- Page 1 LS-AES Owner’s Manual interstage Phistersvej 31, 2900 Hellerup, Danmark Telefon 3946 0000, fax 3946 0040 www.interstage.dk - pro audio with a smile...
-
Page 3: Table Of Contents
Optional Equipment ..........................2 System Requirements ......................... 2 Manual Conventions ..........................3 Warranty Registration ..........................3 Locating the Serial Number of Your LS-AES ................... 3 Installation Procedure ..........................4 LynxTWO/L22 Driver........................4 LynxTWO/L22 Firmware ........................4 LS-AES Internal Card Installation ..................... 5 External Connections .......................... -
Page 4: Introduction
Verify that your computer meets or exceeds the following the system requirements specified in the LynxTWO or L22 User’s Guide. The LS-AES requires one expansion card position in your computer. A PCI slot is not required. The LS-AES derives all signals from the host LynxTWO/L22 card via the LStream ribbon cable. -
Page 5: Manual Conventions
Once you are registered you will automatically receive notifications of new products and upgrades. Locating the Serial Number of Your LS-AES To register your LS-AES, you must supply its serial number. The serial number is located on a label attached to the back of the card and on the shipping carton. -
Page 6: Installation Procedure
About Mixer in the Mixer menu of the LynxTWO/L22 Mixer. If you do not have the correct driver version it can be downloaded from the Lynx web site at http://www.lynxstudio.com/download.html. Refer to the Installation section of the LynxTWO or L22 User’s Guide for more information related to driver installation. -
Page 7: Ls-Aes Internal Card Installation
LS-AES LS-AES Internal Card Installation 1. If you are installing one LS-AES internal card, verify that a shorting jumper is in place on JP4 (refer to figure on following page for location). This will set the board’s LStream bus address to 0. -
Page 8: External Connections
LS-AES External Connections The following figure depicts the LS-AES circuit board layout and its connector. JP4 - LStream Address Jumper JP1 - Internal LStream Port Digtial I/O Port Connect the included breakout cable to the bracket- mounted Digital I/O Port connector on the LS- AES. -
Page 9: Lynxtwo / L22 Mixer Controls
With the LS-AES installed, AES-specific controls are displayed as shown below. The LStream page for the LS-AES contains five panels. The leftmost panel, labeled LStream n, includes controls pertaining to LStream and LS-AES routing. The remaining four panels, labeled Digital I/O n, provide control and status for the LS-AES’s digital inputs and outputs. -
Page 10: Digital I/O Panel Description
Use this mode when connecting to external devices that are locked to a clock source that is common to the LS-AES or host card. This mode is also valid if the digital input is selected as the clock source for the LS-AES. -
Page 11: Lstream Interface To The Host Lynxtwo/L22
Double 176.4/192 kHz Quad * The LS-AES uses the first eight channels of an LStream port in single speed mode In dual-card installations, each card is assigned an individual LStream port, thereby doubling the number of signal channels Page 9... -
Page 12: Ls-Aes Output Routing
LStream output channels. This connection scheme allows any (or all) of the digital mixer’s output channels to be routed to the outputs of the LS-AES via the LStream interface. Please note, that the signals sent to host card’s analog and digital outputs will be mimicked on the corresponding LS-AES channels if mixer outputs 1-8 are routed to the LS-AES. -
Page 13: Lstream Output Channel Group Mapping
1-8/9-16 Maps mixer output channels 1-8 to LStream output channels 1-8. Typically, the default setting is easiest to work with since the LS-AES uses only the first eight LStream channels. This setting utilizes digital mixer outputs that are independent of those connected to the host card’s analog and digital outputs. -
Page 14: Ls-Aes Input Routing
LS-AES Input Routing As shown below, the AES data from the LS-AES is routed into the digital mixer of the host card via the LStream 2 Header port. This data can be routed to the record bus using the Input Source Select function within each Input Submixer. -
Page 15: Widewire Channel Mapping
Quad-wire connections require four digital input or output connections to transfer two audio channels. In each case, the number of active LStream channels is reduced. The LS-AES inputs and outputs used for each mode are shown in the following table. -
Page 16: Clocking And Synchronization
LS-AES. Dual Card Systems When using two LS-AES cards with one LynxTWO/L22, the clock source of at least one of the two cards must be set to Slave. Failure to due so will cause unstable clock generation. -
Page 17: Support
Support We are devoted to making your experience with LS-AES trouble-free and productive. If you have questions or comments regarding the operation of your LS-AES please check the Troubleshooting topics on the Support section of the Lynx web site at: http://www.lynxstudio.com/support.html... -
Page 18: Specifications
Core FPGA -based core. Support for field upgrades of firmware. Audio Devices Via host card, the LS-AES’s four digital inputs and outputs are visible to applications as four stereo record devices and four stereo play devices Routing/Mixing Integrates with host card’s digital mixer to allow independent routing of AES I/O with host... -
Page 19: License Agreement
License and Limited Warranty (collectively the “Agreement”). This Agreement constitutes the complete agreement between you and Lynx Studio Technology, Inc. If you do no agree to the terms of the Agreement, DO NOT OPEN the anti-static bag containing the LS-AES board. Promptly return the unopened package and all other items using the original packaging to the location of purchase.
