Page 1: Tellabs Flexsym Bolt Olt Installation And Turnup Guide
Tellabs FlexSym BOLT OLT Installation and Turnup Guide Copyright © 2024 Tellabs ® All Rights Reserved... -
Page 2: Tellabs® Information
Information in this publication is subject to change without notice. Trademarks The following trademarks and service marks are owned by Tellabs Operations, Inc. or its affiliates in the United ® ®... -
Page 3: Table Of Contents
Table of Contents Tellabs FlexSym BOLT OLT Installation and Turnup Guide................1 Tellabs® Information..........................2 Copyright................................2 Trademarks................................2 Proprietary................................2 Tellabs FlexSym BOLT OLT Installation and Turnup Guide............... 4 Description-bolt..............................5 Site Preparation..............................7 Safety Precautions............................. 9 Installation................................. 12 OLT Turnup................................15 Contact Us................................. 21 Page 3 of 21 ©... -
Page 4: Tellabs Flexsym Bolt Olt Installation And Turnup Guide
Tellabs FlexSym BOLT OLT Installation and Turnup Guide Note: This product is currently in Limited Availability and specifications will not be finalized until product General Availability. This document provides instructions to install and turnup the Tellabs® FlexSym BOLT optical line terminal. DOCUMENT REVISION... -
Page 5: Description-Bolt
Tellabs FlexSym BOLT OLT Installation and Turnup Guide Description-bolt OVERVIEW The Tellabs FlexSym ® BOLT Optical Line Terminal (FlexSym BOLT) is a multi-purpose Optical Line Terminal (OLT) enabling open, simple, and scalable connectivity for wired and wireless access over fiber. It supports multiple technologies, massive bandwidth, and in a compact form factor, enabling flexible design options for both fixed and mobile connectivity. - Page 6 Tellabs FlexSym BOLT OLT Installation and Turnup Guide FlexSym BOLT has high-performance Intel processor that allows for the support of future technologies. It can be purchased with either a 4 core or 8 core processors enabling either more cost- effective solutions today, or additional compute for future proofing investment protection (e.g. future routing, firewall, and SDN capabilities).
-
Page 7: Site Preparation
Laptop Computer: A laptop computer is only required if the network is not set up for ZTP. This laptop would · be used for manual turnup of the BOLT OLT and proper configuration of the uplink interfaces. Uplink Lasers: Ensure you have purchased the appropriate Tellabs supported Modules shown in the "OLT · Laser Part Numbers" table shown below. - Page 8 Tellabs FlexSym BOLT OLT Installation and Turnup Guide The BOLT OLT has the following AC power requirements when powered by AC: AC Power Specifications Value Comments AC Input Voltage 100-240VAC AC Input Line Frequency 50-60Hz (nominal) AC Current Rating 2.05 A @ 100VAC, .86 A @ 240VAC...
-
Page 9: Safety Precautions
Warning! Do not open the enclosure unless directed to do so by Tellabs technical support. Doing so is dangerous and voids the warranty. Check that the DC power supply polarity is correct. The system will not be damaged by reversed polarity but ·... - Page 10 Electrostatic Discharge (ESD) Observe and follow all ESD instructions while handling Tellabs plug-in equipment. Caution! The Tellabs plug-in equipment uses semiconductor devices that can be damaged by electrostatic discharge (ESD). Do not remove a plug-in from a protective packing box or equipment rack until time of installation or replacement. To equalize the static charge on the plug-in, establish a body path to ground using an ESD wrist strap connected to a ESD ground.
- Page 11 Tellabs FlexSym BOLT OLT Installation and Turnup Guide Product Disposal The Waste Electrical and Electronic Equipment (WEEE) symbol (shown below) will accompany products that must be collected and disposed of separately from household waste. The black bar under the symbol signifies the product was placed on the market after August 13, 2005.
-
Page 12: Installation
Tellabs FlexSym BOLT OLT Installation and Turnup Guide Installation OVERVIEW The following steps should be followed for hardware installation of the BOLT OLT: Mount the OLT · Install Power Wiring and Grounding · Install Optical Modules · Power up the OLT ·... - Page 13 Tellabs FlexSym BOLT OLT Installation and Turnup Guide OPTICAL MODULE INSTALLATION The optical modules are installed on the front of the BOLT unit. Use only the approved optical modules shown in the site preparation section. There are 16 PON positions on the front left side. There are four SFP+ positions for the 10GE modules, four QSFP+ positions for the 40GE modules, and two QSFP28 positions for the 100GE modules.
- Page 14 Tellabs FlexSym BOLT OLT Installation and Turnup Guide All Provisioned ONT serial numbers are ranged on the PON and there are Green Solid no unexpected ONTs. The state of the PON is good. PON Link Indicates connection status of At least one provisioned serial number exists and is failed (LOPL-LOS) or attached ONTs.
-
Page 15: Olt Turnup
The BOLT is equipped with an Console Serial RJ45 interface which provides direct access to the Command Line Interface (CLI) found on all Tellabs OLTs. To use this interface, attach a standard Cisco serial cable from the OLT Console port to any serial port or USB to serial cable. - Page 16 Tellabs FlexSym BOLT OLT Installation and Turnup Guide BOLT can be accessed via SSHv2 via the IP address that is assigned by DHCP or via the static IP address defined by the turnup wizard. ZTP functionality requires that the ztp URL either be explicitly set, or be obtained via DHCP. See the ZTP documentation for more details on the setup.
- Page 17 Tellabs FlexSym BOLT OLT Installation and Turnup Guide Password must be a minimum of 6 characters for non Admin users. - Password must not exceed 12 characters. - Password cannot be the same as previous 8 passwords. Enter New Password: _...
- Page 18 Tellabs FlexSym BOLT OLT Installation and Turnup Guide Uplink Interface Configuration: Number Of Uplink Interfaces (NETs/LAGS) for element management: (1—2) ..[1] : Configuration Details for Uplink Interface #1: AID of Uplink Interface #1: (NET1)........[NET1] : Number of ports for NET1: (1-4)..........[1] : Enable Link Aggregation Control Protocol (LACP) for NET1: (y/n)....[N] :...
- Page 19 Tellabs FlexSym BOLT OLT Installation and Turnup Guide VLAN ID for Element management Communication This specifies the VLAN ID for management traffic between the OLT and Panorama. VLAN Priority Defines the 802.3P layer 2 priority bits for management packets. It is recommended that the default setting of 7 be used to ensure management traffic continues to flow even if the link becomes oversubscribed.
- Page 20 Tellabs FlexSym BOLT OLT Installation and Turnup Guide IP Static Route Configuration Default Gateway : 192.168.1.1 Element Management Admin State : Enabled IP Stack Type : IPv4 VLAN Priority |============================================================================================| Apply this Element Management configuration(may trigger a restart): (y/n) ....[n]: _ Note: If you made a mistake during Turnup, enter ...
-
Page 21: Contact Us
Contact Us TELLABS TECHNICAL ASSISTANCE CENTER Tellabs TAC is available 24x7x365. Our team is comprised of Support Engineers with years of telecommunications and networking experience, holding a variety of networking certifications in addition to the Tellabs Certification for the product(s) they support.
