- Page 1 BREAD SLICER MODEL NO: USER MANUAL BSMS BSMS-T ----�" •' BSMS BSMS-T SERIAL NUMBER YEAR OF PRODUCTION (€ <@> PAGE / from 1116...
- Page 2 CONTENTS CONDITIONS PAGE NR. COVER CONTENTS PRESENTATION TECHNICAL SPECIFICATIONS GENERAL MEASUREMENTS- POWER PLAN WARNING DIAGRAMS SAFETY-RELATED DETAILS TRANSPORTATION AND BASE REPLACEMENT APPLIANCE USE, CLEANING AND MAINTENANCE 10-12 WARRANTY CONDITIONS 14-16 Exploded view 2/16...
- Page 3 PRESENTATION Dear user, Thank you for choosing our appliance and for your trust in our company. Together with you, our appliances are used in commercial kitchens in 60 countries. Our appliance is manufactured in accordance with international standards. We strongly recommend that you read the operating instructions carefully so that you get the right efficiency from your appliance and can use it for a longer period of time.
- Page 4 TECHNICAL SPECIFICATIONS MODEL BSMS BSMS-T EXTERIOR DIMENSIONS (x-y-z 65x65x70 TOTAL ELECTRICAL 0,37 0,37 POWER (KW) ELEKTRISCHE VERSORGUNGS- SPANNUNG (V) OPERATING FREQUENCY 50/60 50/60 (Hz) SLICING AREA 10-13-16-20 10-13-16 WIRELESS SUPPLY 3x1,5 (H07 RNF) CLASS OF PROTECTION IP 20 IP 20...
- Page 5 GENERAL MEASUREMENTS e e e, ö Front view Side view CODE BSMS BSMS-T 5/16...
- Page 6 ELECTRICAL DIAGRAM ---G>z SWITCH EMERGENCY • STOP LAMP SWITCH 6/16...
- Page 7 WARNINGS NET WATER EARTHING PROTECTIVE EARTHING CURRENT STRENGTH OVERHEATING TEMPERATURE ELECTRICAL CONNECTION VALUES 220V -240V / 50/60 Hz Voltage: 220 V - 240 V Network connection: 220-240 Ground wire Frequency: 50/60 Hz. 7/16...
- Page 8 SAFETY DETAILS ☞ All types of solid liquid materials (clothing, alcohol and derivatives, petrochemical products, wood and plastic materials, curtains, etc.) that can be burnt in the working area of the appliance should never be stored in the vicinity. ☞ Do not clean with high-pressure water. ☞...
- Page 9 TRANSPORTATION AND BASE REPLACEMENT Do not clean with high-pressure water. The appliance is intended for industrial use only and may only be used by trained personnel. The feet of the under-table should be adjusted and the appliance should be operated at scale level. The electrical connection of the appliance must be checked by a qualified electrician.
- Page 10 USING THE DEVICE CONTROL PANEL CAUTION : DO NOT OPERATE THE APPLIANCE WITHOUT HAVING OUR AUTHORIZED SERVICE PERSONNEL INSTALL THE APPLIANCE 1. emergency stop -------------------------1 switch ------------------------------2 2. energy lamp 3. parking switch ----------3 4. movement lever -----------------------------------------------------------------4 USING THE DEVICE Operating instructions Pull the arm.
- Page 11 USING THE DEVICE Slices of the same thickness on any size of bread Easy and precise adjustment depending on the type and thickness of the bread Stainless steel work stations Good for your health Automatic stop at the end of the cut Easy to transport thanks to the wheels Stylish and aesthetic appearance 5 mm reinforced body and stainless steel top cover...
- Page 12 USING THE DEVICE ATTENTION: As described in the installation and usage instructions, make sure that it is installed and operated correctly. Call us if you notice any abnormalities. IN THE EVENT OF DEVICE FAILURE, FAULT AUTHORIZATION ONLY FROM AUTHORIZED SERVICES INTERVENTION BY UNAUTHORIZED PERSONNEL WILL INVALIDATE THE WARRANTY.
- Page 13 1-) The warranty period begins on the date of delivery of the goods and is 2 years. 2-) All parts of the product are warranted by our company. 3-) In the event of a malfunction within the warranty period, the remaining repair time will be added.
- Page 14 14/16...
- Page 15 BSMS - Spare parts CODE NAME CLASS DRAWER BACKSIDE FRONTSIDE DRIVER PRINT CRADLE DRIVER CLAMPS PRESSURE COATING BAND CUTTING KNIFE PACKAGING MIRROR ECCENTRIC SUSPENSION GLASSES 6205 ZZ BEARING UCFL204 BEARING MIDDLE BED CASTING MIDDLE BED SHAFT CASSETTE CONNECTION SHAFT MIDDLE BED BUILT...
- Page 16 BSMS-T - Exploded view 16/16...
