- Page 1 ZH 用户手册 / 组装说明 EN Instructions for use / assembly instructions Talis Select S 220 72822007...
- Page 2 Bester Service, beste Preise Ihr Online-Fachhändler für: • Kostenlose und individuelle Beratung • TOP Bewertungen • Hochwertige Produkte • Exzelenter Kundenservice • Kostenloser und schneller Versand • Über 20 Jahre Erfahrung E-Mail: info@unidomo.de Tel.: 04621 - 30 60 89 0 www.unidomo.de uniDomo GmbH &...
- Page 3 中文 安全技巧 符号说明 装配时为避免挤压和切割受伤，必须戴上手套。 请勿使用含有乙酸的硅胶！ 冷热水管间过大的压力差必须予以平衡。 安装提示 调节 (参见第页 6) • 安装前必须检查产品是否受到运输损害。 安装后将不认可运输损害或表 热水温度调节。如果使用即热式喷头，则不建议安装热水阀 面损伤。 门。 • 管道和阀门必须根据通用标准进行安装、冲洗和检查。 • 请遵守当地国家现行的安装规定。 大小 (参见第页 7) • 首次调试时和维护作业之后，管接头中的空气可能产生噪音。大约使用 管接头 15 次后噪音消失。 流量示意图 (参见第页 7) 技术参数 1 MPa 工作压强： 最大 备用零件 (参见第页 10) 0,1 - 0,5 MPa 推荐工作压强： 1,6 MPa 测试压强： (1 MPa = 10 bar = 147 PSI) 70°C 热水温度： 最大 操作 (参见第页 8) 65°C 推荐热水温度： 70°C / 4 分钟 热力消毒: 最大...
-
Page 4: Installation Instructions
English Safety Notes Symbol description Gloves should be worn during installation to prevent crushing and cutting Do not use silicone containing acetic acid! injuries. The hot and cold supplies must be of equal pressures. Adjustment (see page 6) Installation Instructions To adjust the hot water limiter. Using a hot water limiter in combination with a continuous flow water heater is not recommended. • Prior to installation, inspect the product for transport damages. After it has been installed, no transport or surface damage will be honoured. Dimensions (see page 7) • The pipes and the fixture must be installed, flushed and tested as per the applica- ble standards. Flow diagram (see page 7) • The plumbing codes applicable in the respective countries must be observed. • During initial start-up and after servicing, air in the fittings can cause noise. After switching the jet on and off about 15 times, the noise will stop. Spare parts (see page 10) Technical Data Operating pressure: max. 1 MPa Recommended operating pressure: 0,1 - 0,5 MPa Operation (see page 8) Test pressure: 1,6 MPa • Hansgrohe recommends not to use as drinking water the first half (1 MPa = 10 bar = 147 PSI) liter of water drawn in the morning or after a prolonged period of... - Page 5 SW 24 mm (4 Nm) (3 Nm) 150° SW 10 mm 110° SW 19 mm (4Nm) 150° 75° 75° 24 x 15° 105° 45° 105° 45°...
- Page 6 110° 55° 55° 24 x 15° 85° 25° 85° 25° SW 12 mm SW 17 mm...
- Page 7 > 2 min 60 °C 10 °C 0,3 MPa SW 3 mm SW 3 mm (5 Nm) 43°C 38°C 55°C 36°C 60°C 50°C...
- Page 8 Maße Maße Talis Select S 220 72822007 2 2 2 2 0 8 2 0 8 Ø 4 9 Ø G1/2 Durchflussdiagramm Durchflussdiagramm 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 9 12 15 18 21 24 27 30 Q = l/min Q = l/sec...
- Page 9 开 / open 热 / hot 关 / close 冷 / cold SW 19 mm SW 10 mm SW 10 mm SW 19 mm (4 Nm)
-
Page 10: Warranty
Reinigung 中文 English 汉斯格雅产品的清洁建议 Cleaning Recommendation for Hansgrohe Products Today, modern sanitary and kitchen tapware, showers, accessories, washstands, 现代的卫浴龙头、厨房龙头、花洒、配件、盥洗台、浴盆和加热器采用的 tubs and radiators consist of very different materials to comply with the needs of the 制造材料非常迥异，以适应产品外形设计和使用功能的市场需求。 market with regard to design and functionality. 为了避免产品损坏和由此引发的投诉及争议，必须在使用和清洁产品时遵 To avoid damage and reclamations, it is necessary to consider certain criteria when 循有关规程。 cleaning. With regard to caring for the Hansgrohe products, the 在保养汉斯格雅产品时，原则上必须注意： following must in principle be heeded: • 只能使用那些有明确注明是适用于本产品的清洁剂。 • Only use cleaning material which is explicitly provided for this type of application. • 不允许使用含有盐酸、蚁酸、氯漂或醋酸的清洁剂，因为这些清洁剂会 给产品表面造成严重的损伤。 • Never use cleaning materials, which contain hydrochloric acid, formic acid, chlorine pale lye or acetic acid, as they cause considerable damage. - Page 11 Serviceteile 92693000 98201000 (14x1,5) 92567000 93174XXX 98463000 93175XXX 98112000 (8x2) 96456000 98211000 (21x2,5) 98365000 98863XXX 98864000 13913000 97685000 93148XXX 98398000 (23x2) 98146000 (25x1,5) 92527000 (27x1,5) 98865000 95372000 (900 mm) 92568000 97523000 97548000 96099000 95049000 92569000 96456000 92500000 95291000 Prüfzeichen...
