HK39
SPECIFICATIONS
·
Weight capacity is 5 lbs. MAX.
·
Must be installed into stud.
1
Determine the position and location of the part on the work
surface. Mark the mounting position for the mounting
hardware and drill a 5.00mm [3/16"] diameter pilot hole
for drywall or a 3.00mm [1/8"] diameter pilot hole for stud
installation.
2024.03.07
TOP VIEW
Stud
PILOT HOLE
TABLE OF CONTENTS
50.00mm
[1-31/32"]
2
Place plastic anchor into 5.00mm [3/16"] diameter pilot
hole.
1
. . . . . . . . . . . . 1X HK39
. . . . . . . . 1X Plastic Anchor
. . . . . . . . 1X M4 X 40.00mm
Hanger Bolt
21.00mm DIA.
[27/32"]
FRONT VIEW
Plastic Anchor
(For drywall
use only)
Advertisement
Related Manuals for Mockett HK39
Summary of Contents for Mockett HK39
- Page 1 TABLE OF CONTENTS · Weight capacity is 5 lbs. MAX... . . 1X HK39 · Must be installed into stud..1X Plastic Anchor .
- Page 2 HK39 HK39 M4 X 40.00mm Hanger Bolt Align HK39 to M4 X 40.00mm hanger bolt. Secure by tightening clockwise and make sure part is fully level on the Align the M4 X 40.00mm hanger bolt to plastic anchor. work surface.
