1. summary ......................................................................................................................................................................................2
2. application environment ........................................................................................................................................................ 2
3. Product selection (this product has various specifications as follows) .....................................................................2
4. technical parameter ................................................................................................................................................................. 2
5. The wiring principle ................................................................................................................................................................. 4
6. Installation method .................................................................................................................................................................. 7
7. Induction distance adjustment ............................................................................................................................................. 8
8. dimensions and physical drawings ......................................................................................................................................9
9. induction range and angular displacement ......................................................................................................................9
10. Product warranty terms and description .......................................................................................................................10
11. Manual version ......................................................................................................................................................................11
Phone: 86-0755-33523599
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Shenzhen XingKeChuang Technology Co.， Ltd .
Instructions for infrared sensor
XKC -KE200-PUB
catalogue
FAX: 86-0755-33515410
XKC -KE200-PUB-V10
URL: http://www.sz-xkc.com
1/11
Advertisement
Table of Contents
Related Manuals for XingKeChuang XKC-KE200-PUB
Summary of Contents for XingKeChuang XKC-KE200-PUB
-
Page 1: Table Of Contents
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. XKC -KE200-PUB-V10 Shenzhen XingKeChuang Technology Co.， Ltd . Instructions for infrared sensor XKC -KE200-PUB catalogue 1. summary ......................................2 2. application environment ................................ 2 3. Product selection (this product has various specifications as follows) ..............2 4. -
Page 2: Summary
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. 1. summary Shenzhen XingKeChuang Technology Co.， Ltd . XKC-KE 200 is an intelligent non-contact induction switch, integrating infrared reception and control, equipped with anti-sunlight interference function, the sensing distance under sunlight can reach 150cm, and compatible with indoor and outdoor use; the sensor uses infrared light, when the object, in the front of the sensor, the sensor immediately enters the sensor state, so as to control the output signal;... - Page 3 深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. quiescent current <3.5 mA load current <1A Shenzhen XingKeChuang Technology Co.， Ltd . operating ambient -20～85℃ temperature Storage -20～85℃ temperature wire length 30cm (± 10MM) (batch customizable) material quality The PC-V0 fireproof material Waterproof...
-
Page 4: The Wiring Principle
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. 5. The wiring principle Shenzhen XingKeChuang Technology Co.， Ltd . XKC-KE200-M-NO wiring schematic diagram Operating principle of relay point NO output: 1. When the black line is connected to the VCC: When sensing the object, the relay is closed, the relay NO point conduction, and the output VCC voltage;... - Page 5 Shenzhen XingKeChuang Technology Co., Ltd. b) XKC-KE200-M-NC wiring schematic diagram Shenzhen XingKeChuang Technology Co.， Ltd . Operating principle of relay NC point output: 1. When the black line is connected to the VCC: When the object is induced, the relay is closed, and the relay NC point is disconnected;...
- Page 6 深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. XKC-KE200-NPN wiring schematic diagram Shenzhen XingKeChuang Technology Co.， Ltd . Phone: 86-0755-33523599 FAX: 86-0755-33515410 URL: http://www.sz-xkc.com Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen 6/11...
-
Page 7: Installation Method
Shenzhen XingKeChuang Technology Co., Ltd. Schematic diagram of high and low level wiring XKC-KE200-V Shenzhen XingKeChuang Technology Co.， Ltd . 6. Installation method Open holes in the panel where the sensor needs to be installed with an aperture of 28mm. Install the sensor from the front of the panel and tighten the nut behind the sensor. -
Page 8: Induction Distance Adjustment
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. Shenzhen XingKeChuang Technology Co.， Ltd . 7. Induction distance adjustment The sensor is in the normal operating state, placing approximately 80x60cm of kraft cardboard less than or equal to 80cm directly in front of the sensor. The induction distance adjustment step is... -
Page 9: Dimensions And Physical Drawings
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. Shenzhen XingKeChuang Technology Co.， Ltd . 8. dimensions and physical drawings The tooth pitch is M27.5*0.8mm. 9. induction range and angular displacement Phone: 86-0755-33523599 FAX: 86-0755-33515410 URL: http://www.sz-xkc.com Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen... -
Page 10: Product Warranty Terms And Description
12 months from the date of delivery, the latest DOA application period, to 7 days from the date of delivery. (VI) Statement 1. The copyright of this manual belongs to Shenzhen XingKechuang Technology Co., LTD. Phone: 86-0755-33523599 FAX: 86-0755-33515410 URL: http://www.sz-xkc.com... -
Page 11: Manual Version
4. The contents of this manual may be changed due to the product version upgrade or other reasons. XingKechuang reserves the right to modify the contents of this manual without any notice or prompt. This manual is only used as a guide for use, and StarKechuang tries its best to provide accurate information in this manual.
