX? 1x greenMachine callisto 1x external power supply (RPS 6120) 1x power cord (EU, UK or US) 1x Quick Reference Guide 1x Warranty Card HARDWARE OVERVIEW...
- Page 3 Windows and Mac. You can download the greenGUI from our homepage: www.lynx-technik.com > Support > Download Area > greenGUI After you have downloaded the greenGUI, install it and connect the computer to the same IP network as the greenMachine is connected to.
- Page 4 To start building a constellation (group of APPs), go to the “Constellation Editor“ which you can find in the “APPs“ menu of the greenGUI. Note: If you have purchased a greenMachine callisto bundle (e.g. DualFS, DualUPXD, Dual Transport, or similar) you can skip this step and continue with step 5.
- Page 5 DEPLOYING A CONSTELLATION TO A greenMachine Step 5: To deploy a constellation to a greenMachine, go to the “Universe Editor“, which you can find in the “APPs“ menu of the greenGUI. On the left hand side is a rolodex with all the greenMachines that are within the greenUniverse (i.e.
- Page 6 LOCAL CONTROL AND MONITORING The greenMachine callisto has a local control panel which can be used to fully operate and monitor the module when used stand-alone. The nine push buttons on the left hand side in conjunction with the local display provide everything that is required for a detailed input and output signal monitoring.
- Page 7 “Outputs“ Button Select the “Outputs” button for monitoring based on the output signals instead of the input signals. Processing Configuration Access and control the configuration menus by using the buttons to the immediate left and top right of the display. You can also use the „Back“ button underneath the rotary encoder.
- Page 8 W: 218mm (1/2 19”), H: 44mm (1.75”), D: 225mm (8.86”) - including connectors Weight: 1.1kg (2.43lb) Ambient Temperature: 5°C to 40°C (41°F to 104°F) maintaining specification Humidity: 90% maximum, non-condensing Visit our website for additional information and the latest news on LYNX Technik AG products. LYNXTechnik www.lynx-technik.com © LYNXTechnik AG...
